EXTERNAL SPEAKER/RINGER AMPLIFIER (BESCB1A)

External Telephone Ringer

BESCB
AC Adapter
Figure 1-12 Telephone External Ringer
DKT/IPT IOU
Set jumper to IOU
1
2
(+) to Red
3
(-) to Green
4
L2 to Yellow
5
6
7
Low impedance speaker use:
Jacketed Twisted Pair 14 - 24 AWG
8
8 - 16 ohm
9
10
2K - 10K ohm
11
High impedance speaker use:
Note: Refer to Figure 1-11.
Figure 1-13 External Ringer Wiring Diagram
1-28
Using the BESCB1A as the interface and amplifier for a loud ringer
external speaker. This option functions a an external loud ringer for an
IPT telephone set.
External
Speaker
IP5000-series Telephone
External Ringer
External Ringer
Jacketed Twisted Pair
24 AWG
LAN
(+)
HESC1A-65 Cable to the speaker
connector on the IPT telephone
IPT Installation Manual Feb,, 2015
External Telephone Ringer
GN
(-)
R
BK Y
L2
BL
W
6 5 4 3 2 1
