- Page 1 UNINTERRUPTIBLE POWER SYSTEM (UPS) G9000 SERIES Slim Maintenance Bypass INSTALLATION AND OPERATION MANUAL Part # 96011-000 October 2016 Manufactured in the USA © Copyright 2016 TOSHIBA International Corporation All rights reserved.
- Page 2 G9000 Slim MBS Installation and Operation Manual – 96011-000...
- Page 3 UNINTERRUPTIBLE POWER SYSTEM (UPS) G9000 Series Slim Maintenance Bypass INSTALLATION AND OPERATION MANUAL Part # 96011-000 October 2016 G9000 Slim MBS Installation and Operation Manual – 96011-000...
- Page 4 Product Use and Warranty Restrictions The Toshiba products listed in this document are intended for usage in general electronics applications (computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These Toshiba products are neither intended nor warranted for usage in equipment that requires extraordinarily high quality and/or reliability or where a malfunction or failure may cause loss of human life or bodily injury (Unintended Usage).
- Page 5 Unless otherwise specified, the warranty period for the UPS or UPS part is 36 months from the shipment date (see Toshiba International Corporation bill of lading). Unless otherwise specified, the warranty period for a UPS battery is 24 months from the shipment date (see Toshiba International Corporation bill of lading).
- Page 6 Toshiba International Corporation reserves the right, without prior notice, to update information, make product changes, or discontinue any product or service identified in this publication. Toshiba is a registered trademark of the Toshiba Corporation. All other product or trade references appearing in this manual are registered trademarks of their respective owners.
-
Page 7: Table Of Contents
Contents Introduction ....................1 1.1 System Compatibility .................1 General Safety Instructions ..............2 Symbols ..................2 Signal Words .................3 Qualified Personnel ...............3 Factory Authorized Personnel............4 Important Safety Instructions ..............4 Maximum Operating Temperatures ..........4 Safety Precautions ..................5 Disclaimer ..................5 General Maintenance ..............5 Transporting ...................6 Storage/Operating Environment ..............7 Inspection/Storage .................7 Storage Environment ..............7... - Page 8 This Page Left Blank Intentionally G9000 Slim MBS Installation and Operation Manual – 96011-000...
-
Page 9: Introduction
• Safety Precautions • Installation Precautions Please read the G9000 Series UPS Installation and Operation Manual in addition to this manual for important instructions on installing and operating the Maintenancy Bypass Cabinet in accompaniment with the UPS. This manual and the accompanying drawings should be considered a permanent part of the equipment and should be readily available for reference and review. -
Page 10: General Safety Instructions
General Safety Instructions DO NOT attempt to transport, install, operate, maintain or dispose of this equipment until you have read and understood all of the product safety information provided in this manual. Symbols The symbols listed below are used throughout this manual. When symbols are used in this manual they will include important safety information that must be carefully followed. -
Page 11: Signal Words
Signal Words The signal words listed below are used throughout this manual. When the words DANGER, WARNING, CAUTION and ATTENTION are used in this manual they will include important safety information that must be carefully followed. The word DANGER in capital letters preceded by DANGER the safety alert symbol indicates that an imminently hazardous situation exists, and if not avoided... -
Page 12: Factory Authorized Personnel
Factory Authorized Personnel Factory authorized personnel have been factory trained and certified to install, service, and repair the UPS. Contact the Toshiba Customer Support Center for assistance in locating the factory authorized personnel nearest you. Important Safety Instructions The following contains important instructions that should be followed during the installation, operation, and maintenance of the G9000 Series Maintenance Bypass Cabinet. -
