Summary of Contents for Planet Networking & Communication HDVR-435
- Page 1 H.265 4-/16-ch 5-in-1 Hybrid Digital Video Recorder HDVR-435 HDVR-1635...
- Page 2 Hybrid Digital Video Recorder H.265 HDVR series Copyright Copyright 2019 by PLANET Technology Corp. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.
- Page 3 Hybrid Digital Video Recorder H.265 HDVR series FCC Caution To assure continued compliance, for example, use only shielded interface cables when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 4 Hybrid Digital Video Recorder H.265 HDVR series Revision User’s Manual of PLANET H.265 Hybrid Digital Video Recorder Model: HDVR-435/HDVR-1635 Rev: 1.1 (March 2020) Part No. EM-HDVR-435_1635_v1.1...
-
Page 5: Table Of Contents
Hybrid Digital Video Recorder H.265 HDVR series Table of Contents Chapter 1. Product Introduction ..............8 1.1 Package Contents ................8 1.2 Overview ................... 9 1.3 Features ..................10 1.4 Product Specifications ..............12 Chapter 2. Hardware Interface ..............15 2.1 Physical Descriptions ...............15 2.2 Hardware Installation ...............16 2.2.1 Installing Hard Disk ..............16 Chapter 3. - Page 6 Hybrid Digital Video Recorder H.265 HDVR series 5.5.2 Video Blind ................41 5.5.3 Video Loss ................42 5.5.4 Abnormality ................43 5.6 System Setup ..................44 5.6.1 General ..................44 5.6.2 Encode Setup ................46 5.6.3 GUI Display ................48 5.6.4 PTZ/RS485 Device ..............50 5.6.5 Tour ..................52 5.6.6 Output Adjust .................53 5.6.7 Restore ..................53 5.6.8 RS232 ..................54...
- Page 7 Hybrid Digital Video Recorder H.265 HDVR series Appendix C: Configuring Port Forwarding Manually ........88...
-
Page 8: Chapter 1. Product Introduction
Hybrid Digital Video Recorder H.265 HDVR series Chapter 1. Product Introduction 1.1 Package Contents The package should contain the following items: HDVR Unit x 1 Screw Kit x 1 Power Adapter x 1 Quick Installation Guide x 1 ... -
Page 9: Overview
1.2 Overview Efficient Solution for All Video Formats PLANET HDVR-435 and 1635 are H.265 Hybrid DVR recorders which are able to record video and data from traditional AHD (analog high definition), HD-CVI (high definition composite video interface), HD-TVI (high definition transport video interface) and Network IP security cameras. -
Page 10: Features
Hybrid Digital Video Recorder H.265 HDVR series the need for a separate PC to view video from the unit. Besides, it also can be operated with the USB mouse to configure and monitor all the system easily. Real-time Remote Monitoring Video from the HDVR system can be accessed with Web browsers and mobile devices. - Page 11 Hybrid Digital Video Recorder H.265 HDVR series Video Recording and Backup Simultaneous recording and live video streams Manual or scheduled recording of 4/16 cameras simultaneously Video recycling function 24/7 for easy inquiry of suspicious events Exports recorded video file in H.26X or AVI format to USB device ...
-
Page 12: Product Specifications
Hybrid Digital Video Recorder H.265 HDVR series 1.4 Product Specifications Product HDVR-435 HDVR-1635 Hardware Ethernet 1 x RJ45, 10/100BASE-TX BNC Interface USB Interface 2 x USB 2.0 for backup device and mouse Video VGA/HDMI/video out interface Interface Audio 4 x audio-in, 1 x audio-out... - Page 13 Hybrid Digital Video Recorder H.265 HDVR series Analog cameras & IP Analog cameras & IP cameras: cameras: 12-ch 1080p & 4-ch 1080p, 2-ch 1080p & 2-ch 1080p 8-ch1080p & 8-ch1080p, IP cameras: 4-ch 1080p & 12-ch 1080p ...
