- Page 1 9L OIL / FLUID EXTRACTOR MODEL NO: CHT928 PART NO: 1801928 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS LS1020...
-
Page 2: Safety Symbols
INTRODUCTION Thank you for purchasing this CLARKE 9L Oil / Fluid Extractor. This product is suitable for extracting Water, Oils and liquids, Motor Oil, Brake Fluid, Antifreeze, THIS PRODUCT IS NOT SUITABLE FOR EXTRACTING, PETROL OR DIESEL Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. -
Page 3: Safety Warnings
11. DO NOT pull or yank any pipes or hoses and do not attempt to 2. Replace or repair damaged move the extractor by pulling the parts. Use genuine CLARKE parts hose. only. Unauthorised parts may be dangerous and will invalidate the 12. -
Page 4: Part Identification
PART IDENTIFICATION Housing Cover Pump Handle Release Button Fluid Outlet Housing Tank Fluid Inlet Coupler Tube Storage Unit Suction Tube with adaptor Foot rest Extraction Tube with adaptor Base M Brake Tube with Rubber Fitting G Hand Pump Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 5: Before Use
ASSEMBLY 1. Fit the Tube Storage Unit (D) on to the hooks of the Tank (C) as shown. 2. Push down until the Tube Storage Unit (D) snaps into position. BEFORE USE When using the fluid extractor to extract engine oil: •... - Page 6 OPERATING INSTRUCTIONS 1. Position the extractor near the engine. 2. Connect the Suction Tube (K) to the Fluid Inlet Coupler (J) with the Suction Tube Adapter. Connect the other end of the Suction Tube (K) to the Extraction Tube (L) with the Extraction Tube Adapter. 3.
- Page 7 5. Extend the foot rest. 6. Put your foot on the foot rest to steady the unit. 7. Pump the handle up and down through its full travel. • As you pump up and down, the tank starts to fill. 8.
-
Page 8: Troubleshooting
TROUBLESHOOTING Cause Remedy The extractor doesn't suck up 1. Make sure the tube is fully inserted. any fluid. 2. Has all of the fluid been removed. 3. Make sure that the extractor isn't full. BRAKE FLUID SAFETY WARNING: BRAKE FLUID IS FLAMMABLE - KEEP AWAY FROM SOURCES OF IGNITION, INCLUDING HOT SURFACES E.G. -
Page 9: Changing The Brake Fluid
3. Identify the brake bleeding tube which has a blue flexible plastic brake nipple connector at one end and a black rubber adaptor at the other. 4. Connect the brake bleeding tube (M) to the top of the fluid extractor tank by pushing the black rubber adaptor into the fluid inlet coupling. -
Page 10: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Parts List
PARTS LIST Piston Housing Cover Hex Nut M8 Release Button Pump Holder Spring Pump Cylinder Fluid Inlet Coupler Pump Base O Ring Screw M5x16mm Fluid Outlet Housing Nut M5 O Ring Handle Lock Nut End Cap Locking Bushing Screw M5x20mm Shaft Suction Tube With Adapter Spring...
