- Page 1 OWNERS MANUAL MODEL NO. 45-01763 7 CU. FT. FARM/YARD CART CAUTION: Read Rules for Safe Operation and Instructions Carefully • Safety • Assembly • Operation • Maintenance • Parts PRINTED IN U.S.A. FORM NO. 48325 (11/01)
-
Page 2: Rules For Safe Operation
ASSEMBLY INSTRUCTIONS RULES FOR SAFE OPERATION Preventing accidents is the responsibility of every TOOLS REQUIRED equipment operator. The following general safety (1) Screw Driver precautions must be fully understood and followed by (1) Pliers every operator. (1) 7/16" Wrench 1. Do not at any time carry passengers in this cart. It is designed for carrying materials only and not intended to carry passengers. - Page 3 3. Turn the front angle assembly and bottom panel 7. Stand the cart on its front end with the front angle upside down as shown in figure 3. assembly on the floor. See figure 5. 4. Lay the two side angles on the bottom panel so 8.
- Page 4 10. Place one side panel in position against a side 13. Assemble one 1/4" x 1" screw through bottom hole angle and down on top of the front panel. Start one in side panel and front angle assembly. Secure 1/4" x 1" screw through the center hole in side with a flat washer and hex nut, making only panel and side angle.
- Page 5 15. Lay the cart down on the floor so that the sides are 17. Leave the cart standing to assemble the handle up in a normal position. Remove the front panel by tube in the next step. sliding it up, then remove the four large washers you used for shims.
-
Page 6: Maintenance
MAINTENANCE 20. Assemble a cotter pin to the inside hole at one end of the axle. Place a 1-1/2" flat washer, a wheel and then another 1-1/2" flat washer onto the axle. Secure the wheel with a cotter pin assembled to 1. - Page 7 MODEL 45-01763 7 CU. FT. FARM/YARD CART REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 47585 Front Panel 43010 Cotter Pin, 1/8" x 1-1/4" Lg.* 47586 Side Panel 43949 Flat Washer 25/32" I.D. x 1-1/2" O.D. 47587 Bottom Panel 47584 Truss Head Screws 1/4-20 x 2"...
-
Page 8: Repair Parts
If you do not know the dealer or distributor in your area, please write to the Customer Service Department of AGRI-FAB, Inc. at P.O. BOX 903, SULLIVAN, ILLINOIS 61951. The return of a product or part to AGRI-FAB ®...