- Page 14 Hybrid Digital Video Recorder H.265 HDVR series Disk Error Disk Full Net Loss IP Conflict Camera Events – Motion Detection, Video Blind, Video Loss, Alarm Input, Alarm Output Show Message Buzzer Event Action Send e-mail ...
-
Page 15: Chapter 2. Hardware Interface
Press to enter main menu Return Press to return to previous page Direction & OK Control and Enter Press to select and enter HDVR-435 Rear Panel Connector Description V1‐V4 Composite video signal (CVBS) input interface A1‐A4 The input interface of the audio signal... -
Page 16: Hardware Installation
Hybrid Digital Video Recorder H.265 HDVR series HDVR-1635 Rear Panel Connector Description Composite video signal (CVBS) input interface V1‐V16 A1‐A4 The input interface of the audio signal A-OUT The output interface of the audio signal The network interface of RJ45 HDMI The output interface of the HDMI video signal The output interface of the VGA video signal... - Page 17 Hybrid Digital Video Recorder H.265 HDVR series 2. Plug the HDD power cable and SATA cable into the slots of the PCBA board and the HDD, respectively, making sure the connections are well done. 3. Please align the screw holes on the HDD with those on the HDVR case and secure them with the given screws.
- Page 18 Hybrid Digital Video Recorder H.265 HDVR series 4. After the HDD is secured, it should look like the one in the pictures (front and back) below:...
-
Page 19: Chapter 3. Connecting To The Hdvr
Hybrid Digital Video Recorder H.265 HDVR series Chapter 3. Connecting to the HDVR There are various ways you can connect to the HDVR and below are the suggested methods for different network setups: The HDVR is placed in a network with a DHCP server: Connect to the HDVR by using “HDVR Search Tool”... - Page 20 Hybrid Digital Video Recorder H.265 HDVR series Next, press the “Search” button to find the HDVR. The HDVR should be located and its IP address should be displayed. Select the HDVR and click on “Visit”; the program should automatically access the HDVR’s web administration page from your default browser.
-
Page 21: Accessing Hdvr With Its Default Ip Address
Hybrid Digital Video Recorder H.265 HDVR series 3.2 Accessing HDVR with its default IP address The HDVR comes with a pre-configured static IP address “192.168.0.20”. However, it is only used when there is no DHCP server presented in the network. Connect the HDVR and PC to your switch or hub, or connect the PC directly to the HDVR using a crossover Cat5 Ethernet cable. - Page 22 Hybrid Digital Video Recorder H.265 HDVR series Login page of Web...
-
Page 23: Chapter 4. Basic Operation
Hybrid Digital Video Recorder H.265 HDVR series Chapter 4. Basic Operation This chapter provides setup instructions of the HDVR local display Interface. 4.1 Main/Live Viewing The main/live view is the first interface displayed once you access the HDVR through local display. -
Page 24: Preview
Hybrid Digital Video Recorder H.265 HDVR series 4.2 Preview You can right-click mouse to switch between the windows. The system date, time and channel name are shown in each viewing window. The surveillance video and alarm statuses are shown in each window. Recording status Video loss Motion detection... -
Page 25: Main Menu
Hybrid Digital Video Recorder H.265 HDVR series 4.3.1 Main Menu The system main menu is shown below after login. Picture 4.3 Main Menu 4.3.2 Window Switch Previewing in single window, four windows, eight windows, nine windows or sixteen windows is up to your choice. -
Page 26: Ptz Control
Hybrid Digital Video Recorder H.265 HDVR series 4.3.4 PTZ Control PTZ control is a little different between analog mode and full digital mode. 1) Digital channel – the digital channel needs to link PTZ; the remote device should connect with PTZ with protocol correctly set also. 2) Analog channel –... -
Page 27: Coaxial Control
Hybrid Digital Video Recorder H.265 HDVR series 4.3.5 Coaxial Control Click “Coaxial Control” to enter coaxial control interface. Picture 4.6 Coaxial Control Setup 4.3.6 Preview Signal Click “Preview Signal” to enter preview signal selection interface, and then set 43 to AHD/TVI/CVI signal preview. -
Page 28: Color Setting
Hybrid Digital Video Recorder H.265 HDVR series 4.3.7 Color Setting Color setting is only applied for hybrid /full analog mode and can be configured in analog channel. You can adjust the selective image parameters according to your requirement (current channel for single window display and cursor place for multi-window display). Through desktop shortcut menu, you are able to enter the interface. - Page 29 Hybrid Digital Video Recorder H.265 HDVR series Picture 4.9 Video Playback Function Function Play/Pause Backward play Slow forward Fast forward Previous frame Next frame Previous file Next file Full screen Stop Table 4.10 Playback Control Button Operation tips: Show function of the key that cursor placed. Play frame by frame, the playback status should be paused first.