Page 13: Safety Precautions
(computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These Toshiba products are neither intended nor warranted for use in equipment that, if a malfunction or failure occurs, may result in loss of human life or bodily injury (collectively referred to as “Unintended Usage”). -
Page 14: Transporting
Transporting WARNING DO NOT tilt the Maintenance Bypass Cabinet more than 10° from upright position. Tilting more than 10° may cause crushing, trapping or other personal injuries. CAUTION DO NOT transport, move, store, or place the Maintenance Bypass Cabinet on its sides. Excessive force applied from heavy components inside may damage the Maintenance Bypass Cabinet. -
Page 15: Storage/Operating Environment
Storage/Operating Environment Inspection/Storage Inspection Upon receipt of the Slim MBS, an inspection for shipping damage should be performed. Use caution when removing the unit from the pallet. Refer to labels or documentation attached to packing material. Unpacking Check the unit for loose, broken, bent or otherwise damaged parts. If damage has occurred during shipping, keep all original crating and packing materials for return to the shipping agent. -
Page 16: Operating Precautions
6) DO NOT attempt to disassemble, modify, or repair the Slim MBS cabinet. Call your Toshiba sales representative for repair information. 7) Turn the power on only after installing ALL of the covers. 8) DO NOT remove any covers of the Slim MBS cabinet when power is on. -
Page 17: Maintenance Precautions
UPS output and the load input. 3) The maximum ambient operating temperature is 104 °F (40 °C) for the G9000 Slim MBS. 4) Only factory authorized personnel should service the UPS. Contact Toshiba for the nearest authorized service center. 5) Battery servicing should be performed by factory authorized personnel only. -
Page 18: Unpacking
• Packing materials should be disposed by the appropriate means. • Immediately report any abnormalities to Toshiba Customer Support Center or an authorized representative. • Retain the packing rails, if included, for offloading the Slim MBS Cabinet from the shipping pallet. -
Page 19: Transporting By Forklift
Transporting By Forklift Verify forklift maximum load capacity and ensure that the forks are long enough to properly support the UPS. Insert the forks into the space shown in Figure 6.1. Spaces for the forks are provided underneath the maintenance bypass cabinet. DO NOT tilt MBS when lifting and/or transporting. -
Page 20: Installation
Electrical shock, injury or Slim MBS Cabinet failure may occur if non- authorized technicians attempt to modify or relocate the Slim MBS Cabinet. Please contact Toshiba Customer Support Center if you plan to move or make modifications to the Slim MBS Cabinet WARNING METAL CONDUIT IS NOT AN ACCEPTABLE GROUND. -
Page 21: Slim Mbs Cabinet Clearance
0 in (0 mm) 0 in (0 mm) FIGURE 7.1 CLEARANCE FOR SLIM MBS CABINET 7.3 Wiring Between UPS & MBS G9000 Series NEUTRAL N N N N 24V DC PCB 1 2 3 4 5 6 7 8 CNEPO-2... -
Page 22: Mbs Component Layout
MBS Component Layout FIGURE 8.1 – FRONT AND INNER COMPONENT LAYOUTS Part Number Part Description Part Number Part Description Control Transformer TB-1 UPS Connection Utility Connection Load Connection G9000 Slim MBS Installation and Operation Manual – 96011-000... -
Page 23: Mbs Operation
MBS Operation Begin this procedure only with the system in the normal operating mode (UPS On-Line) Touch the “Start/Stop” button on the MAIN screen on the UPS Cabinet. Touch and Hold the “Stop” button until it beeps (this will transfer the UPS to static bypass.) If SKRU in MBS is equipped with a light, it should now be illuminated, and the key can be removed. -
Page 24: Mbs One-Line Drawing
MBS One-line Drawing G9000 Slim MBS Installation and Operation Manual – 96011-000... - Page 25 INFRASTRUCTURE SYSTEMS & SOLUTIONS COMPANY POWER ELECTRONICS DIVISION 13131 West Little York Road, Houston, Texas 77041 Tel (713) 466-0277 Fax. (713) 466-8773 US (800) 231-1412 Canada (800) 872-2192 Mexico 01-800-527-1204 www.toshiba.com/tic/industrial/uninterruptible-power-systems Printed in the U.S.A.
