Agri-Fab
OWNERS MANUAL
MODEL NO.
45-01772
14 CU. FT. FARM/YARD CART
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
• Safety
• Assembly
• Operation
• Maintenance
• Parts
the fastest way to purchase parts www.speedepart.com
PRINTED IN U.S.A.
FORM NO. 47592 (REV. 7/03)
www.mymowerparts.com
Advertisement
Related Manuals for Agri-Fab 45-01772
Summary of Contents for Agri-Fab 45-01772
- Page 1 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 ¨ Agri-Fab OWNERS MANUAL MODEL NO. 45-01772 14 CU. FT. FARM/YARD CART CAUTION: Read Rules for Safe Operation and Instructions Carefully • Safety • Assembly • Operation • Maintenance • Parts the fastest way to purchase parts www.speedepart.com...
-
Page 2: Rules For Safe Operation
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 ASSEMBLY INSTRUCTIONS RULES FOR SAFE OPERATION Preventing accidents is the responsibility of every TOOLS REQUIRED equipment operator. The following general safety (1) Screw Driver precautions must be fully understood and followed by (1) Pliers every operator. - Page 3 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 3. Turn the front angle assembly and bottom panel 7. Stand the cart on end with the front angle assem- bly down on the floor. Temporarily place the four upside down as shown in figure 3. large 1-1/2"...
- Page 4 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 9. Position a side panel against a side angle, resting it down on top of the front panel. Place a support strap on the outside of the side angle and start a 1/4"...
- Page 5 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 16. Turn the cart upside down. Place the handle tube 17. Insert a 1/4" x 1" screw through the hole at the rear on the bottom of the cart as shown in figure 10. of each side panel and the hole at the rear of each Place the four tube clamps over the handle tube, side angle.
-
Page 6: Maintenance
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 23.Slide the axle through the axle clamps. See figure MAINTENANCE 24. Assemble a cotter pin to the inner hole at one end 1. Grease or oil wheel bearings occasionally. Use of the axle. Place a 1-1/2" flat washer, a wheel and automotive wheel bearing type grease or 20 weight then another 1-1/2"... - Page 7 For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 MODEL 45-01772 14 CU. FT. FARM/YARD CART REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 47590 Bottom Panel 43949 Flat Washer, 25/32" x 1-1/2" x 3/32" 24889 Axle, Wheel 43010 Cotter Pin, 1/8" x 1-1/4" *...
-
Page 8: Repair Parts
For Agri Fab Discount Parts Call 606-678-9623 or 606-561-4983 the fastest way to purchase parts www.speedepart.com REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 © 1999 Agri-Fab, Inc. www.agri-fab.com www.mymowerparts.com...
