Page 1: User Manual
Refrigerator user manual imagine Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register Free Standing Appliance the possibilities RL60 * RL58 * RL56 * English... -
Page 2: Safety Information
Important safety symbols and precautions : Hazards or unsafe practices that may result in severe personal injury or WARNING death. -
Page 3: Severe Warning Signs For Installation
(R600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. SEvERE WARNING SIGNS FOR INSTAllATION WARNING • D o not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). - Page 4 Lamp Cover and LED Lamp by yourself. - Please contact your service agent. • I f any dust or water is in the refrigerator, pull out power plug and contact your Samsung Elec- tronics service center. - There is a risk of fire. cAuTION SIGNS FOR...
-
Page 5: Additional Tips For Proper Usage
cAuTION SIGNS FOR clEANING ANd MAINTENANcE cAuTION • D o not directly spray water inside or outside the refrigerator. - There is a risk of fire or electric shock. • D o not use or place any substances sensitive to temperature such as inflammable sprays, inflammable objects, dry ice, medicine, or chemicals near the refrigerator. Do not keep volatile or inflammable objects or substances (benzene, thinner, propane gas, etc.) in the refrigerator. -
Page 6: Getting Ready To Install The Refrigerator
This will help reduce power consumption and keep your energy bills lower. Setting up your refrigerator GETTING REAdY TO INSTAll THE REFRIGERATOR Congratulations on your purchase of the Samsung refrigerator. We hope you enjoy the state-of-art offers. Selecting the best location for the refrigerator • A location without direct exposure to sunlight. -
Page 7: Reversing The Door
2. I f the customer does not feel confident to follow instruction in the user manual, a Samsung qualified service engineer must be contacted to carry out this change. 3. Do not plug in Refrigerator just after door reverse finished process and wait for at least one hour. - Page 8 6. Disassemble the Middle hinge. 7. R emove the freezer door from the Bottom hinge by carefully lifting the door straight up. The door is heavy, be careful not to injure yourself when removing the door. CAUTION 8. Lay the refrigerator carefully. Switch the position of Bottom Hinge and Leg. before after 9.
-
Page 9: Levelling The Refrigerator
14. Assemble the Hinge case to the hinge. (Use left hinge case which can be found underneath the Hinge Cover). 330mm 15. A ssemble the Wire Covers ( ① ) and Door Cover ( ② ). ① 16. Connect wires and Assemble the Hinge Cover. 17. Switch the handles from the to left the right. 18 . -
Page 10: Checking Control Panel
Operating your refrigerator cHEcKING THE cONTROl pANEl (TYpE A) (TYpE b) Each time you press the button, a short beep will sound. Fridge Press the Fridge button to set the fridge to desired temperature from the range between 1°C and 7°C. Default set temperature is set on 3°C and each time you press the Fridge button, temperature will change in following order and temperature... -
Page 11: Quick Cool
Cool Select Zone Quick Cool( • I f you want to cool down food quickly, store food in Cool Select Zone and Select Quick Cool Mode. • Cool Select Zone will cool food for 60 minutes. • W hen Quick Cool mode is completed, the Cool Select Zone drawer will automatically set the mode to Cool. Zero Zone( • W hen you select Zero Zone mode, temperature of the Cool Select Zone will be set on 0°C. • A ctivate this Chill function for the storage of highly perishable foodstuffs. -
Page 12: Making Ice
MAKING IcE 1. Fill the tray up to 80% with water level. 2. Place the ice tray in the top freezer drawer. 3. W ait until the ice cubes are formed. 4. Twist the ice tray slightly to take out the ice cubes. Freezing time It is recommended that you wait for about 1~2 hour with the temperature set to Power Freeze for the ice cubes to form. -
Page 13: Cleaning The Refrigerator
Drawers Pull the drawers out fully then slightly lift it up to remove the drawers. ( Fresh Room Drawer, Cool Select Zone Drawer, Freezer Drawers) clEANING THE REFRIGERATOR D o not use Benzene, Thinner or Clorox™ for cleaning. WARNING They may damage the surface of the appliance and can create a risk of fire. -
Page 14: 14_ Troubleshooting
Troubleshooting pROblEM SOluTION • Check if the power plug is correctly connected. The appliance is not • I s the temperature control on the front panel correctly set? operating at all or the • D oes sun shine on the appliance or are there any heat sources temperature is too high. nearby? • Is the back of the appliance too close to the wall? • I s the temperature control on the front panel set to the coldest The food in the temperature? refrigerator is frozen. • Is the surrounding temperature too low? • C heck if the appliance is installed on a stable and even floor. • Is the back of the appliance too close to the wall? There are unusual • H ave any foreign objects fallen behind or under the appliance? -
Page 15: Circuit Diagram
Circuit diagram... -
Page 16: Ambient Room Temperature Limits
