Travis Industries 3615 HO GSR2 Cheat Sheet Quick Start Manual

The 3615 HO GSR2 has several new features and characteristics that require special attention during installation and set-up.
This unit uses the new GreenSmart 2 system. Refer to the owner's manual for full details.
REMOVE THE SCREEN BEFORE YOU REMOVE THE GLASS FRAME
This fireplace uses a newly designed screen barrier. Make sure to remove the barrier prior to removing the glass frame.
1. Remove the concealment cover and place aside. It has two holes that aid in removal.
2. Remove the three screws holding the screen in place (1/4" nutdriver- magnetic driver recommended). Then pivot the
screen down slightly until the clips on the bottom disengage from the glass frame.
This Fireplace Requires Firebacks
96100941 Stainless Steel
96100942 Black Enamel
If using LP (Propane)
A conversion kit is required if using propane with this heater (sku 94400999 – GSR Stepper Motor Kit).
No Drill or Screw Zone
Controls for this fireplace are directly in front. Do not drill or screw into this area (see manual for details).
Battery Box Heat Shield
Travis Industries recently updated the 6015 to include a
heat shield over the top of the battery box. Make sure to
replace this heat shield after installing the batteries. The
heat shield must be in place whenever the fireplace is in
operation.
NOTE: The heat shield is shipped in place. It is held in
place with a lock-tie. Remove and discard this lock-tie to
allow the heat shield to be removed and the batteries
installed.
Page 1 of 2
3615 HO GSR2 Cheat Sheet
96100943 Black Painted
96100944 Ledgestone
Heat Shield
Battery Box
17601837
Lock-Tie
FUSE
FUSE
Printed 10/21/14
