Before You Begin

Obtaining Optional
Components for the
NJ225
9 Switched port cable
10 Pass-through LAN
cable
Before you begin installation, register your product at: http://eSupport.3com.com.
The IntelliJack is available in single- and 20-packs. Before you begin the
installation, familiarize yourself with the following items, which are included with
the IntelliJack:
• NJ225 IntelliJack.
• Four pairs of M3.5 x 25mm screws (two per IntelliJack) for mounting the
IntelliJack to the wall, floor box or office cubicle.
• Mounting plate (face plate).
Additionally, the following items are shipped with the single pack:
• Compact disc containing
User Guide and additional informational documents.
n
Configuration Manager software.
n
All screws are phillips pan head type screws. The type of threads vary to match
the different mounting locations compatible with the IntelliJack.
• Thread forming screws for mounting into plastic:
M3 x 30mm (2x)
n
M3 x 40mm (2x)
n
• Machine screws for mounting into metal:
M3.5 x 30mm (2x)
n
M3.5 x 40mm (2x)
n
The switch works with the following optional components, all of which are
available from 3Com. Order online at www.3com.com or by calling
1-877-949-3266.
Component Purpose
Ethernet For providing Power Over Ethernet to power
Multi-port up to 24 IntelliJack devices.
Midspan Power
802.3af-compliant
Supply
Ethernet For providing Power Over Ethernet to power
Multi-port up to 24 IntelliJacks.
Endspan Power
802.3af-compliant
Supply
Connects the NJ225 switched RJ-45ports to the Ethernet LAN.
White cable.
Connects directly to your LAN (located on the front of the
NJ225.) Black cable, no LED.
integrated switch
Before You Begin 3
3C Number(s)
3CNJPSE24
3C17205
