INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
4300 WOOD APPLIANCE SERIES
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBERS:
43M-ACC-C
43ST-ACC-C
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
R
7037-802A
WARNING
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified.
•
Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
•
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre
revendeur ou visitez
www.quadrafire.com
February 17, 2020
Advertisement
Table of Contents
Related Manuals for Quadra-Fire 4300 Series
Summary of Contents for Quadra-Fire 4300 Series
- Page 1 Owner’s Manual Operation & Care INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not followed exactly, a fire could result causing property damage, personal injury,...
-
Page 2: Sample Of Serial Number / Safety Label
Welcome to the Quadra-Fire Family NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Back of appliance CAUTION HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE. -
Page 3: Table Of Contents
K. Negative Pressure......L. Frequently Asked Questions ....Quadra-Fire is a registered trademark of Hearth & Home Technologies. February 17, 2020... -
Page 4: Warranty Policy
B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: WARRANTY PERIOD: distributor, whichever occurs earlier. - Page 5 WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. •...
-
Page 6: Quick Start Guide
C. Quick Start Guide NOTE: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry ITEMS NEEDED FOR FIRST FIRE: Kindling and Few Pieces of Dry Split Wood. OPEN AIR CONTROLS LOAD WOOD ADD NEWSPAPER... -
Page 7: Listing And Code Approvals
Listing and Code Approvals A. Appliance Safety Certification C. BTU & Efficiency Specifications Model: 43M-ACC-C & 43ST-ACC-C EPA Certification Number: N/A Number: Laboratory: OMNI Test Laboratories, Inc. EPA Certified Report Number: 0061WS067S 1.6 grams per hour Emissions: Type: Listed Room Heater, Solid Fuel Type *LHV Tested Efficiency: 80.2% UL1482-11 (R2015), ULC S627-00 **HHV Tested Efficiency: 74.2%... -
Page 8: Glass Specifications
D. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. Fire Risk. Hearth & Home Technologies disclaims any responsibility for, and the warranty will be E. -
Page 9: Operating Instructions
Much of the blame for poor air quality Chimney fire has been placed on the burning of wood for home heating. In order to improve the situation, we at Quadra-Fire 2. What To Do if Your Appliance is Over-Firing have developed cleaner-burning wood appliances that... -
Page 10: Air Controls
2. Second Stage D. Air Controls The next stage of burning, the secondary stage, is the Users will need to find their preferred setting between period when the wood gives off flammable gases which high and low based on desired heat output, installation burn above the fuel with bright flames. -
Page 11: Using Burn Rate Air Control & Acc System
E. Using Burn Rate Air Control & ACC System 3. Manual Timer Over-Ride If you need to shut the ACC system off before it goes CAUTION through the cycle of shutting itself off; 25 minutes, reach towards the back of the appliance on the right side and pull the lever towards the front of the appliance (Figure 11.2). -
Page 12: Burn Rates And Operating Efficiency
F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency This wood appliance has a manufacturer-set minimum Risk of Fire. low burn rate that must not be altered. It is against federal When set on High Burn Rate and over-riding regulations to alter this setting or otherwise operate this the Automatic Combustion Control system an wood appliance in a manner inconsistent with operating... -
Page 13: Building A Fire
G. Building A Fire NOTE: Before lighting your first fire in the appliance: • Build fire on brick firebox floor. • Do NOT use grates, andirons or other methods to NOTE: The special high temperature paint that your support fuel. It will adversely affect emissions. appliance is finished with will cure as your appliance heats. -
Page 14: Blower Operating Instructions
I. Opacity (Smoke) H. Blower Operating Instructions This is the measure of how cleanly your appliance is NOTE: If your Quadra-Fire wood appliance is equipped burning. Opacity is measured in percent; 100% opacity is with an optional blower, you should follow... -
Page 15: Clear Space
K. Negative Pressure J. Clear Space NOTE: Do NOT place combustible objects within WARNING 4 ft(1.2 m) of the front of appliance (Figure 15.1). Asphyxiation Risk. • Mantel: • Negative pressure can cause spillage Avoid placing candles and other heat-sensitive objects of combustion fumes, soot and on mantel or hearth. -
Page 16: Frequently Asked Questions
L. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing. Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct. -
Page 17: Maintenance And Service
Maintenance and Service A. Quick Reference Maintenance Guide CAUTION! When properly maintained, your fireplace will give you many years of trouble-free service. Contact your Allow the appliance to completely cool down before dealer to answer questions regarding proper operation, performing any cleaning or maintenance. Start the troubleshooting and service for your appliance. -
Page 18: Cleaning And Operating The Ash Removal System
B. Cleaning and Operating the Ash Removal System WARNING Fire Risk. Make sure Ash Removal System door is sealed tight against the gasket. Air leakage may cause: • Over-fire condition • Flame and/or smoke spillage • Wood to burn too fast Figure 18.1 •... - Page 19 Formation and Need For Removal: 3. Disposal of Ashes When wood is burned slowly, it produces tar and other • Frequency: When ash is within 1-3/4 in. (44mm) of organic vapors which combine with expelled moisture firebox lip to form creosote. •...
