User Manual
Quick Installation Guide
3.5" IDE Network Attached Storage
Model # ANAS250
Section 1
Hard Drive Installation
WARNING:
This Network Attached Storage device is not hot-swappable. Please make sure that
it is turned off and not connected to the power outlet when performing the following
assembly procedure.
Step 1
Unfasten the two screws at the rear side of the device, and pull out the
back cover.
Home NAS
Package Contents:
•
Home NAS
•
Vertical Stand
•
Power adapter
•
Ethernet Cable
•
USB Cable
•
Manual CD
•
Quick Installation Guide
•
Screws (4)
Ver. 1.0
Step 2
Pull out the front panel.
Step 3
Put the 3.5-inch IDE hard drive into the plate, and connect the IDE and
power cables to it.
Advertisement
Related Manuals for Airlink101 ANAS250
Summary of Contents for Airlink101 ANAS250
-
Page 1: Quick Installation Guide
Quick Installation Guide Home NAS 3.5” IDE Network Attached Storage Model # ANAS250 Section 1 Hard Drive Installation WARNING: This Network Attached Storage device is not hot-swappable. Please make sure that it is turned off and not connected to the power outlet when performing the following assembly procedure. - Page 2 Step 4 Secure the drive to the plastic plate on the sides with the provided four screws. Step 5 Insert the plastic plate back to the device. Step 6 Re-attach the back panel to the device and secure it with the two screws removed in step 1.
-
Page 3: Configuring Home Nas
Section 2 Accessing Home NAS To access Home NAS, double-click on My Network Place or open Windows Explorer and then type in “\\homenas” into the Address bar and press Enter. Now you can begin accessing your files and using Home NAS to store/backup your data. -
Page 4: Technical Support
Section 4 Section 2 Technical Support E-mail: support@airlink101.com Toll Free: 1-888-746-3238 Web Site: www.airlink101.com * Actual data throughput will vary. Network conditions and environmental factors lower actual data throughput rate. Specifications are subject to change without notice. Copyright ©2007 AirLink101™ All rights reserved. AirLink101, the stylized AirLink101 logo, specific product designations, and all other words and logos that are identified as trademarks and/or service marks are, unless noted otherwise, the trademarks and service marks of AirLink101.
