Trane ADAPTIVE CONTROL UCM-CLD Installation Operation & Maintenance page 11

Default = ON. Manual override of chilled water
pump off delay
AUTO = activates the "Chilled water pump off
delay"
[MINUTES]
Default = 10 minutes
Select = 1 minute to 30 minutes
The time period that the chilled water pump will
run, once the stop signal is given to the chiller.
Default = 120%
Select = 40% to 120%
Default = Disable
Default = Disable
Default = -6.6°C
Select: -28°C to 16°C
Chilled water pump
"Press (+) (-) to change setting"
Chilled water pump off delay
"Press (+) (-) to change setting"
Front panel current limit setpoint
"Press (+) (-) to change setting"
External current limit setpoint
"Press (+) (-) to change setting"
Low ambient lockout
"Press (+) (-) to change setting
Low ambient lockout
(Operator settings menu)
Enable
Low ambient lockout setpoint
"Press (+) (-) to change setting
11
[ON, AUTO]
Next
[MINUTES]
Next
XXX %
Next
[Disable/Enable]
Next
[Disable/Enable]
Next
Disable
XXX C
Next
