View menu screens and settings. Press any control button to activate the backlight.
② Infrared (IR) port
Align with the receiver IR port during an IR Sync for automated transmitter tuning and setup.
③ Control buttons
Use to navigate through parameter menus and to change settings.
④ Power switch
Hold the X button to power the unit on or off.
⑤ Enter button
Press to enter menu screens and confirm menu changes.
⑥ Power LED
◦
Green = Unit is powered on
◦
Red = Low battery, or battery error
⑦ Audio LED
Red, yellow, and green LEDs indicate average and peak audio levels.
The LED will turn red when the limiter is engaged.
⑧ USB-C port
Supplies power or charges Shure rechargeable battery. LED indicates charging status when connected to a power supply.
◦
Red = Charging
◦
Green = Full charge
◦
Yellow = Not charging
⑨ Battery compartment
Requires two AA batteries or Shure rechargeable battery.
⑩AA battery adapter
Use to secure AA batteries. Remove when using a Shure rechargeable battery.
⑪ XLR connector
Connection point for wired microphones, cables, and boom poles, among other things.
⑫ Locking ring
To release the XLR connector, turn the ring counterclockwise and push in.
⑬ Pouch
Provides additional grip and protection for the transmitter.
⑭ Belt clip
Shure Incorporated
5/23
