ADJUSTING ICE CUBE SIZE

On models equipped with an ice maker, the cube size may be adjusted
by changing the amount of water injected into the ice maker assembly.
1. Remove the ice maker assembly cover (see Figure 39).
2. Locate the adjusting screw on the ice maker assembly control box.
The adjusting screw is just below the minus (–) and plus (+) signs
on the control box (see Figure 40).
Figure 39
3. Turn the adjusting screw toward the minus (–) sign (clockwise) for
smaller cubes or toward the plus (+) sign (counterclockwise) for
larger cubes.
4. Install the ice maker assembly cover.
Some units are not frost free and must be defrosted periodically. Refer
to CARE AND CLEANING.
Use only genuine U-Line replacement parts. U-Line ice
maker parts are not the same as standard FSP Whirlpool
parts. Using non U-Line parts can reduce ice rate, cause
water to overflow from ice maker mold, damage the unit,
and may void the warranty.
UL133
CAUTION
27
– +
Figure 40
UL122
