Lightning Protection
Requirements
Table Mount
Requirements

Precautions

Installation Tools,
Meter and Equipment
Many measures have been taken to protect 3000 DSL Family from lightning.
However, if the lightning intensity exceeds a certain range, damage to the router is
still possible. To better protect the router from lightning, the following should be
considered:
Ensure the PGND wire of the chassis is well grounded.
Ensure the ground point of the socket of AC power supply is well grounded.
To enhance the lightning protection capability of the power supply, a
lightning arrester could be installed at the input end of the power supply.
As for the signal line outdoors to which the interface modules of 3000 DSL
Family routers are connected, such as ISDN line, telephone line, T1 line, etc,
a special lightning arrester should be installed at the input end of the signal
line to enhance the lightning protection capability.
There is spacing reserved at the air inlet and outlet in the router so as to
facilitate the radiation of the router cabinet.
The workbenches have good radiation systems.
The workbenches are firm enough to support the weight of the router and
other installation accessories.
The workbench are well grounded.
Routers play a key role in data communications network. Please pay attention to
the following:
It indicates that this operation is incorrect and may seriously damage the router or
endanger the operator. Please follow the correct operation procedures for sake of
safety.
It indicates that during the installation and usage of the router, the operation
needs attention. This operation is incorrect and perhaps will affect the normal
operation of the router.
Please follow these safety recommendations during the installation and use of the
router:
Keep the router away from any wet place or a heat source.
Make sure that the router is normally grounded.
Please wear an ESD-preventive wrist strap before installation; make sure one
end securely contacts your skin, and the other end is well grounded.
Do not hot swap any cable.
Correctly connect the interface cable for the router. Do not connect the
telephone cable (including the ISDN cable) to the AUX port or the console
port.
Always use Uninterrupted Power Supply (UPS).
Tools
Phillips screwdriver
Precautions 23
