19-Mar-19
fitlet2 DIN-rail bottom mounting
installation instructions
Package content
4x VESA
1x DIN-rail
1x Mounting
mounting
2x Standoffs
bracket
bracket
screws
4x flat head
2x Screw-nuts
Phillips screws
Includes the parts of both fitlet2 kits
required for DIN-rail bottom mounting:
1. fitlet2 mounting bracket
2. DIN-rail mounting bracket
Page 1
Advertisement
Related Manuals for CompuLab fitlet2
Summary of Contents for CompuLab fitlet2
- Page 1 19-Mar-19 fitlet2 DIN-rail bottom mounting installation instructions Package content 4x VESA 1x DIN-rail 1x Mounting mounting 2x Standoffs bracket bracket screws 4x flat head 2x Screw-nuts Phillips screws Includes the parts of both fitlet2 kits required for DIN-rail bottom mounting: 1. fitlet2 mounting bracket ...
- Page 2 Fasten both standoffs to the back of the DIN-rail's designated holes using the screw-nuts. The DIN-rail bracket can be installed to the mounting bracket at both horizontal and vertical orientations. Use 2x flat head Phillips screws and fasten through the designated holes (marked in RED) to the DIN-rail bracket's standoffs.