-
Page 30: Recording
Hybrid Digital Video Recorder H.265 HDVR series 4.3.9 Recording Please check the current channel status; “○” means it is not in the recording status, and “●” means it is in the recording status. You can use desktop shortcut menu or click [main menu]> [recording function]>... -
Page 31: Camera Management
Hybrid Digital Video Recorder H.265 HDVR series In this series of product, the HDVR provides full analog channel mode, hybrid mode and full digital mode in channel type. Different models have different channel modes. User can shift the mode freely if necessary. 4.3.11 Camera Management Picture 4.13 Camera Management... -
Page 32: Chapter 5. Main Menu
Hybrid Digital Video Recorder H.265 HDVR series Chapter 5. Main Menu 5.1 Main Menu Navigation Main Menu Sub Menu Function Set the recording configuration, recording type and Record Config recording time section Set recording search, recording play and video file Playback Config storage... - Page 33 Hybrid Digital Video Recorder H.265 HDVR series Main Menu Sub Menu Function Set system time, data format, language and hard disk in General action when it is full and comes with machine number, configuration video standard, auto logout, etc. Set main (extra) coding parameters: code mode, resolving ability, frame rate, code stream control, image Encode quality type, code stream value, and frame between...
-
Page 34: Recording
Hybrid Digital Video Recorder H.265 HDVR series Main Menu Sub Menu Function Export the device's log or configuration to external Import/Export device (like USB flash disk); input the configuration with external device (like USB flash disk). Camera Search, add, delete IP cameras and display whatever Management devices has been added Display resolution, frame rate and connection status... - Page 35 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.1 Record Configuration Choose the corresponding channel number to set the channel. Channel Choose the all option to set the entire channels. Choose the redundancy function option to implement the file double backup function.
-
Page 36: Playback
Hybrid Digital Video Recorder H.265 HDVR series 5.3 Playback Refer to chapter 4.3.8. 5.4 Backup You can back up the video files to external storage through setup. The storage must be installed before the file backup. If the backup is finished, the video can be displayed individually. - Page 37 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.3 Backup Clear the file information. Remove Search Show the file information satisfying the set file attributes. Configure the backup file format based on requirement. H.26X, Backup Format AVI or MP4 format can be selected. Start Click the start button to start the backup Burning...
-
Page 38: Sensor Function
Hybrid Digital Video Recorder H.265 HDVR series 5.5 Sensor Function Sensor function includes motion detection, video blind, video loss and abnormality. 5.5.1 Motion Detection When system detects the motion signal that reaches the set sensitivity, the motion detection alarm is on and the linkage function is turned on. The details are shown below. Digital channel: It not only enables motion detection function at the local side, but also enables the remote device that is connected. - Page 39 Hybrid Digital Video Recorder H.265 HDVR series Click the set button to enter the set area. The area is divided into PAL 16X12. Red block means the motion is being detected in the defensive area. White block means the unfenced area. Region You can set the area as follows: Drag the mouse and draw the area.
- Page 40 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.6 Set the Time Section PTZ Activation: Set the PTZ activation when the alarm is turned on. In hybrid mode, PTZ links to the related PTZ information of analog channel. While in digital channel model, PTZ links to the related PTZ information on the remote device which is connected.
