Traulsen G10002P Specification Sheet

Project
Model Specified:
G-Series Pass-Thru Solid Door
Refrigerators/Self-Contained
Equipped with an
easy to use
microprocessor
control!
Model G20004P
Standard Product Features
• High Quality Stainless Steel Exterior Front and Doors
• Corrosion Resistant Anodized Aluminum One-Piece Sides
• Durable Anodized Aluminum Interior
• Microprocessor Control With LED Temperature Readout
• Top-Mounted, Balanced, Self-Contained Refrigeration System
• Large High Humidity Evaporator Coil Outside The Food Zone
• Load-Sure Guard Protects Against Improper Loading
• Full or Half Length Stainless Steel Doors With Locks
• Self-Closing Doors With Stay Open Feature At 120 Degrees
• Guaranteed For Life Cam-Lift Hinges
• Guaranteed For Life Horizontal Work Flow Door Handles
• Automatically Activated Incandescent Lights
• Damage Resistant Stainless Steel Breaker Caps
• Three (3) Adjustable Epoxy Coated Shelves Per Section,
Supported On Shelf Pins (installed at the factory)
• Energy Saving Automatic Non-Electric Condensate Evaporator
• Magnetic Snap-In Door Gaskets
• Gasket Protecting Anodized Aluminum Door Liner
• Anti-Condensate Door Perimeter Heaters
• Thermostatic Expansion Valve Metering Device Provides Quick
Refrigeration Recovery Times
• Stainless Steel One-Piece Louver Assembly
• 9' Cord & Plug Attached
• Set of Four (4) 6" High Casters With Locks
• One Year Parts And Labor Warranty
• Five Year Compressor Warranty
Listed by Underwriters Laboratories Inc., to
U.S. and Canadian safety standards and
Listed by NSF International.
Quantity
G
SERIES
Stainless Steel
Front & Door(s)
Model G10012P
TRAULSEN
4401 BLUE MOUND RD.
PHONE 1 (800) 825-8220
Website: www.traulsen.com
One & Two Section Models, 32" Deep
Aside from their anodized aluminum side and interior finishes,
Traulsen's G-Series "Dealer's Choice" models meet or exceed the
standard specifications and performance of most other brands top
tier product offerings. Reliable, energy efficient, and durable, with
large individual storage capacities, the high quality G-Series line-up
includes a wide range of one and two section pass-thru refrigerator
models, built in our most popular footprints. They are available with
either full or half height doors, and the added convenience of a
variety of different door hingings to choose from. In addition, each
also includes a number of user-friendly features, making them one
of the best overall equipment values in Foodservice today, and the
right fit for nearly any commercial application.
AVAILABLE MODELS
*Door hinging when viewed from that side.
Single Section Models
Control Side Other Side
Model # Door Hinging Hinging*
G10002P Half Right Right
G10003P Half Right Left
G10004P Half Left Left
G10005P Half Left Right
G10012P Full Right Right
G10013P Full Right Left
G10014P Full Left Left
G10015P Full Left Right
Optional Accessory Kits
• Additional Epoxy Coated Shelves*
• No. 1 Type Tray Slides* To Accommodate either: (1) 18" x
26" or (2) 14" x 18" Sheet Pans, Adjustable To 2" O.C.
• No. 4 Type Tray Slides* To Accommodate (1) 18" x 26" Sheet
Pans (equips one full section)
• Universal Type Tray Slides* To Accommodate Either (1) 18" x
26" or (2) 14" x 18" Sheet Pans, or (2) 12" x 20" Steam Table
Pans, Adjustable To 4" O.C.
• Chrome Plated Shelves* (for use in lieu of standard shelving)
• 6" High Adjustable Legs (for use in lieu of standard casters)
• Two Year Service/Labor Warranty Available
*Please refer to spec sheet 4-7 for
optional accessory kit details
NOTE: All optional accessory kits are shipped separately for
later installation by others at the jobsite.
Approval: __________________________________
FT. WORTH, TX 76106
FAX-MKTG. 1 (817) 624-4302
Item #
CSI Section 11400
Two Section Models
Control Side Other Side
Model # Door Hinging Hinging*
G20004P Half Left/Right Left/Right
G20005P Half Left/Left Left/Left
G20006P Half Right/Left Right/Left
G20007P Half Right/Right Right/Right
G20014P Full Left/Right Left/Right
G20015P Full Left/Left Left/Left
G20016P Full Right/Left Right/Left
G20017P Full Right/Right Right/Right
SECTION
4-5
