- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SPLASHBACK ELECTRIC COOKER SB200/3 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SB200/3 Voltage: 230-240 Volts AC 50Hz Wattage: 9.8-10.7kW Height: 1240mm Width: 460mm Depth: 585mm Weight: 51.4kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC... -
Page 3: Table Of Contents
CONTENTS Technical Details ............................ 2 Contents ..............................3 Preface ..............................4 Safety ............................... 5 Before Installation ........................... 5 During Operation ..........................5 After Use ............................6 General ............................6 Introduction ............................. 7 Rating Plate ............................ 7 Installation ............................7 General Notes on Using Your Appliance ..................8 About Condensation and Steam ..................... -
Page 4: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 5: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN DURING OPERATION THE INTERESTS OF YOUR SAFETY. This appliance is not intended to be ENSURE THAT UNDERSTAND operated by means of an external THEM ALL BEFORE INSTALLING OR timer or remote control system. USING THE APPLIANCE. Do not use this appliance if it is in contact with water. -
Page 6: After Use
Take care follow Do not leave utensils containing recommendations given for tending foodstuffs, e.g. fat or oil in or on the the food when grilling. appliance in case it is inadvertently switched ON. Always use oven gloves to remove Appliances and hobs become very and replace food in the oven. -
Page 7: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE This is a type 'X' appliance, which means it is free- standing and can be fitted with cabinets on one or both sides. It may also be fitted in a corner setting. This is situated on the lower front frame of the appliance and can be seen upon opening the door. -
Page 8: General Notes On Using Your Appliance
GENERAL NOTES ON USING YOUR GRILL AND OVEN FURNITURE APPLIANCE The following items of grill/oven furniture have been We suggest that you run the oven elements for 10 – supplied with the appliance: 15 minutes at 220 C to burn off any residue from their surfaces. -
Page 9: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Hotplate Controls - Grill Control - Oven Temperature Control - Oven Indicator Neon... -
Page 10: The Radiant Hob
THE RADIANT HOB USING THE HOB HINTS AND TIPS · To operate the hotplates, turn the control knobs · clockwise from the OFF position (0) to the Lift, rather than slide saucepans on and off the required setting. hob to help reduce scratches and maintain the efficiency of the hotplates. -
Page 11: Deep Fat Frying
5. Double frying chips. · To prolong the life of the hotplates: Double frying will ensure good chips. First fry the · Never use utensils with a skirt, e.g. a bucket. chips for a few minutes at 170°C/340°F to seal ·... -
Page 12: The Grill
THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. To correctly locate the grill pan ensure the pan · To operate the grill, turn the grill control locates into the runners in the grill compartment side clockwise from the 'OFF' position (0) to the panels. -
Page 13: Hints And Tips
HINTS AND TIPS GRILLING CHART · Food should be thoroughly dried before grilling to FOOD RUNNER GRILL TIME minimise splashing. Brush lean meats and fish POSITION (mins in total) lightly with a little oil or melted butter to keep Bacon Rashers them moist during cooking. -
Page 14: The Oven
THE OVEN HINTS AND TIPS · To operate the oven turn the oven control to the required temperature. · Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. THINGS TO NOTE The indicator neon will glow. -
Page 15: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. MAIN OVEN SHELF APPROXIMATE COOKING FOOD POSITIONS COOK TEMP (°C) (TIME MINS) Biscuits 4 and 5... -
Page 16: Oven Roasting Chart
ROASTING CHART TEMPERATURES (°C) COOKING TIME MEAT OVEN 20-35 minutes per ½kg (1lb) Beef 180 - 200°C and 20-35 minutes over Beef, boned 180 - 200°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Mutton and Lamb 180 - 200°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Pork and Veal... -
Page 17: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE ELECTRICITY CLEANING THE HOB AND HOTPLATE SUPPLY AT THE MAIN WALL SWITCH TRIMS AND ALLOW THE APPLIANCE TO COOL Clean the hob surface with liquid detergent or a mild BEFORE CLEANING. abrasive cleaner, e.g. Cif. The chrome hotplate trims are removable for CLEANING MATERIALS cleaning, and can be washed in the dishwasher. -
Page 18: Hints And Tips
HINTS AND TIPS · Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if abrasives or aerosol sprays of any kind are used. · Slight discolouration polishing Stayclean surfaces may occur in time. This DOES NOT affect the Stayclean properties in any way. -
Page 19: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 20: Service And Spare Parts
Email: service.eid@electrolux.ie CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below; Customer Care Department Tricity Bendix 55 –... -
Page 21: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 22: Notes
NOTES... - Page 23 NOTES...
- Page 24 Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
