Table 5 LEDs of Router 3031
LED
ON means that power is being
supplied.
Port attributes
The Router 3031 provides one console port, four 10/100M Ethernet port, one
ISDN S/T port and one ADSL over POTS port.
These ports are configured and managed as a single logical entity.
The following illustrations depict the components of the Router 3032.
Figure 5 Router 3032 Front Panel
1
3
2 4
1. ETH LED (LAN3)
2. ETH LED (LAN2)
3. ETH LED (LAN1)
4. ETH LED (LAN0)
5. ADSL active LED (DSL ACT)
6. ADSL LINK LED (DSL LINK)
7. System LED (SYS)
8. Power LED (PWR)
Description
5
7
6 8