-
Page 41: Video Blind
Hybrid Digital Video Recorder H.265 HDVR series Picture 5.7 PTZ Activation in Hybrid Mode Show message: Pop-up the dialog box of alarm information on the screen of the local host computer. Send email: It means sending an email to user when the alarm is turned on. Set in the Email function and make a mail testing first. -
Page 42: Video Loss
Hybrid Digital Video Recorder H.265 HDVR series Picture 5.8 Video Blind Set method: Refer to Motion Detection in Chapter 5.5.1. 5.5.3 Video Loss When the equipment cannot obtain the channel video signal, the video loss alarm and the linkage function are turned on. The details are shown below. Digital channel: It not only enables video loss function at the local side, but also enables the remote device that is connected. -
Page 43: Abnormality
Hybrid Digital Video Recorder H.265 HDVR series Picture 5.9 Video Loss Set method: refer to Motion Detection in Chapter 5.5.1. 5.5.4 Abnormality Analyzing and inspecting the current software and hardware of the device. When some abnormal events happen, the device will take an action immediately, such as show message and buzzer. -
Page 44: System Setup
Hybrid Digital Video Recorder H.265 HDVR series Event Type Select abnormality you want to inspect. Enable Select it to make sure abnormal function workable Automatically alarm cue dialog box pops out of the main Show Message screen Buzzer Device will have one long “di” sound while alarm is happening 5.6 System Setup In system setting, the functions contain General, Encode, GUI display, PTZ configure/RS485 device, Tour, Output Adjust, Restore, RS232, and Account. - Page 45 Hybrid Digital Video Recorder H.265 HDVR series Choose list separator of the date format. Date Separator Time Format Choose time format: 24-hour or 12-hour. Language Support multiple languages up to 28. Stop recording: Stop recording when the hard disk is full. HDD Full Overwrite: Cover the earliest recording files and continue recording when the hard disk is full...
-
Page 46: Encode Setup
Hybrid Digital Video Recorder H.265 HDVR series 5.6.2 Encode Setup HDVR provides encode setting in hybrid mode or full analog mode. The encode setting is for analog channel only. Set the video/audio code parameter: video file, remote monitoring and so on. Set every main stream parameter in the left part, and set the extra stream parameter in the right part. - Page 47 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.14 Hybrid/ Analog Encode Setup Channel Choose the channel number. Compression Standard H.264/H.265/H.265+ main profile and extra stream. Resolution Resolution type: 1080P/720P/960H/VGA/D1/CIF. Frame Rate 1 frame/s~25 frame/s You can choose limited code stream (CBR) or variable code stream (VBR).
-
Page 48: Gui Display
Hybrid Digital Video Recorder H.265 HDVR series 5.6.3 GUI Display Configure the video output parameters including the monitor output mode and encode output mode. Monitor output: In the local preview mode, it includes channel title, time display, channel display, record status, alarm status, transparency and region cover information. Encode output: In the network surveillance and video file mode, it includes channel title, time display, channel display, record status, alarm status, transparency and region cover information. - Page 49 Hybrid Digital Video Recorder H.265 HDVR series Click the channel name modify button and enter the channel name menu. The 16 Chinese characters and 25 letters are Channel Title supported. Time Display Display the system data and time in the surveillance window. Display the system channel number in the surveillance Channel Display window.
-
Page 50: Ptz/Rs485 Device
Hybrid Digital Video Recorder H.265 HDVR series 5.6.4 PTZ/RS485 Device When system is in hybrid mode or full analog mode, PTZ device and RS485 device are listed on the PTZ configure page. Picture 5.17 PTZ Configuration Channel Choose input channel of dome camera. Choose the corresponding dome protocol. - Page 51 Hybrid Digital Video Recorder H.265 HDVR series When in full digital mode, only RS485 device is shown below. Picture 5.18 RS485 Device Protocol Choose related protocol of brand model (e.g. Vista) Address Set with corresponding address, default is 1 Choose baud rate that related device uses; default is 9600 Baud Rate Data Bits Include 5-8 options, default is 8...
