SaniSpray HP
Backpack Kit 25T780
For use with Graco SaniSpray HP 20 Cordless and HP 20 Electrostatic Handheld
sprayers. For portable spraying of water-based disinfectants approved for spray
application only. Not for use with architectural paints and coatings. Not approved for use
in explosive atmospheres or hazardous (classified) locations. For professional use only.
Important Safety Instructions
Read all warnings and instructions in this manual, in the sprayer
manual, and on the sprayer and ProPack before using the
equipment. Be familiar with the controls and the proper usage
of the equipment. Save these instructions.
Important Medical Information
Read the medical alert card provided with the sprayer. It
contains injection injury treatment information for a doctor.
Keep it with you when operating the equipment.
WARNING
CHEMICAL HAZARD
To prevent serious injury:
•
Follow all directions and
requirements on disinfectant
label. It is a violation of Federal
law to use an EPA-approved
disinfectant in a manner
inconsistent with its labeling.
•
Flush after each use. Never
store disinfectant in
equipment.
•
Use only with appropriate
personal protective
equipment.
www.graco.com/techsupport
Use only genuine Graco replacement parts.
The use of non-Graco replacement parts may void warranty.
ProPack
™
www.graco.com/sanisprayhp20esupport
3A8304B
EN
Advertisement
Table of Contents
Related Manuals for Graco SaniSpray HP ProPack 25T780
Summary of Contents for Graco SaniSpray HP ProPack 25T780
- Page 1 3A8304B Backpack Kit 25T780 For use with Graco SaniSpray HP 20 Cordless and HP 20 Electrostatic Handheld sprayers. For portable spraying of water-based disinfectants approved for spray application only. Not for use with architectural paints and coatings. Not approved for use in explosive atmospheres or hazardous (classified) locations.
-
