Napa 791-7332 Operating Manual

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all
personnel read this manual prior to using the device. It is also
the responsibility of the device owner to keep this manual
intact and in a convenient location for all to see and read. If the
manual or product labels are lost or not legible, contact NAPA for
replacements. If the operator is not fluent in English, the product
and safety instructions shall be read to and discussed with the
operator in the operator's native language by the purchaser/owner
or his designee, making sure that the operator comprehends
its contents.
SPECIFICATIONS
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Ton @ 100 PSI
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5/8"
Ram Travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7/8"
Ext. Screw Adj. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3/4"
Max. Height with Adapter . . . . . . . . . . . . . . . . . . . . . . 23-3/8"
Chassis Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-3/4"
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7/8"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2"
Wheel Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5"
Handle Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35-1/2"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 lbs.
791-7332
AIR/HYDRAULIC ECONOMY
• Read, study, understand and follow all instructions before
operating this device • Inspect the jack before each use.
Do not use if damaged, altered, modified, in poor condition,
leaking hydraulic fluid or unstable due to loose or missing
components. Make corrections before using • Lift only at
points of the vehicle as specified by the vehicle manufacturer
• User and bystanders must wear eye protection that meets
ANSI Z87.1 and OSHA standards • Do not exceed rated
capacity • This is a lifting device only. Immediately after
lifting, support the vehicle with appropriate means • No
persons should be under vehicle when jack is in use
• No alterations shall be made to this product • Use only
on a hard level surface • Always lower the jack slowly and
carefully • Do not use saddle adaptors or saddle extenders
between the stock lifting saddle and the load • Failure to
heed these warnings may result in serious or fatal personal
injury and/or property damage.
WARNING: This product can expose you to chemicals
including nickel, which is known to the State of California
to cause cancer and birth defects or other reproductive
harm. For more information go to
www.P65Warnings.ca.gov.
1
MODEL # 791-7332
20 TON CAPACITY
TRUCK JACK
ASME PASE-2014
WARNING
rev. 03/23/18