-
Page 52: Tour
Hybrid Digital Video Recorder H.265 HDVR series 5.6.5 Tour Set the patrol display. The tour mode is enabled when box is checked. You can choose the single-view, four-view or nine-view of single mode tour or hybrid mode tour. Picture 5.19 Tour Configure MD Interval Set the patrol switch interval. -
Page 53: Output Adjust
Hybrid Digital Video Recorder H.265 HDVR series 5.6.6 Output Adjust In hybrid mode, the output adjust function supports black vertical and black horizontal adjustment; in full digital mode, the function does not support the adjustment below. The function allows you to adjust TV output area parameters. You can go to the setup interface via desktop shortcut menu or enter [main menu]>... -
Page 54: Rs232
Hybrid Digital Video Recorder H.265 HDVR series 5.6.8 RS232 Picture 5.22 Serial Port Setting Common serial port is used to debug and update program or set up Function specific serial port. Baud Rate Choose the corresponding baud rate length. Include 5-8 options. Data Bits Stop Bits Include 2 options. -
Page 55: Account
Hybrid Digital Video Recorder H.265 HDVR series 5.6.9 Account Manage the user purview. 1. The character length is 8 bytes at most for the following user and user team name. The blank ahead or behind the character string is invalid. The middle blank in the character string is valid. - Page 56 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.24 Modifying Password Add User: Add a user in the group and set the user purview. Enter the menu interface and input the user name and password. Choose the team and choose whether cover using the user.
- Page 57 Hybrid Digital Video Recorder H.265 HDVR series Add Group: Add a user group and set the purview. There are 33 different purviews: shut down the equipment, real-time surveillance, playback, record setting, video backup, etc. Picture 5.26 Adding Group Delete User: Delete the current user. Choose the user and click the delete user button. Delete Group: Delete the current group.
-
Page 58: Advanced
Hybrid Digital Video Recorder H.265 HDVR series 5.7 Advanced Manage tools menu provides Version, Log, BPS, Online User, Device Info, Upgrade, Auto Maintain and Import/Export functions. 5.7.1 Version Display the basic information such as hardware information, software version, issue date, serial number and NAT status. -
Page 59: Log
Hybrid Digital Video Recorder H.265 HDVR series 5.7.2 Log Log information includes system operation, configuration operation, data management, alarm affair, recording operation, user management, file management, etc. You can set the time section and click the Search button to look for logs. The log information will be displayed as the following list (one page lists 128 items). -
Page 60: Online User
Hybrid Digital Video Recorder H.265 HDVR series 5.7.4 Online User Check the information of network user that is connected with local device. Tick the selected user to break up connection, (make √ at the box), and then the user will be frozen after connection is stopped. -
Page 61: Upgrade
Hybrid Digital Video Recorder H.265 HDVR series 5.7.6 Upgrade Picture 5.33 Upgrade Upgrade: Choose USB interface. Upgrade file: Choose the upgrade file. 5.7.7 Auto Maintain The user can set the time to auto reboot and auto delete file. Picture 5.34 Auto Maintain... -
Page 62: Import/Export
Hybrid Digital Video Recorder H.265 HDVR series 5.7.8 Import/Export Users can export the log info and the configure file from device to connected flash stick, and also can import related configure file from flash stick to settings, which greatly bring convenience to the customers. -
Page 63: Hdd Info
Hybrid Digital Video Recorder H.265 HDVR series Picture 5.36 HDD Manage 5.8.1 HDD Info Display the hard disk state and it lists hard disk type, overall capability, residual capability, the recording time, etc. Picture 5.37 HDD Info Tips: Symbol “○” means that the hard disk is normal; symbol “X” means that the hard disk is broken down;... -
Page 64: Network
Hybrid Digital Video Recorder H.265 HDVR series corresponding disk is damaged, the information will show “？”. 5.9 Network Manage tools menu provides Network, DDNS, UPNP, Email, Cloud and Net Service. 5.9.1 Network Setup Picture 5.38 Network Setup You can choose cable network card or wireless network card. Net Card DHCP Enable Obtain IP address automatically. -
