Back Panel - D-Link DWM-312W Quick Installation Manual

DWM-312W

Back Panel

Name
WIFI
WAN/LAN
LAN
Terminal
block
PWR
3 Included antennas are interchangeable.
An SMA connector for the detachable Wi-Fi antenna
A port to connect
An Ethernet port to connect a computer or network device.
Terminal block with DI-1, DI-2, DO, Rx, Tx, GND pins.
Power connector.
Description
to a private Ethernet line.
