- Page 1 OPERATOR'S MANUAL 3D Sonar Visualizer F3D-S Model (Option for FSV-25/FSV-25S) www.furuno.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS FOREWORD ........................ii SYSTEM CONFIGURATION ..................iii OPERATIONAL OVERVIEW ..................1 1.1 How to Start and Quit the Software ................1 1.2 Display Screen Overview ....................2 1.2.1 3D-View mode......................3 1.2.2 Top-View mode ......................3 1.2.3 Side-View mode .....................4 1.2.4 Vslice-View mode....................4 1.2.5 Other indication ......................5 1.3 Operational Overview ....................5 1.4 How to Change the Viewpoint ..................5... -
Page 4: Foreword
Please carefully read and follow the recommended procedures for operation and maintenance. Features This software, installed in a PC, displays the 3D echo data obtained from the FURUNO model col- or scanning sonar FSV-25/FSV-25S. Hereafter, FSV-25 refers to FSV-25 or FSV-25S. -
Page 5: System Configuration
SYSTEM CONFIGURATION Monitor Processor Unit FSV-2503/2503S LAN cable 12-24 Rectifier RU-1746B-2 (Local supply, program installed in PC) 100/110/115/220/230 VAC, 1ø, 50/60 Hz Control Unit FSV-2501 IF Unit FSV-8502 Hull Unit FSV-253/254 Raise/Lower Control Box FSV-2530 Transceiver Unit 200-220 VAC, FSV-251 3ø, 50/60 Hz Junction Box FSV-2550... -
Page 6: Operational Overview
USB dongle. 5. To quit the software, click the close button (x) at the upper right-hand corner of the screen. All setting information is saved to the folder “C: \ Users \ User name \ Documents \ FURUNO \ F3D-S”. -
Page 7: Display Screen Overview
1. OPERATIONAL OVERVIEW Display Screen Overview When the sonar is available and the F3D-S software is started, a screen, similar to that shown below, appears. There are four view modes; 3D-View, Top-View, Side-View, and Vslice -View. xx xx 33°50.245N 119°44.237W 0.4kn 237°... -
Page 8: View Mode
1. OPERATIONAL OVERVIEW 1.2.1 3D-View mode The 3D-View mode shows a diagonal 3D view of the echoes. You can change the viewpoint. For details, see section 1.4. The 3D-View mode is useful for viewing the entire three-dimensional area around own ship. Heading line Own ship mark North mark... -
Page 9: Side-View Mode
1. OPERATIONAL OVERVIEW 1.2.3 Side-View mode The Side-View mode shows a horizontal view from stern side. This is the default setting. When [Rotate Top-View/Side-View] is turned on, the Side-View mode shows a horizontal view from fore- side of the screen. (See section 3.5.) The Side-View mode is useful for measuring the depth of the fish school. -
Page 10: Other Indication
1. OPERATIONAL OVERVIEW 1.2.5 Other indication The following data are displayed at the top right of the screen. • Sonar settings: Shows the range, gain and user program number. • External data: Shows the data received from external equipment. • Echo volume: Shows the volume calculated from the echo region mark function. Sonar settings External data - R: Range (100 m to... -
Page 11: How To Set The Sonar
Note: When the FSV-25 is in the H mode or the H2 (horizontal combination) mode, the TX (transmission) interval of the FSV-25 is reduced depending on the range setting of the F3D-S. The TX interval does not decrease when V mode is in use. -
Page 12: How To Set The Depth Range Line
1. OPERATIONAL OVERVIEW How to Set the Depth Range Line To set the depth range line on Side-View, click the depth range line for upper or lower limit and then spin the scrollwheel, or drag the depth range line. You can set the depth range line while the depth range line is displayed in cyan color. -
Page 13: Upper User Menu
UPPER USER MENU ™ The upper InstantAccess bar is on the top left side of the screen. Click to show the upper user menu. Click to hide the upper user menu. Upper user menus Icon Name Description Section Show Shows the upper user menu. Hide Hides the upper user menu. -
Page 14: How To Scale Or Move The View
2. UPPER USER MENU How to Scale or Move the View 1. Click to show the upper user menu. 2. Click 3. To scale the view, put the cursor on a view and spin the scrollwheel. To move the view, put the cursor on a view and drag the view. 4. -
Page 15: How To Enter The Event Mark
2. UPPER USER MENU How to delete the echo region mark To delete the echo region mark and the volume, do one of the following: • Click , and then click • Click the echo region mark on the view. How to Enter the Event Mark You can enter the event mark on Top-View. -
Page 16: How To Enter The Purse Net Mark
2. UPPER USER MENU How to Enter the Purse Net Mark You can enter the purse net mark on 3D-View or Top-View. 1. Click to show the upper user menu. 2. Click 3. Click the position on 3D-View or Top-View to enter the purse net mark in cyan color. When moving the cursor to an area other than the purse net mark, the purse net mark color changes to white. -
Page 17: How To Enter The Trawl Mark
2. UPPER USER MENU How to Enter the Trawl Mark You can enter the trawl mark on 3D-View or Top-View. 1. Click to show the upper user menu. 2. Do the following steps on 3D-View referring to the figures. Distance from own ship to the center of trawl door mark Click and then move the cursor to the... - Page 18 2. UPPER USER MENU • Top-View: The horizontal distances from own ship to the center of each trawl door are dis- played in numerical values. Also, the distance between two trawl doors is displayed in nu- merical value. • Side-View: The depth for the center of trawl door is displayed in numerical value (default: 0 •...