Page 65: Ddns
Hybrid Digital Video Recorder H.265 HDVR series HTTP Port Default: 80. HS Download Network high-speed download There are three strategies: self-adaption, image quality precedence and fluency precedence. The code stream will adjust according to the setup. Self-adaption is the tradeoff between the image quality Transfer Policy precedence and fluency precedence. -
Page 66: Upnp
Hybrid Digital Video Recorder H.265 HDVR series The DNS setup must be configured correctly in the network setup. It is not necessary to input user name and password for Easy DDNS. The system will generate a domain name automatically according to MAC address. 5.9.3 UPNP UPNP protocol is to realize auto port forwarding on router, precondition of using this function is to make sure the UPNP function of router is enabled. -
Page 67: Email
Hybrid Digital Video Recorder H.265 HDVR series 5.9.4 EMAIL If the alarm is turned on or the alarm linkage photos are taken, send an email about the alarm information and the photos to appointed address. Picture 5.41 Email Setup Email server address. It could be an IP address or domain name. -
Page 68: Cloud
Hybrid Digital Video Recorder H.265 HDVR series 5.9.5 Cloud The cloud function is enabled by default. The user is able to scan the iOS or Android QR code to install app viewer (OKview) on mobile. The app viewer can help user to monitor channels of the HDVR remotely. - Page 69 Hybrid Digital Video Recorder H.265 HDVR series When you execute OKview app, you can input the required information as below then press the “save” button to take effect. Picture 5.43 App Setup In GID field, you can double click the QR code icon to start your QR code scanner app.
-
Page 70: Net Service
Hybrid Digital Video Recorder H.265 HDVR series 5.9.6 Net Service The Net Service provides PPPoE, RTSP, IP Filter, FTP, NTP and Dropbox functions. Choose the network service option and click the set button to configure the advanced network functions or double-click the service button to configure the parameters. Picture 5.44 Net Service Setup PPPoE Setup Picture 5.45 PPPoE Setup... - Page 71 Hybrid Digital Video Recorder H.265 HDVR series Operation: The current IP address is displayed after successful dial-up. Use this IP address to visit the HDVR through user port. RTSP Setup The setting is for live view via browsers (Safari, Firefox, and Chrome) and VLC software. This function is only for live view and it cannot control the device.
- Page 72 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.47 IP Filter Setup FTP Setup FTP is available only when alarm happens or alarm activates record and snapshot. It will upload related record and snapshot pictures to FTP server. Picture 5.48 FTP Setup IP address of FTP server Server IP Port...
- Page 73 Hybrid Digital Video Recorder H.265 HDVR series User Name User name of FTP server Password Password of FTP server When anonymous is enabled, setting user name and password Anonymous is not required Max. length for uploaded files at every packed, default value is Max.
- Page 74 Hybrid Digital Video Recorder H.265 HDVR series Dropbox Setup Picture 5.50 Dropbox The procedure follows below: 1. Log in with a Dropbox account to apply for a Drobox space. Go to https://www.dropbox.com/developers/apps and create an app (click on the "Create app" button).
- Page 75 Hybrid Digital Video Recorder H.265 HDVR series Here we create a normal API, the permissions for the directory and the name is SimonTestApp3. Specify the "Create app" button, then enter the following interface: Firstly, click the "Enable additional users" button. Next, click the "OKay" button in the pop-up dialog box, and then click "Show"...
- Page 76 Hybrid Digital Video Recorder H.265 HDVR series https://www.dropbox.com/developers/apps. You can also view them by clicking on the corresponding app. 2. Log in the device with IE, go to the “Net ServiceDropbox” configuration interface, then check Enable, and copy the values of App Key and App Secret in Step 1 to the “Key” and “Secret”...
- Page 77 Hybrid Digital Video Recorder H.265 HDVR series 4. Click “OK” and wait for the result. If the configuration fails, repeat steps 2 and 3 until the configuration is successful.