-
Page 20: Correct Baffle & Blanket Placement
INCORRECT POSITIONS D. Correct Baffle & Blanket Placement WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •... -
Page 21: Troubleshooting Guide
Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken. Start Fire Problems Possible Cause Solution... -
Page 22: Service Part Replacement
NOTE: DO NOT OVER TIGHTEN RETAINERS - can cause glass to break. Magnet 9. Replace the door on the appliance. Spade Quadra-Fire appliances are equipped with ceramic super Connectors heat-resistant glass, which can only be broken by impact Figure 22.1 or misuse. -
Page 23: Firebrick
C. Firebrick Replace the firebrick if they become crumbly and/or if there is a 1/4 inch (6.35mm) gap between the bricks. Inspect the firebrick after each ash removal. The firebox is lined with high quality firebrick, which has exceptional insulating properties. There is no need to use a grate; simply build a fire on the firebox floor. -
Page 24: Door Handle Assembly
D. Door Handle Assembly NOTE: DO NOT over tighten locking nut; door handle needs to move smoothly! 43M-ACC-C Service Part: 832-0540 43ST-ACC-C Service Part: SRV7033-071 1. Install washer on door handle shaft. 1. Slide door handle through door. 2. Slide door handle through door. 2. -
Page 25: Baffle
E. Baffle Service Part: SRV7037-112 1. Remove all ash from the firebox, and extinguish all hot embers before disposal into a metal container. 2. The baffle board has 2 pieces. With the ceramic blanket still in place, slide one baffle piece over the top of other one and pull out top piece through the door opening and then remove bottom baffle piece (Figure 25.1). -
Page 26: Tube Channel Assembly
F. Tube Channel Assembly Service Part: SRV7033-023 Removing Tube Channel Assembly 1. Remove the right side panel by removing 2 screws in NOTE: Service Space the back using a Phillips head screw driver. In order to replace the tube channel assembly a 2. -
Page 27: Reference Materials
Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service February 17, 2020 7037-802A... - Page 28 Date of Service Performed By Description of Service 7037-802A February 17, 2020...
- Page 29 Date of Service Performed By Description of Service February 17, 2020 7037-802A...
-
Page 30: Acc-C
B. 43M-ACC-C 43M-ACC-C Service Parts Wood Stove Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active Part number list on following page. 02/20 7037-802A February 17, 2020... - Page 31 43M-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 32 Cam Latch SRV430-1141 13.6 Nut, Locking Door Handle Pkg of 24 226-0100/24 Component Pack: (Spring Handles(1) 1/2” & (2) 1/4”, 2 Nickel 436-5360 Hinge Pins, & Quadra-Fire Logo) Additional service part numbers appear on following page. 7037-802A February 17, 2020...
- Page 33 Timer (Only) Replacement Assembly SRV480-1940 Component Pack (Includes Touch-Up Paint, Fiber Handle, SRV7037-052 Owner’s Manual, & Installation Manual) Paint, Touch-Up Black 3-42-19905 Logo, Quadra-Fire Pkg of 10 7000-649/10 Additional service part numbers appear on following page. February 17, 2020 7037-802A...
- Page 34 43M-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
-
Page 35: 43St-Acc-C
C. 43ST-ACC-C 43ST-ACC-C Service Parts Step Top Model - Wood Stove Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active Part number list on following page. 02/20 February 17, 2020 7037-802A... - Page 36 43ST-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 37 43ST-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 38 43ST-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 39 43ST-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 40 43ST-ACC-C Service Parts Beginning Manufacturing Date: Jan 2020 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Stocked Provide model number and serial number when requesting service parts from your dealer at Depot or distributor.
- Page 41 Wire Harness (Blower) 7033-262 Component Pack 7033-051 Upgrade, Door (Nickel Handles, Hinge Pins & Logo) Nickel UK-DRNL Logo, Quadra-Fire Pkg of 10 7000-649/10 Cast Legs, Black Set of 4 TRAD-LEG-BK FASTENERS Avk Rivnut Repair Kit - 1/4-20 & 3/8-16 Rivnut Tools...
- Page 42 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
