- Page 1 Owner’s Manual UPS Systems Models: OMNIVSX850A, OMNIVSX1000A, OMNIVSX1500A (Series Numbers: AG-04F5, AG-04F1, AG-04F2) 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support Copyright © 2020 Tripp Lite. All rights reserved.
-
Page 2: Important Safety Instructions
Important Safety Instructions SAVE THESE INSTRUCTIONS This manual contains instructions and warnings that should be followed during the installation, operation and storage of this product. Failure to heed these warnings may affect the warranty. UPS Location Warnings • Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust or direct sunlight. -
Page 3: Equipment Connection Warnings
Important Safety Instructions Equipment Connection Warnings Short Circuit backup protection and overcurrent protection is provided by the building installation. To reduce the risk of fire, connect only to a circuit provided branch circuit overcurrent protection. The plug on the power supply cord is intended to serve as the disconnect device. -
Page 4: Battery Warnings
Tripp Lite products use sealed lead-acid batteries, which are highly recyclable. Call Tripp Lite at 1.773.869.1234 or visit tripplite.com/support/recycling-program for more information on recycling the batteries or any other Tripp Lite product. Please refer to local codes for disposal requirements. -
Page 5: Quick Installation
Quick Installation STEP 1: Plug the UPS into a properly grounded outlet. After plugging the UPS into a wall outlet, press and hold the power button until a beep is heard, then release to turn on the UPS. Note: The UPS will not turn on automatically in the presence of live utility power. OMNIVSX850A / OMNIVSX1000A / OMNIVSX1500A Local Utility... -
Page 6: Step 3: Turn On The Ups
1. Make sure the UPS is plugged into a live AC outlet. 2. Press the power button to turn on the UPS. A beep should sound when the UPS starts. 3. If the UPS still does not start, contact Tripp Lite Tech Support for assistance. Basic Operation UPS ON/OFF •... -
Page 7: Display Ups/Power Conditions
Basic Operation Display UPS/Power Conditions On-Line AC Power Mode LCD Data The LCD touchscreen offers five screens of UPS and site power information when the UPS is operating in line-power mode. Screens 1-4 (Output Voltage, Input Voltage, Load %, Battery Charge Level) are available for viewing in line-power mode. - Page 8 BATTERY LOW Charge UPS for 24 hours. If problem persists, replace battery VOLTAGE and contact Tripp Lite Technical Support if problem persists. BATTERY MODE Turn off power to the UPS and contact Tripp Lite Technical HIGH OUTPUT Support for assistance.
-
Page 9: Front Panel
USB Communication Port: This port can connect your UPS to any computer for automatic saves and unattended shutdown in the event of a power failure. Use with Tripp Lite’s PowerAlert Software (available as a FREE download at tripplite.com) and the USB cable... -
Page 10: Battery Replacement
Features AC Power Input: Use the Australian power cord to connect the OMNIVSX850A / OMNIVSX1000A / OMNIVSX1500A to the main power source. Replaceable Input Fuse: Protects your electrical circuit from overcurrent draw from the UPS load. If the fuse has blown, remove some of the load, then replace the fuse. The fuse is rated for 5A/250V AC for OMNIVSX850A and 10A/250V AC for OMNIVSX1000A / OMNIVSX1500A. -
Page 11: Storage And Service
If you leave your UPS batteries discharged for a long period of time, they will suffer a permanent loss of capacity. Service A variety of Extended Warranty and On-Site Service Programs are available from Tripp Lite. For more information on service, visit tripplite.com/support. Before returning your product for service, follow these steps: 1. -
Page 12: Regulatory Compliance
Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information.