-
Page 78: Camera
Hybrid Digital Video Recorder H.265 HDVR series 5.10 Camera The camera function includes camera manage, channel status and channel type. There is only analog mode if device is in full analog mode Channel Manage Page in All Analog (DVR) Mode Picture 5.51 Camera Interface Channel Manage Page in Hybrid Mode/Full Digital Mode Picture 5.52 Camera Interface... - Page 79 Hybrid Digital Video Recorder H.265 HDVR series Digital Channel: Picture 5.53 Single Link Page of Digital Channel Channel Select channel title When the digital channel is enabled, user is able to configure Enable related settings for the channel. Time When the function is enabled, the time of channel will be the Synchronization same as the device.
- Page 80 Hybrid Digital Video Recorder H.265 HDVR series Picture 5.54 Remote Channel Configuration Default configuration title of the device. User can modify it if Configure Name necessary. Device Type Default is IPC Default is NETIP Protocol User can input remote channel title from the device that you Remote Channel want to connect remotely Stream...
- Page 81 Hybrid Digital Video Recorder H.265 HDVR series After clicking the Search button, the list will show all the devices in the network. User can choose any device that you prefer. Picture 5.55 Device Searched List Channel Status: Channel status is to show the status of all digital channels which are connected. The status information includes channel, maximum resolution, frame rate and connection status.
- Page 82 Hybrid Digital Video Recorder H.265 HDVR series When a channel is added to device but it is not enabled, you will see as shown below. Picture 5.57 Resolution Status Channel status interface is in full digital mode; the first channel with 5MP resolution is disconnected because of resolution limitation (1080p).
-
Page 83: Logout
Hybrid Digital Video Recorder H.265 HDVR series Channel Type: Picture 5.59 Channel Type In this series of product, the HDVR provides full analog channel mode, hybrid mode and full digital mode in channel type. Different models have different channel modes. User can shift the mode freely if necessary. 5.11 Logout In logout setup interface, it comes with logout, shutdown and reboot functions. -
Page 84: Chapter 6. Web Remote Management
Hybrid Digital Video Recorder H.265 HDVR series Chapter 6. Web Remote Management The HDVR is able to be viewed from Internet Explorer when the network is available. You can have live view, playback and most of the functions that are the same as those of the HDVR system. -
Page 85: Live View On Browser
Hybrid Digital Video Recorder H.265 HDVR series Please login your username and password. When you click “connect all video” button, you will see the “Bit Rate Type” window shown below: You may select bit rate type you would like to view on your computer. The bit rate type can impact bandwidth consumption on IE. -
Page 86: Appendix A: Ping Ip Address
Hybrid Digital Video Recorder H.265 HDVR series Appendix A: Ping IP Address The ping (Packet Internet Groper) command is used to detect whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It’s also a very useful tool to confirm whether or not Internet camera is installed or if the IP address conflicts with any other device over the network. -
Page 87: Appendix B: Planet Ddns Application
Hybrid Digital Video Recorder H.265 HDVR series Appendix B: Planet DDNS Application Configuring PLANET DDNS Steps: Step 1 Visit DDNS provider’s web site and register an account if you do not have one yet. For example, register an account at http://planetddns.com Step 2 Enable DDNS option through accessing web page of the camera. - Page 88 Hybrid Digital Video Recorder H.265 HDVR series Appendix C: Configuring Port Forwarding Manually The device can be used with a router. If the device wants to be accessed from the WAN, its IP address needs to be set up as a fixed IP address. The port forwarding or Virtual Server function of router also needs to be set up.
- Page 89 Hybrid Digital Video Recorder H.265 HDVR series Your WAN IP address will be listed here. 3. Opening/Setting Virtual Server Ports to enable remote image viewing The firewall security feature is built into the router and most routers prevent users from accessing the video from the device over the Internet.
- Page 90 Hybrid Digital Video Recorder H.265 HDVR series Enter valid ports in the Virtual Server section of your router. Please make sure to check the box on this line to enable settings. Then the device can be accessed from WAN by the router’s WAN IP address.
