Before You Begin

Obtaining Optional
Components

Installing the NJ225FX

Setting Up the Power
Supply
Before you begin installation, register your product at: http://eSupport.3com.com.
The IntelliJack is available in single- and 20-packs. Before you begin the
installation, familiarize yourself with the following items, which are included with
the IntelliJack:
• NJ225FX IntelliJack.
• Trim ring
• Two mounting brackets
• Internal power connector
• Two pairs of screws
• Compact disc containing
User Guide and additional informational documents.
n
Configuration Manager software.
n
The switch works with the following optional components, all of which are
available from 3Com. Order online at www.3com.com or by calling
1-877-949-3266.
Component Purpose
Local power For locally powering a single IntelliJack;
supply required if your network does not support
Power Over Ethernet.
NBX Phone For powering over Ethernet a NBX VoIP
Power Module telephone that uses Capacitive Power
Discovery Process by an IEEE 802.3af compliant
PSE.
Due to hardware differences, installing the NJ225FX requires a slightly different
procedure than the NJ225. Please note that the following installation steps are
different for this switch:
• Setting up the power supply
• Mounting the IntelliJack
Power to the IntelliJack 225FX is provided through one of the following two
methods:
1 Directly via AC power: The 225FX has an internal power supply that can accept
100~240V AC power if you have access to AC power near the unit. A green
power connector is supplied that can be securely plugged into the unit. The
connector can accept either solid or stranded power wire.
WARNING: This product should be installed by a qualified electrician to insure
that it is properly installed according to local building code requirements.
Before You Begin 15
3C Number(s)
3CNJPSL
3CNJVOIP-NBX