- Page 19 2. UPPER USER MENU How to change the horizontal position for trawl mark To change the horizontal position for trawl mark, do one of the following: • When is selected, put the cursor on a trawl door mark and drag the trawl door mark to the desired position.
-
Page 20: Seabed Color
2. UPPER USER MENU Seabed Color The seabed can be displayed in a specified color. You can set the seabed border line on Vslice- View. Seabed Color: OFF Seabed Color: ON 1. Click to show the upper user menu. 2. Click to display the seabed border line on Vslice-View. - Page 21 2. UPPER USER MENU How to reset the seabed border line Click and then click to reset the seabed border line. Seabed border line Seabed depth mark 1 Seabed depth mark 2 How to offset the seabed depth You can offset the seabed depth using the scrollwheel. 1.
-
Page 22: User Program
2. UPPER USER MENU User Program You can save up to 10 shortcut programs for views including the view arrangement. 1. Click to show the upper user menu. 2. Click to open the user program menu. Return icon: Returns to Save icon the upper user menu. -
Page 23: Lower User Menu
LOWER USER MENU ™ The lower InstantAccess bar is on the bottom right side of the screen. Click to show the lower user menu. Click to hide the lower user menu. Lower user menus Icon Name Description Section Show Shows the lower user menu. Hide Hides the lower user menu. -
Page 24: How To Connect/Disconnect The Pc To The Fsv-25
3. LOWER USER MENU 3. Click 4. Click a view setting number icon. The caution message "Are you sure to change registered settings?" appears. 5. Click [Yes]. The following dialog box appears. 6. Enter the comment for the view setting (max. 64 characters) and then click [OK]. The com- ment set here is displayed when the cursor is placed on the appropriate view setting number icon. -
Page 25: How To Start And Stop Data Recording
3. LOWER USER MENU How to Start and Stop Data Recording This software records the echo data of the FSV-25. The size of the echo data depends on the range setting. When the range is set to 1000 m, approximately 13 MB of the echo data can be saved per one transmission. -
Page 26: Advanced Setting
3. LOWER USER MENU Icon Description Opens the [Jump] dialog box. Select the file number and click Click ▲ or ▼ to [Jump] to replay the selected file. select the file number. Opens the interval setting dialog box. Select the re- playing interval between Click ▲... - Page 27 3. LOWER USER MENU 3. Referring to the table below, set each menu item. Menu item Description [View] Check the box for each item you want to view on-screen. [Numeric Data] Check the box for each external data you want to view on-screen. ([HDG]: Heading, [COG]: Course over the ground, [SPD]: Speed, [Lat/Lon]: Latitude and Longitude, [DPTH]: Depth, [Current1 (to 5)]: Tidal current, [TEMP]: Temperature...
-
Page 28: Troubleshooting
TROUBLESHOOTING This section provides simple troubleshooting procedures which the user can follow to restore nor- mal operation. If you cannot restore normal operation, contact your dealer. Problem Possible cause Remedy The message "Sentinel The USB dongle is not in- Check if the USB dongle is firmly inserted. key not found"... -
Page 29: Appendix 1 Error Messages
When an error occurs, an error message appears in the dialog. Click [OK] to delete the dialog. Message Meaning Remedy 000403E8 F3D-S Already Run!! The F3D-S software is al- Restart the F3D-S software ready started up. after five seconds. 00410111 Connection to sonar has... - Page 32 (Elemental Chlorine Free) The paper used in this manual is elemental chlorine free. ・ 機器の修理・使用方法等に関するお問い合わせは、お買い上げの販売店・代理店、最寄りの 当社支店・営業所あてへお願いします。 ・ FURUNO Authorized Distributor/Dealer お問い合わせは 本書の無断複写複製(コピー)は特定の : JUL. 2019 場合を除き、当社権利侵害になります。 Printed in Japan Pub. No. OMC-13442-A ( YOTA) F3D-S(FSV-25) 00019680510...
