Overview
Thank you for purchases CS-2000, the UTM Content Security Gateway. This UTM Content
Security Gateway provides the multiple functions in one unit including VPN, Firewall,
Content Filtering, IDP, Email Anti-Virus and Anti-Spam, etc. Please refer to the following
sections for quick setup of your security gateway. And please also refer to the user's
manual for more details.
This quick installation guide includes the following sections:
1. Package Content
2. Hardware Description: Hardware outlook and panel description
3. DMZ operation mode
4. Quick setup: Quick setup through Web browser


Advertisement

Table of Contents
loading

Related Manuals for Planet Networking & Communication CS-2000

Summary of Contents for Planet Networking & Communication CS-2000

  • Page 1 Overview Thank you for purchases CS-2000, the UTM Content Security Gateway. This UTM Content Security Gateway provides the multiple functions in one unit including VPN, Firewall, Content Filtering, IDP, Email Anti-Virus and Anti-Spam, etc. Please refer to the following sections for quick setup of your security gateway. And please also refer to the user’s manual for more details.

  • Page 2: Package Content

    1. Package Content CS-2000 x 1 User’s Manual CD-ROM x 1 Quick Installation Guide x 1 Power cord x 1 Console cable x 1 Cat5 cable x 3 Cat5 cross cable x 1 Rack-mount ear x 2 Mat x 4 If any of the above items are missing or damaged, please contact your local dealer for support.

  • Page 3: Hardware Description

    Green 100Mbps speed 3. DMZ Operation Mode This section describes the three different operation mode of CS-2000. The CS-2000 DMZ port supports three operation modes, Disable, NAT and Transparent. Disable mode, the DMZ port is not active. Transparent mode, the CS-2000 works as proxy with forward DMZ packet to WAN and forward WAN packet to DMZ.

  • Page 4: Transparent Mode Connection Example

    3.1 Transparent Mode Connection Example WAN1 WAN2 61.11.11.11 61.22.22.22 Transparent Mode to WAN1 CS-2000 192.168.1.1 LAN PC1 LAN PC1 DMZ Server1 DMZ Server2 192.168.1.2 192.168.1.3 61.11.11.12 61.11.11.13 The IP addresses of WAN and DMZ are on the same subnet. This application is suitable if you have a subnet of IP addresses from your ISP and you do not want to change any IP configuration on the subnet.
  • Page 5 3.2 NAT Mode Connecting Example WAN1 WAN2 61.11.11.11 61.22.22.22 CS-2000 NAT Mode 10.0.0.1 192.168.1.1 LAN PC1 LAN PC1 DMZ Server1 DMZ Server2 192.168.1.2 192.168.1.3 10.0.0.2 10.0.0.3 DMZ and WAN IP addresses are on the different subnet (as shown in the figure above).

  • Page 6: Quick Setup

    255.255.255.0. Therefore, the IP address of the Administrator PC must be in the range between 192.168.1.2– 192.168.1.254. By default, the CS-2000 is shipped with its DHCP Server function enabled. This means the client computers on the LAN network including the Administrator PC can set their TCP/IP settings to automatically obtain an IP address from the Content Security Gateway.
  • Page 7 Figure-1 Login Web UI STEP 4: After entering to the main system of CS-2000, select the Interface tab on the left menu. Click on WAN from the sub-function list, and a sub-function list will be displayed. (Figure- Figure-2 WAN 1/2 Interface...
  • Page 8 STEP 5: Select the WAN 1 / 2 port that you want to set. Click Modify button to configure WAN port. Enter the IP address provided from ISP. (Figure-3) Figure-3 WAN Port IP Address and Netmask Setting...
  • Page 9 STEP 6: Click on System function and click on Date/Time function in Configure. Enter the following setting in Date/Time setting: (Figure-4) Select Enable synchronize with an Internet time Server. Set offset hours from GMT: +8 for example Enter the Server IP/Name: 140.100.1.10 for example Enter Update system clock time: 0 for example Click OK.
  • Page 10 STEP 9: When the New Entry option appears, enter the following configuration: (Figure-5) Source Address – select “Inside_Any” Destination Address – select “Outside_Any” Service - select “ANY” Action - select “Permit all” Click on OK to apply the changes. Figure-5 Add New Policy Setting...

  • Page 11: Further Configuration

    Internet immediately. If a Content Security Gateway filter function is required, please refer to the Policy section in the user’s manual. 5. Further Configuration The above steps introduce simple configuration for CS-2000. For further configuration, such as the Anti-Spam, Anti-Virus, IDP, VPN and System Configuration etc., please refer to the user’s manual in the CD.
  • Page 12 This page is intentionally left blank...
  • Page 13 Part NO : 2011-B90110-000...
