OTHER FUNCTIONS

Using the Surveillance function

When this function is turned ON, the beep is not heard
and the backlight and the Status indicator do not light,
even when a signal is received, or a key is pushed.
1. Assign the function to the [P1] key in the Menu
screen.
[OK] > Functions > Key Setup > P1 Key
2. Hold down [BACK] for 1 second to exit the Menu
screen.
3. Push [Surveillan] to turn the function ON or OFF.
" " is displayed while the function is ON.

Using the AquaQuake function

The AquaQuake water draining function removes
water from the speaker grill by vibrating the internal
speaker.
1. Assign the function to the [P1] key in the Menu
screen.
[OK] > Functions > Key Setup > P1 Key
2. Hold down [BACK] for 1 second to exit the Menu
screen.
3. Hold down [AquaQu...] to use the function.
Water in the speaker grill may muffle the sound
coming from the speaker.
After the specified period of time, the function
automatically stops, even if you continue holding
down the key.
The function works with only the internal speaker.

Using the Last Call Play function

The transceiver can playback the previously received
call.
You can playback up to 6 latest calls.
[OK] > PTT Options > Call Recorder
1. Assign the function to the [P1] key in the Menu
screen.
[OK] > Functions > Key Setup > P1 Key
2. Hold down [BACK] for 1 second to exit the Menu
screen.
3. Push [Last Call] to playback the received call.
Push [Last Call] to change the previously received
call.

Using the RX Speaker function

The transceiver can output received call audio to an
external speaker.
Hold down the [S2] key to turn the RX Speaker
function ON or OFF.
• " " is displayed when the function is ON.
When the transceiver is turned OFF, this function is
also turned OFF.

Using the Public Address function

The Public Address function can output the audio from
the supplied transceiver microphone to an external
device through the D-Sub 25-pin (22 pin: EXAFO).
Push [S3] key to turn the Public Address function
ON or OFF.
• Enters the Public Address function.
Push DIRECTIONAL KEY to change the volume.
When the transceiver turns OFF or received a
message, this function also turns OFF.
Public Address
Last Call
5
50
Scan
