4.
Align the LEDs on the IBM High IOPS Adapter with the holes in the half-height bracket. Insert the bracket
screw holes in the same manner as the full height bracket was inserted. Refer to the example below that
matches your device configuration.
5.
Attach the half-height bracket using a Philips #1 tip screwdriver to tighten the two screws.
Attention
Do not over-tighten! This can cause damage to the device.
6.
Return
to Step 3 of the installation section to complete the install.
IBM High IOPS Adapter Hardware Installation Guide for ioMemory VSL 3.1.1
______ _
|
_
14
