Connecting - Bench saw Position
1. Connect one hose to the small diameter outlet and one to the large diameter using the
corresponding spouts.
2. Blank off the middle opening of the 3-way connector.
3. Connect both hoses to the outer outlets.
Mitre Saw Extra Support/Length Stop (Fig. C)
The extra support and length stop can be mounted on the left-hand side or on the right-hand
side, or with two sets on either side.
1. Fit items 30 – 34 onto the two guide rails
33
2. Use the inclinable support for cross-cutting 210 mm wide boards (15 mm thick).
Side Extension Table (Fig. D)
35
The side extension table increases the distance from the rip fence to the blade to 600 mm
or more, depending on the rod length fitted to the machine and the clamped position of the
table. The side extension table must be used in conjunction with guide rails
The adjustable table is equipped with an engraved scale along its front edge and mounted on
a sturdy base which clamps to the guide rods.
• Fit the extension table to the right-hand side of the machine for continuity of the distance
scale on both tables.
Transporting

WARNING: Always transport the machine in bench saw mode with the upper blade
guard fitted.
• Remove the legs.

WARNING: When carrying the machine, always use the hand indentations (Fig.A;
and seek for assistance. The machine could be too wide protruding for one person
to handle.

MAINTENANCE

Your D WALT power tool has been designed to operate over a long period of time with a
e
minimum of maintenance. Continuous satisfactory operation depends upon proper tool care
and regular cleaning.

WARNING: To reduce the risk of injury, turn unit off and disconnect machine
from power source before installing and removing accessories, before adjusting
or changing set-ups or when making repairs. Be sure the trigger switch is in the OFF
position. An accidental start-up can cause injury.
Lubrication
The bearings of the motor are pre-lubricated and watertight.
• Slightly oil the rotating table bearing surface where it slides on the lip of the fixed table at
regular intervals.
• Clean the parts subject to accumulation of sawdust and chips periodically with a
dry brush.
Cleaning

WARNING: Blow dirt and dust out of the main housing with dry air as often as dirt is seen
collecting in and around the air vents. Wear approved eye protection and approved dust
mask when performing this procedure.

WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic
parts of the tool. These chemicals may weaken the materials used in these parts. Use a
cloth dampened only with water and mild soap. Never let any liquid get inside the tool;
never immerse any part of the tool into a liquid.

WARNING: To reduce the risk of injury, regularly clean the table top.

WARNING: To reduce the risk of injury, regularly clean the dust collection system.
Before use, carefully check the upper blade guard, movable lower blade guard as well as
the dust extraction tube to determine that it will operate properly. Ensure that chips, dust or
workpiece particle cannot lead to blockage of one of the functions.
In case of workpiece fragments jammed between saw blade and guards disconnect the
machine from the power supply and follow the instructions given in section Mounting the
Saw Blade. Remove the jammed parts and reassembling the saw blade.
Optional Accessories

WARNING: Since accessories, other than those offered by D
with this product, use of such accessories with this tool could be hazardous. To reduce the
risk of injury, only D WALT recommended accessories should be used with this product.
e
Saw Blades
ALWAYS USE noise reduced 250 mm SAW BLADES WITH 30 mm ARBOR HOLES. SPEED RATING
MUST BE AT LEAST 3000 RPM. Never use a smaller or greater diameter blade. It will not be
guarded properly. Use cross cut blades only. Do not use blades designed for fast ripping,
combination blades or blades with hook angles in excess of 10°.
31 .
31 (option).
15
WALT, have not been tested
e
BLADE DESCRIPTIONS
APPLICATION
Construction saw Blades (thin kerf with anti-stick rim)
General Purpose
Woodworking saw Blades (provide smooth, clean cuts)
Fine crosscuts
Consult your dealer for further information on the appropriate accessories.
Protecting the Environment
Separate collection. Products and batteries marked with this symbol must not be
disposed of with normal household waste.
Products and batteries contain materials that can be recovered or recycled reducing
the demand for raw materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at www.2helpU.com.
)
English
DIAMETER TEETH
250 mm 30 (Series 60)
250 mm 60 (Series 60)
