Weider 831.150850 User Manual

Weider user's manual weight bench exerciser 831.150850
Hide thumbs Also See for 831.150850:
Table of Contents

Advertisement

Quick Links

Download this manual
PATENT PENDING
Model No. 831.150850
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179
®

Advertisement

Table of Contents
loading

Related Manuals for Weider 831.150850

Summary of Contents for Weider 831.150850

  • Page 1 PATENT PENDING Model No. 831.150850 Serial No. Write the serial number in the space above for reference. Serial Number Decal CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this manual for future reference.

  • Page 2: Table Of Contents

    This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. SEARS, ROEBUCK AND CO., DEPT. 817WA, HOFFMAN ESTATES, IL 60179 WEIDER is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    Important Precautions WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before using the weight bench. 2. Use the weight bench only as described in this manual.

  • Page 4: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is 831.150850. The serial number can be found on a decal attached to the WEI- 145 Weight Bench (see the front cover of this ®...

  • Page 5: Part Identification Chart

    Part Identification Chart This chart is provided to help you identify the small parts used in assembly. Important: Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts bags, check to M10 x 70mm Bolt (26)–5 M8 x 55mm Bolt (25)–2 M8 x 40mm Bolt (27)–8 see if it has been pre-assembled.

  • Page 6: Assembly

    Assembly Before beginning assembly, carefully read the following information and instructions: • Place all parts in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed. • Tighten all parts as you assemble them, unless instructed to do otherwise.
  • Page 7 3. Attach the Frame (2) to the Crossbar (3) with two M8 x 55mm Bolts (25) and two M8 Nylon Locknuts (34). 4. Press a 50mm Square Bushing (31) onto each Upright (1, 15) and tap them in place with a rubber mallet.
  • Page 8 7. Press two 19mm Round Inner Caps (33) into each Short Pad Tube (10). Press two 19mm Round Inner Caps into the Long Pad Tube (23). Insert the Short Pad Tubes (10) into the holes in the Leg Lever (4). Slide two Foam Pads (22) onto each Pad Tube.
  • Page 9 11. Attach the Curl Pad (12) to the Curl Upright (13) with two M6 x 16mm Screws (24). Slide the Curl Upright (13) into the Front Leg (8). Align one of the adjustment holes in the Curl Upright with the adjustment hole in the Front Leg. Tighten the Small Threaded Knob (19) into the adjustment hole in the Front Leg.

  • Page 10: Using The Weight Bench

    Using the Weight Bench The weight bench is designed to be used with your own weight set (not included). The steps below explain how the weight bench can be adjusted. See EXERCISE GUIDELINES on page 11 for important exercise information and refer to the accompanying exercise poster to see the correct form for each exercise.

  • Page 11: Exercise Guidelines

    Exercise Guidelines THE FOUR BASIC TYPES OF WORKOUTS • Muscle Building In order to increase the size and strength of your muscles, you must push your muscles to a high per- centage of their capacity. You must also progressively increase the intensity of your exercise so that your muscles continue to adapt and grow.
  • Page 12 during the return stroke; never hold your breath. Rest for 3 minutes after each set if you are doing a muscle building workout, 1 minute after each set if you are doing a toning workout, and 30 seconds after each set if you are doing a weight loss workout.
  • Page 13 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...

  • Page 14: Part List

    Part List—Model No. 831.150850 Key No. Qty. Description Upright A Frame Crossbar Leg Lever Backrest Tube Backrest Support Tube Front Leg M10 x 130mm Bolt Short Pad Tube Seat Curl Pad Curl Upright Support Plate Upright B Weight Rest M8 Washer 1”...

  • Page 15: Exploded Drawing

    Exploded Drawing—Model No. 831.150850 33 21 R1099B...
  • Page 16 1-800-FON-PART (1-800-366-7278) Part No. 147267 H01516-C R1099B The model number and serial number of your WEIDER listed on a decal attached to the frame. See the front cover of this manual to find the location of the decal. All replacement parts are available for immediate purchase or special order when you visit your nearest SEARS Service Center.
