Summary of Contents for Porsche 911 GT3 Cup
- Page 2 Porsche 911 GT3 Cup Modification Instructions FUEL CELL UPGRADE FROM MY 2014 TO MY 2015...
- Page 3 Rollover Ventil / Roll over valve 900.123.101.30 Dichtring A 12x18 / Sealing ring • • 991.201.043.8H Z Einfüllstutzen Kraftstoff / As filler neck fuel 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 4 Überblick / Overview Notes: MJ F / MY F 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 5 Dismount fuel pump bracket • Only work on the fuel system in well ventilated rooms. • No smoking! • Fuel must only be stored in suitable containers 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 6 Filtergehäuse muss dabei bündig mit der Pumpe an der Tankwand anliegen (siehe Pfeil) / Filter housing must be flash fitted with the fuel cell wall (see arrow) Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 7 Block Nr. 1, Nr. 2 und Nr. 3 in Tank einlegen / Place foam block #1, #2 and #3 into fuel cell Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 8 Pumpe im Halter einrastet / Place main pump into catch tank, guide into bayonet base and turn 90° clockwise until pump clicks into position Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 9 Modifikationen / Modifications Notes: • Catchtank an den drei Halteösen befestigen / Mount catch tank to the three retaining lugs Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 10 • Deckel Catchtank montieren (Anzugsdrehmoment 9 Nm) / Mount catch tank cover (torque to 9 Nm) Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 11 • Block Nr. 4 und Nr. 5 in Tank einlegen / Place foam block #4 and #5 into fuel cell Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 12 • Block Nr. 6 und Nr. 7 in Tank einlegen / Place foam block #6 and #7 into fuel cell Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 13 • Block Nr. 8 und Nr. 9 in Tank einlegen / Place foam block #8 and #9 into fuel cell Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 14 / Tie remaining cables together with cable tie (optinal wires for use of 4 intank pumps) • Spannungsversorgung der Hauptpumpe an Kabelstrang anschließen / Connect main pump power supply with cable loom Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 15 Block Nr. 10 in Tank einlegen / Place foam block #10 into the tank • Kabelstrang zwischen Block 9 und 10 einlegen / Place cable loom between foam blocks #9 and #10 Fahrtrichtung / Driving direction 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
- Page 16 Connect fuel lines and electrical connectors and check for function Note After assembly Hinweis Nach Montage visually check the Leitungsverbindungen pipe fittings to ensure optisch auf Dichtheit there are no leaks. kontrollieren. 911 GT3 Cup (991) 12-Feb-15 Upgrade to MY 15 fuel cell for 991 Cup MY 2015...
