- Page 1 Air Compressor Instruction manual www.portercable.com OPERATING INSTRUCTIONS, SERVICE CENTERS AND WARRANTY POLICY. READ THESE INSTRUCTIONS BEFORE USING THE PRODUCT. PXCMF226VW...
-
Page 2: General Safety Rules
GENERAL SAFETY RULES This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. Indicates a potentially Indicates an imminently hazardous situation which, if not... - Page 3 • Restricting any of the com- • Never place objects against pressor ventilation openings or on top of compressor. will cause serious overheat- • Operate compressor in an open ing and could cause fire. area at least 12" (30.5 cm) away from any wall or obstruction that would restrict the flow of fresh air to the ventilation openings.
- Page 4 HAZARD RISk OF BURSTING Air Tank: On February 26, 2002, the U.S. Consumer Product Safety Commission published Release # 02-108 concerning air compressor tank safety: Air compressor receiver tanks do not have an infinite life. Tank life is dependent upon several factors, some of which include operating conditions, ambient condi- tions, proper installations, field modifications, and the level of maintenance.
- Page 5 Tires: • Over inflation of tires could result in • Use a tire pressure gauge to check serious injury and property damage. the tires pressure before each use and while inflating tires; see the tire sidewall for the correct tire pressure. NOTE: Air tanks, compressors and similar equipment used to inflate tires can fill small tires very rapidly.
- Page 6 HAZARD RISk FROM FLYING OBjECTS WHAT CAN HAPPEN HOW TO PREVENT IT • The compressed air stream can • Always wear certified safety cause soft tissue damage to equipment: ANSI Z87.1 eye exposed skin and can propel dirt, protection (CAN/CSA Z94.3) chips, loose particles, and small with side shields when objects at high speed, resulting in using the compressor.
- Page 7 HAZARD RISk OF UNSAFE OPERATION WHAT CAN HAPPEN HOW TO PREVENT IT • Unsafe op e r a t ion of your • Review and understand all compressor could lead to se ri ous instructions and warnings in ju ry or death to you or others. in this manual.
-
Page 8: Specification Chart
ANSI S12.6 may contribute to hearing loss. (S3.19) hearing protection. SAVE THESE INSTRUCTIONS FOR FUTURE USE SPECIFICATION CHART Model No. PxCMF226VW Running Horsepower 1.5 * Bore 2.48" (63.0 mm) Stroke 0.87" (22.0 mm) Voltage... -
Page 9: Duty Cycle
compressor pump. Pump Produces the compressed air with a NPT (National Pipe Thread) reciprocating piston contained within the A seal thread tape must be used to cylinder. provide a leak-free seal on pipe threaded Regulator Pressure Gauge connections. Displays the current line pressure. Line Pressure Regulator knob pressure is adjusted by rotating the Regulates the outgoing pressure from... - Page 10 OVERVIEW Oilless air compressors are factory lubricated for life and do not require any oil. The basic components of the air compressor are the electric motor, pump, pressure switch, and tank. (Figure 1) The electric motor (A) powers the pump. The electric motor is equipped with an overload protector and an automatic reset.
-
Page 11: Assembling The Compressor
ASSEMBLY ASSEMBLING THE COMPRESSOR (Figure 2) Unpack the air compressor. Inspect the unit for damage. If the unit has been damaged in transit, contact the carrier and complete a damage claim. Do this immediately because there are time limitations to damage claims. Check the compressor’s serial label to ensure that you have received the model ordered, and that it has the required pressure rating for its intended use. -
Page 12: Electrical Power Requirements
ELECTRICAL POWER REQUIREMENTS ELECTRICAL WIRING Refer to the air compressor’s serial label for the unit’s voltage and amperage requirements. ExTENSION CORDS NOTE: Avoid use of extension cords. For optimum performance, plug the compressor power cord directly into a grounded wall socket. Do not use an extension cord unless absolutely necessary. Instead, use a longer air hose to reach the area where the air is needed. -
Page 13: Compressor Controls
OPERATING INSTRUCTIONS COMPRESSOR CONTROLS (Figure 4) Pressure Switch (A): This switch turns on the compressor. It is operated manually, but when in the AUTO position, it allows the compressor to start up or shut down automatically, without warning, upon air demand. ALWAYS set this switch to OFF when the compressor is not being used, and before unplugging the compressor. Pressure Relief Valve (B): If the pressure switch does not shut down the motor when pressure reaches the preset level, this valve will pop open automatically to prevent over pressurization. -
Page 14: Daily Startup
DAILY STARTUP (Figure 5) Turn the pressure switch to the OFF position (A). Close the tank drain valve (B). Plug in the power cord (C). High temperatures are generated by the electric motor and the pump. To prevent burns or other injuries, DO NOT touch the compressor while it is running. -
Page 15: Maintenance
MAINTENANCE To avoid personal injury, always shut off and unplug the compressor and relieve all air pressure from the system before performing any service on the air compressor. Regular maintenance will ensure trouble free operation. Your electric powered air compressor represents high quality engineering and construction; however, even high quality machinery requires periodic maintenance. -
Page 16: Troubleshooting
TROUBLESHOOTING Risk of Unsafe Operation. Unit cycles automatically when power is on. When servicing, you may be exposed to voltage sources, com- pressed air, or moving parts. Before servicing unit unplug or disconnect elec- trical supply to the air compressor, bleed tank of pressure, and allow the air compressor to cool. - Page 17 PROBLEM CAUSE CORRECTION Motor will Tank pressure exceeds Motor will start automatically when not run preset pressure switch tank pressure drops below cut- in limit pressure of pressure tank. Make sure the Thermal To reset the motor overload toggle turn Overload Switch has not the pressure switch AUTO/OFF lever tripped.
-
Page 18: Parts Drawing
PARTS DRAWING PUMP/MOTOR ASSEMBLY 18- ENG... - Page 19 PARTS DRAWING PxCMF226VW 19 - ENG...
-
Page 20: Parts List
PARTS LIST REF. NO PART NO. kIT NO. DESCRIPTION Screw, SHCS M6 X 1 X 35mm Washer, Lock M6 E100284 Head, Cylinder 1 & 7 Screw, HFHS M3 X 0.4 X 5mm 1 & 7 Washer, Lock M3 1 & 7 Retainer, Outlet Valve 1 &... -
Page 21: Parts And Service
PARTS LIST REF. NO PART NO. kIT NO. DESCRIPTION Screw, HFH M6 x1.0 x 12MM E100283 Elbow, Exhaust 90 deg. 13mm Male Flr X 1/2in MNPT Motor/Pump Assembly F2D2 (Right Hand Exhaust) Washer, Flat 8mm X 19mm Bolt, SHC M8 x 1.25 x 16MM ( ZDC Plate) Base, Air Filter E100435 Element, Air Filter... -
Page 22: Limited Warranty
This warranty does not apply to accessories or damage caused where repairs have been made or attempted by others. This warranty also does not apply to merchandise sold by PORTER-CABLE which has been manufactured by and identified as the product of another company, such as gasoline engines. - Page 23 The following are PORTER-CABLE trademarks for one or more power tools and accessories: a gray and black color scheme; a F “four point star” design; and three contrasting/outlined longitudinal stripes. Les éléments ci-dessous sont des marques de commerce des outils et des accessoires de PORTERCABLE : un agencement de couleurs grise et noire; un motif d’ « étoile...
