 Maintain power tools. Check for misalignment or bind-
ing of moving parts, breakage of parts and any other
condition that may affect the power tool's operation. If
damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
 Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
 Use the power tool, accessories and tool bits etc. in ac-
cordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Service
 Have your power tool serviced by a qualified repair per-
son using only identical replacement parts. This will en-
sure that the safety of the power tool is maintained.
Safety Warnings for Drills
 Wear ear protectors when impact drilling. Exposure to
noise can cause hearing loss.
 Use auxiliary handle(s), if supplied with the tool. Loss
of control can cause personal injury.
 Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an
electric shock.
 Application tools can become hot whilst working!
There is a risk of injury when changing the application
tool. Use protective gloves to remove the application tool.
 In order to prevent the power tool from being switched
on unintentionally, always unlock the lock-on button.
To do so, briefly press the On/Off switch.
 Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
 Switch off the power tool immediately when the tool
insert jams. Be prepared for high reaction torque that
can cause kickback. The tool insert jams when:
– the power tool is subject to overload or
– it becomes wedged in the workpiece.
 When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
 Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
 Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
Bosch Power Tools
 Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Products sold in AUS and NZ only: Use a residual current
device (RCD) with a rated residual current of 30 mA or
less.
Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Front sleeve
2 Rear sleeve
3 Keyless chuck
4 "Drilling/Impact Drilling" selector switch
5 Lock-on button for On/Off switch
6 Rotational direction switch
7 On/Off switch
8 Button for depth stop adjustment*
9 Wing bolt for auxiliary handle fastening*
10 Auxiliary handle with depth stop *
11 Depth stop*
12 Handle (insulated gripping surface)
13 Auxiliary handle (insulated gripping surface)*
14 Universal bit holder*
15 Screwdriver bit*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
