Free Standing Appliance
DA99-03417A-16.indd 1
DA99-03417A-16.indd 1
Refrigerator

user manual

imagine
the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
RL60 *
RL58 *
RL56 *
English
14. 3. 24.
14. 3. 24.
3:15
3:15

Advertisement

Table of Contents
loading

Related Manuals for Samsung RL60

Summary of Contents for Samsung RL60

  • Page 1: User Manual

    RL58 * RL56 * Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register Free Standing Appliance DA99-03417A-16.indd 1 DA99-03417A-16.indd 1 14. 3. 24.

  • Page 2: Safety Information

    fi nd supervision or instruction help and information online concerning use of the at www.samsung.com. Safety information DA99-03417A-16.indd 2 DA99-03417A-16.indd 2 14. 3. 24. 14. 3. 24.
  • Page 3 Important safety symbols After reading this section, and precautions : keep it in a safe place for future reference. Hazards or unsafe practices that may CE Notice result in severe WARNING This product has been personal injury or determined to be in death.
  • Page 4 as a refrigerant. Check the refrigerant in your particular compressor label on the rear appliance is shown on the of the appliance or the rating identifi cation plate inside the label inside the refrigerator to appliance. see which refrigerant is used - If the appliance contains for your refrigerator.
  • Page 5 appliances. leak. • Do not plug several - This may result in an electric appliances into the same shock or fi re. multiple power board. The refrigerator should • The installation or any always be plugged into its service of this appliance own individual electrical is recommended by a outlet which has a voltage...

  • Page 6: Installation

    hazard. center if any damage is found after removing the • The appliance must be packing materials. positioned so that the plug is accessible after installation. CAUTION SIGNS FOR • The refrigerator must CAUTION INSTALLATION be grounded. - You must ground the •...
  • Page 7 serious personal injury. by the manufacturer. • Do not leave the doors of • Do not use a hair dryer the refrigerator open while to dry the inside of the the refrigerator is unattended refrigerator. Do not place and do not let children enter a lighted candle in the inside the refrigerator.
  • Page 8 Samsung Electronics service center. - There is a risk of fi re. • Do not disassemble or repair the refrigerator by yourself.
  • Page 9 • Do not directly spray Samsung warranty service, water inside or outside nor is Samsung responsible the refrigerator. for safety issues and - There is a risk of fi re or damages that result from electric shock.
  • Page 10 near the refrigerator. Do not SEVERE WARNING CAUTION keep volatile or infl ammable SIGNS FOR objects or substances DISPOSAL (benzene, thinner, propane • Ensure that none of the gas, etc.) in the refrigerator. pipes on the back of - This refrigerator is for storing the appliance are food only.

  • Page 11: Additional Tips For Proper Usage

    • When disposing of - Should the power failure last this product or other more than 24 hours, remove refrigerators, remove the all frozen food. door/door seals, door latch • If keys are provided with the so that small children or refrigerator, the keys should animals cannot become be kept out of the reach of...
  • Page 12 the frozen food up in several - Clean the rear of the layers of newspaper. refrigerator regularly. Dust increases energy • Any increase in temperature consumption. of frozen food during defrosting can shorten its - Do not set temperature storage life. colder than necessary.

  • Page 13: Setting Up Your Refrigerator

    GETTING READY TO INSTALL • Please ensure that appliance can be moved freely in the event of maintenance & service. THE REFRIGERATOR Congratulations on your purchase of the Samsung refrigerator. 100 mm We hope you enjoy the state-of-art offers. Selecting the best location for the...

  • Page 14: Reversing The Door

    Before you reverse the refrigerator door, make sure to unplug the refrigerator. Samsung ② recommends that reversing of the door opening is only completed by Samsung approved Service providers. This will be on a chargeable basis and ① ① at the customers expense.
  • Page 15 6. Disassemble the Middle hinge. 10. Switch the position of Gromet and Cap screws. Be careful not to injure yourself during operation. CAUTION 7. Remove the freezer door from the Bottom 11. Carefully put the freezer door back on. hinge by carefully lifting the door straight up. Assemble the Middle hinge.

  • Page 16: Levelling The Refrigerator

    14. Assemble the Hinge case to the hinge. 17. Switch the handles from the to left the right. (Use left hinge case (additional part) which can be found in freezer top drawer). 330 mm 18 . Detach the Fridge and the Freezer door 15.

  • Page 17: Operating Your Refrigerator

    Operating your refrigerator CHECKING THE CONTROL PANEL Fridge or Freezer temp indicator will blink when temperature in the fridge or freezer compartment goes up dramatically by (TYPE A) (TYPE B) (TYPE C) storing warm food or frequent door opening. (Fridge or Freezer temperature indicator will stop blinking when temperature in the fridge or freezer becomes normal.
  • Page 18 Cool Select Zone Quick Cool( • If you want to cool down food quickly, store food in Cool Select Zone and Select Quick Cool Mode. • Cool Select Zone will cool food for 60 minutes. • When Quick Cool mode is completed, the Cool Select Zone drawer will automatically set the mode to Cool.

  • Page 19: Making Ice

    MAKING ICE Getting water from the dispenser 1. Fill the tray up to 80% with water level. Place a glass underneath the 2. Place the ice tray in the top freezer drawer. water outlet and push it 3. Wait until the ice cubes are formed. gently against the water 4.

  • Page 20: Cleaning The Refrigerator

    Drawers Pull the drawers out fully then slightly lift it up to remove the drawers. ( Fresh Room Drawer, Cool Select Zone Drawer, Freezer Drawers) CLEANING THE REFRIGERATOR Do not use Benzene, Thinner or Clorox™ for cleaning. WARNING They may damage the surface of the appliance and can create a risk of fi...

  • Page 21: Troubleshooting

    Troubleshooting PROBLEM SOLUTION • Check if the power plug is correctly connected. The appliance is not • Is the temperature control on the front panel correctly set? operating at all or the • Does sun shine on the appliance or are there any heat sources temperature is too high.

  • Page 22: Circuit Diagram

    Circuit diagram DA99-03417A-16.indd 22 DA99-03417A-16.indd 22 14. 3. 24. 14. 3. 24. 3:15 3:15...
  • Page 23 memo DA99-03417A-16.indd 23 DA99-03417A-16.indd 23 14. 3. 24. 14. 3. 24. 3:15 3:15...
  • Page 24 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY...
