Napa 791-7200 E Operating Manual & Parts List

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel
read this manual prior to using the device. It is also the responsibility
of the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual or product labels are lost
or not legible, contact NAPA for replacements. If the operator is not
fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
SPECIFICATIONS
Required Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 psig
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35"
Raised Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73.5"
Saddle Forward Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37º
Saddle Backward Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26º
Saddle Lateral Tilt . . . . . . . . . . . . . . . . . . . . . . . . . .12º left and right
Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-1/4" square
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167 Lbs.
791-7200 E
1/2 TON AIR & HYDRAULIC
TRANSMISSION JACK
• Read, study, understand & follow all instructions before
using. • Inspect the jack before each use. Do not use Jack
if damaged, altered, modified, in poor condition, or has loose
or missing hardware or components.
before using. • Consult the vehicle manufacturer for the
transmission's center of balance. • Never use a power tool
to activate the saddle tilt screws. Operate by hand or socket
wrench. • This is a lifting device only. Immediately after
lifting, support the vehicle with jack stands capable of
sustaining the load before working on the vehicle.
• Never get beneath the vehicle when it is supported by
the jack. • Secure the transmission to the jack's saddle
with the anchorage restraint system provided before raising
or lowering the transmission. • Center load on saddle. Be
sure setup is stable before working on vehicle. • Support the
engine with a stand before unbolting the transmission from
the engine. • Users and bystanders should wear eye
protection that meets ANSI Z87.1 and OSHA standards.
• Do not use jack beyond its rated capacity. Do not shock
load. • Use only on a hard level surface. • Adequately su
port the vehicle before starting repairs.• Use of this product
is limited to the removal, installation and transportation in the
lowered position, of transmissions, transfer cases and
transaxles. • Do not use any adapters unless approved or
supplied by NAPA. • Do not use (or modify) this product
for any other purpose than that for which it was designed
without consulting
representative. • Always lower the jack slowly and carefully.
• Failure to heed these warnings may result in serious or
fatal personal injury
WARNING: This product can expose you to chemicals
including nickel, which is known to the State of
California to cause cancer and birth defects or other
reproductive harm. For more information go to
www.P65Warnings.ca.gov.
