Vulcan-Hart 1G8BD Series Specifications

Model 1G8BD
SPECIFICATIONS:
85 - 90 lb. capacity free standing gas fryer, Vulcan-Hart Model
No. (1G8BD) Solid State knob controls located behind the door.
200°F to 390°F. Maintains +/- 2° F yields quick recovery. Both
Fahrenheit and Celsius scales. Electronic ignition standard.
Stainless steel Cabinet. Set of four 6" adjustable casters (2
locking). Stainless steel fry tank with four heat exchanger
tubes and a "V" shaped large cold zone. Twin fry baskets with
plastic coated handles. 150,000 BTU/hr. input. Built in flue
deflector. Drain extension and holder mounted on inside of door.
Tank brush, stainless steel crumb scoop and clean-out rod.
Overall dimensions: 21"w x 34
height 36 / ".
1
4
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
Natural Gas
Propane Gas
SPECIFY ALTITUDE WHEN:
Natural Gas for above 2000 ft
Propane Gas for above 3500 ft.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32937 (5-08)
/ "d x 47 / "h. Working
3 1
8 8
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
1G8BD SERIES
FREE STANDING GAS FRYER
1G8BD: Solid state temperature control behind the door.
Knob set temperature from 200° to 390°F. Two melt
cycles. Electronic ignition.
STANDARD FEATURES
Stainless steel fry tank, 85 - 90 lb. capacity.
Solid State knob controls located behind the door. 200°F to
390°F. Maintains +/- 2° F yields quick recovery.
Both Fahrenheit and Celsius scales.
Electronic Ignition.
Two melt modes - liquid and solid.
Stainless steel cabinet.
Large cold zone area.
Set of four 6" adjustable casters (2 locking).
Twin fry baskets with plastic coated handles.
150,000 BTU/hr. input.
Built in flue deflector.
Drain extension and holder mounted on inside of door.
Hi-limit shut-off.
Combination gas shut-off valve.
Tank brush, stainless steel crumb scoop and clean-out rod.
1 year limited parts and labor warranty. 12 year full replace-
ment tank warranty.
ACCESSORIES
FRYMATE VX21S or VX21MS add-on frymate.
Stainless steel tank cover.
Grease protector strips.
1 / " Rear Gas Manifold Pipe with Shutoff Valves to connect
1
4
single fryers in the field - up to four
Single large basket - 18
Set of twin baskets - 8
Set of tri-baskets - 5"w x 16
/ " Flexible gas hose with quick disconnect.
3
4
OPTIONS
Second year extended limited parts and labor warranty.
FILTRATION
Available with our KleenScreen PLUS® filtration system with
multiple fryers and/or Frymate™ dump station..
C.S.I. Section 11420
3 / "w x 17 1 / "d x 6"h.
4 4
/ "w x 16 / "d x 6"h.
3 3
4 4
/ "d x 5 / "h.
13 5
32 16
