- Page 1 G9000 SERIES MMS KIT INSTALLATION MANUAL 480/480 V 80/100/160/225 kVA Document No: 94466-000 Document Ref: 4GDH0010 Rev.B March 2020...
- Page 3 UNINTERRUPTIBLE POWER SYSTEM If additional information or technical assistance is required call TOSHIBA Customer Support Center at 877-867-8773, or write to: Toshiba International Corporation, 13131 West Little York Road, Houston, TX 77041-9990 Attn: UPS Product Manager.
- Page 4 TOSHIBA shall not be liable for technical or editorial omissions or mistakes in this manual. Nor shall it be liable for incidental or consequential damages resulting from the use of information contained in this manual.
-
Page 5: Table Of Contents
Table of Contents Table of Contents ..................................iii List of Tables ................................... iii List of Figures ..................................iii How to use this Manual ..............................1 Notice Icons ................................. 1 Qualified Personnel ............................. 2 OVERVIEW ..................................3 MMS KIT parts list ................................4 MMS parts Location ................................ - Page 6 This Page Left Intentionally Blank G9000 80-225kVA MMS KIT Installation Manual - 94466-000...
-
Page 7: How To Use This Manual
Prohibit: A prohibit symbol shows the act the user or the service personnel should NEVER perform during the UPS installation, operation or service work. PROHIBIT Safety Recommendations: If any problems are encountered while following this manual, contact the Toshiba Customer Support Center. G9000 80-225kVA MMS KIT Installation Manual - 94466-000... -
Page 8: Qualified Personnel
Qualified Personnel Only qualified persons are to install, operate or service this equipment according to all applicable codes and established safety practices. A qualified person must: Read this entire instruction manual carefully. Be skilled in the installation, construction or operation of the equipment and aware of the hazards involved. Be trained and authorized to safely energize, de-energize, clear, ground, lockout and tag circuits in accordance with established safety practices Be trained and authorized to perform the service, maintenance or repair of this equipment... -
Page 9: Overview
OVERVIEW TOSHIBA G9000 Uninterruptible Power Supply Systems (UPS) need an MMS KIT whenever two or more UPSs are installed in parallel operation configuration. Each UPS requires an MMS KIT installed to allow it to complete the communication circuit with other modules. -
Page 10: Mms Kit Parts List
MMS KIT parts list Table 1 Parts list of MMS KIT Parts No. Part name Remarks IF1 PCB: Parallel Interface PCB (IFAU-08*) PC1 PCB: Parallel Control PCB (TLCR-C*) Mounting Metallic Plate for IFAU-08* Flat Cable (TLCR-C* – UPGR-M*) Wire (GNDC – FG) Cable Clamp For IFAU-08*: 6 Supports... -
Page 11: Mms Parts Location
MMS parts Location Figure 3 MMS parts Location (160kVA, 225kVA) 1) IF1 PCB: 6) Cable Clamp (IFAU-08*) 5) Wire 3) Mounting Metallic Plate UPGR 4) Flat Cable 2) PC1 PCB: (TLCR-C*) G9000 80-225kVA MMS KIT Installation Manual - 94466-000... -
Page 12: Figure 4 Mms Parts Location (80Kva, 100Kva)
Figure 4 MMS parts Location (80kVA, 100kVA) 6) Cable Clamp 1) IF1 PCB: (IFAU-08*) 5) Wire 3) Mounting Metallic Plate UPGR 4) Flat Cable 2) PC1 PCB: (TLCR-C*) G9000 80-225kVA MMS KIT Installation Manual - 94466-000... -
Page 13: Installation Procedure
Prior to the installation of the parts, confirm that the AC input breaker, AC output breaker, Installation procedure Bypass input breaker and DC breaker are turned off. (De-energize the interior of the UPS.) Then remove the metal cover plates from UPS. CAUTION Parallel Interface Board (IFAU-08*) Figure 5 Parallel Interface Board (IFAU-08*) Installation... -
Page 14: Parallel Control Board (Tlcr-C*)
Parallel Control Board (TLCR-C*) Figure 6 Parallel Control Board (TLCR-C*) Installation metal plate metal plate Step 1 Step 3 UPGR-M* UPGR-M* UPGR-M* CN91 CN91 TLCR-C* Supports CN93 CN92 From IFAU-08* metal plate Step 2 Step 1 :Screw the supports with spring and flat washer to the metal UPGR-M* plate. -
Page 15: Dip Switch Setting On Parallel Interface Board (Ifau-08*)
Dip switch setting on Parallel Interface Board (IFAU-08*) Setup Dip switches according to Table 2. Figure 7 Dip switch location on Parallel Interface Board (IFAU-08*) Dip Switch IFAU-08* Example: In Table 2, 3xMMS No. 1 UPS switches are all ON, and the No. 2 UPS switches are all OFF. Table 2 Dip switch setting System No.1 UPS... - Page 16 This Page Left Intentionally Blank G9000 80-225kVA MMS KIT Installation Manual - 94466-000...
- Page 18 SOCIAL INFRASTRUCTURE SYSTEMS GROUP POWER ELECTRONICS DIVISION 13131 West Little York Rd., Houston, TX 77041 Tel: 855-803-7087 Fax 713-896-5212 US 800/231-1412 Canada 800/872-2192 Mexico 01/800/527-1204 www.toshibaups.com Printed in Japan...
