Instructions – Parts List
Husky™ 515/Husky™ 716
Drum Pump Kits and Packages
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
233045
Accessory kit for pump Model No. 241565
233046
Accessory kit for pump Model Nos. 241564,
233305, 243306, 243307
233047
Accessory kit for pump Model No. 241564
233048
Accessory kit for pump Model No. 24B674
233051
Drum pump package including Kit No. 233045
and pump Model No. 241565
233052*
Drum pump package including Kit No. 233047
and pump Model No. 241564
233053*
Drum pump package including Kit No. 233046
and pump Model No. 241564
233054*
Drum pump package including Kit No. 233046
and pump Model No. 243305
233055*
Drum pump package including Kit No. 233046 and pump Model No. 243306
233056*
Drum pump package including Kit No. 233046 and pump Model No. 243307
233057*
Drum pump package including Kit No. 233048 and pump Model No. 24B674
*
II 2 GD
Ex h IIC 66°C...135°C Gb
Ex h IIIC T135°C Db
ATEX T-code rating is dependent on the temperature of the fluid being
pumped. Fluid temperature is limited by the materials of the pump inte-
rior wetted parts. See Technical Data for the maximum fluid operating
temperature for your specific pump model.
309116G
