- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. SB200...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SB 200 Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. 230/240 Volts AC 50Hz 9.8/10.7kW 1240mm 460mm 585mm 51.4 kg... -
Page 3: Table Of Contents
CONTENTS Technical Details ... Contents ... Preface ... Safety ... Before Installation ... During Operation ... After Use ... General ... Introduction ... Rating Plate ... Installation ... Reversible Oven Door ... General Notes on Using Your Appliance ... About Condensation and Steam ... Grill and Oven Furniture ... -
Page 4: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 5: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance has been removed before the appliance is used. -
Page 6: After Use
Take care recommendations given for tending the food when grilling. Do not leave the grill pan handle in position when grilling as it will become hot. Always use oven gloves to withdraw the grill pan, when grilling. Follow recommendations page 12. Ensure that unobstructed to ensure ventilation of... -
Page 7: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE This is situated on the front frame of the appliance and can be seen upon opening the top cavity door. Alternatively the rating plate may also be found on the back or top of some models (where applicable). The appliance must be protected by a suitably rated fuse or circuit breaker. -
Page 8: Reversible Oven Door
REVERSIBLE OVEN DOOR If you require the oven door to be hinged on the opposite side, you will need to contact a qualified Service Engineer. See pages 21 and 22 for your nearest Service Force Centre. that a charge will be made. GENERAL NOTES ON USING YOUR APPLIANCE We suggest that you run the oven elements for 10... -
Page 9: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Hotplate Controls - Grill Control - Oven Indicator - Oven Temperature Control... -
Page 10: The Radiant Hob
THE RADIANT HOB USING THE HOB To operate the hotplates, turn the control knobs clockwise from the 'OFF' position (0) to the required setting. The highest number represents the hottest setting and the lowest number the coolest setting. Choose a setting appropriate to the quantity and type of food to be cooked. -
Page 11: Deep Fat Frying
DEEP FAT FRYING SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one third full of oil, DO NOT cover the pan with a lid and DO NOT leave the pan unattended. In the unfortunate event of a fire, switch the appliance OFF at the electricity supply and cover the pan with a lid or damp cloth to assist in smothering the flames. -
Page 12: The Grill
THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHLDREN SHOULD BE KEPT AWAY. To operate the grill, turn the grill control clockwise from the 'OFF' position (0) to the required setting. The highest number represents the hottest setting and the lowest number the coolest setting. -
Page 13: Hints And Tips
HINTS AND TIPS Food should be thoroughly dried before grilling to minimise splashing. Brush lean meats and fish lightly with a little oil or melted butter to keep them moist during cooking. Adjust the height of the grilling grid and grill pan runner position to allow for different foods. -
Page 14: The Oven
THE OVEN To operate the oven turn the oven temperature control to the required temperature. THINGS TO NOTE The oven indicator neon will glow until the oven has reached the required temperature and then go out. It will turn ON and OFF periodically during cooking showing that the temperature is being maintained. -
Page 15: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10°C to suit individual preferences and requirements Shelf positions are counted from the bottom of the oven. FOOD Biscuits Flapjacks... -
Page 16: Roasting Chart
ROASTING CHART The oven temperatures are intended as a guide only. temperatures by 10°C to suit preferences and requirements. MEAT Beef Beef, boned Mutton and Lamb Pork and veal Chicken Turkey and Goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 17: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE APPLIANCE TO COOL BEFORE CLEANING. CLEANING MATERIALS Before using cleaning appliance, check that they are suitable and that their use is recommended by the manufacturer. Cleaners that contain bleach should NOT be used as they may dull the surface finishes. -
Page 18: Hints And Tips
HINTS AND TIPS Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if abrasives or aerosol sprays of any kind are used. Slight discolouration polishing Stayclean surfaces may occur in time. This does not affect the Stayclean properties in any way. A good time to allow the oven to run on is after the weekly roast. -
Page 19: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 20: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department Tricity Bendix 55 –... -
Page 21: Customer Service Centres
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. - Page 22 NOTES...
- Page 23 NOTES...
- Page 24 In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. TRICITY BENDIX 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ.
