CONNECTING THE WATER SUPPLY

1. Install the 1/4 inch copper
water line from the main
water source. On ice maker
models BI-95 and BI-98, the
water line
through the hole in the rear
of the unit to connect to the
solenoid valve in the front
(see Figure 3).
Figure 3
2. Locate the compression fit-
ting and ferrule packed in the
unit. Slide the compression
fitting and ferrule over the
1/4 inch water supply line.
Do not use thread sealing
compound or tape. Using
two wrenches, tighten the
compression fitting on the
supply line (see Figure 4).
Figure 4
is inserted
POWER
CORD
WATER LINE
UL101
UL134
3. Carefully bend the water sup-
ply line into position and con-
nect the line to the solenoid
valve (see Figures 5 and 6).
Avoid kinking the water sup-
ply line.
CONNECTION
Figure 5
Figure 6
7
WATER
WATER LINE
UL103
UL104
