MSI PRO Series User Manual
Hide thumbs Also See for PRO Series:

Advertisement

PRO Series
LCD Monitor
PRO MP241 (3BA9)

Advertisement

Table of Contents
loading

Summary of Contents for MSI PRO Series

  • Page 1 PRO Series LCD Monitor PRO MP241 (3BA9)
  • Page 2: Table Of Contents

    CONTENTS Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Technical Support ���������������������������������������������������������������������������������������������������iii Safety Instructions ���������������������������������������������������������������������������������������������������iv CE Conformity ���������������������������������������������������������������������������������������������������������vi FCC-B Radio Frequency Interference Statement ���������������������������������������������������vi WEEE Statement ���������������������������������������������������������������������������������������������������vii Chemical Substances Information �������������������������������������������������������������������������vii RoHS Statement ����������������������������������������������������������������������������������������������������vii 1. Getting Started ................1-1 Package Contents ������������������������������������������������������������������������������������������������ 1-2 Installing the Monitor Stand ����������������������������������������������������������������������������������...
  • Page 3: Copyright And Trademarks Notice

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�...
  • Page 4: Safety Instructions

    Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the device or user’s manual should be noted� ◙ Refer servicing to qualified personnel only. Keep the User’s Guide that comes with the package for future reference� To prevent fire or shock hazard, keep this device away from humidity and high temperature�...
  • Page 5 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
  • Page 6: Ce Conformity

    1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
  • Page 7: Weee Statement

    Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
  • Page 9: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT The illustrations are for reference only� Your monitor may vary in appearance�...
  • Page 10: Package Contents

    Package Contents 1� Monitor 2� Stand 3� Base 4� Power Adapter & Power Cord 5� HDMI Cable (Optional) 6� D-Sub VGA Cable (Optional) 7� Quick Start Guide 8� Warranty Card * Contact your place of purchase or local distributor if any of the items is damaged or missing�...
  • Page 11: Installing The Monitor Stand

    Getting Started Installing the Monitor Stand IMPORTANT Place the monitor on a soft, protected surface to avoid scratching the display panel� 1� Align the stand to the base� Push the stand towards the base until it locks in place� 2� Leave the monitor in its protective foam packaging� Align the stand assembly to the monitor groove�...
  • Page 12: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities� IMPORTANT Avoid touching the display panel when adjusting the monitor�...
  • Page 13: Monitor Overview

    Getting Started Monitor Overview HDMI Port D-Sub VGA Port DC Power Jack OSD Keys Power LED Kensington Lock...
  • Page 14: Connecting The Monitor To Pc

    Connecting the Monitor to PC 1� Turn off your computer. 2� Connect the video cable from the monitor to your computer� 3� Assemble the monitor power adapter & power cord� (Figure A) 4� Connect the power adapter to the monitor power jack� (Figure B) 5�...
  • Page 15: Osd Setup

    OSD Setup This chapter provides you with essential information on OSD Setup� IMPORTANT All information is subject to change without prior notice�...
  • Page 16: Osd Keys

    OSD Keys The monitor comes with a set of OSD Keys that help to control the On-Screen Display (OSD) menu� OSD Key Hotkey Basic Operations (When OSD menu is OFF) (When OSD menu is ON) Activating the OSD Main Menu ■...
  • Page 17: Osd Setup Menus

    OSD Setup OSD Setup Menus Press the M key to launch the On-Screen Display (OSD) main menu and use the OSD keys to tune the desired function to suit your personal preferences� 1st Level Menu 2nd/3rd Level Menu Description Brightness Adjusting display brightness Contrast Adjusting display contrast...
  • Page 18 1st Level Menu 2nd/3rd Level Menu Description Adjust Auto adjust Auto adjusting the horizontal/vertical position, clock and focus of pictures Auto color Adjusting the white balance of pictures Gamma Gamma 1 Adjusting color tone brightness gray 1 Gamma 2 Adjusting color tone brightness gray 2 Return Returning to the previous menu Exit...
  • Page 19: Appendix

    Appendix IMPORTANT All information is subject to change without prior notice�...
  • Page 20: Specifications

    Specifications Model PRO MP241 (3BA9) Size 23�8 inch Panel Type Resolution 1920 x 1080 (FHD) Aspect Ratio 16:9 Brightness (nits) 220 cd/m2 (TYP) Contrast Ratio 1000:1 Refresh Rate 60Hz Response Time 7ms (GTG) Input Interface ■ HDMI Port x1 ■ D-Sub VGA Port x1 View Angles 178°(H) , 178°(V) DCI-P3/ sRGB *...
  • Page 21: Preset Display Modes

    Appendix Preset Display Modes Standard Resolution HDMI 640x480 @60Hz @72Hz @75Hz Dos-Mode 720x400 @70Hz SVGA 800x600 @56Hz @60Hz @72Hz @75Hz 1024x768 @60Hz @70Hz @75Hz SXGA 1280x1024 @60Hz @75Hz WXGA+ 1440×900 @60Hz WSXGA+ 1680x1050 @60Hz Full HD 1920x1080 @60Hz Video 480P 640x480P @60Hz Timing...
  • Page 22: Troubleshooting

    Troubleshooting The power LED is off. ■ Press the monitor power button again� ■ Check if the monitor power cable is properly connected� No image. ■ Check if the computer graphics card is properly installed� ■ Check if the computer and monitor are connected to electrical outlets and are turned on�...
