Napa 791-5222 Manual

BEFORE USING THIS DEVICE, READ THIS
MANUAL COMPLETELY AND THOROUGHLY,
UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND
MAINTENANCE REQUIREMENTS.
It is the responsibility of the device owner to make sure all personnel
read this manual prior to using the device. It is also the responsibility
of the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual or product labels are lost
or not legible, contact NAPA for replacements. If the operator is not
fluent in English, the product and safety instructions shall be read to
and discussed with the operator in the operator's native language by
the purchaser/owner or his designee, making sure that the operator
comprehends its contents.
SPECIFICATIONS
MODEL 791-5222 CAR DOLLY
Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500 Lbs.
Arm Length . . . . . . . . . . . . . . . . .18" long and fits 13" wide tires
Arm Spread . . . . . . . . . . . . . 15-1/2" to 27-1/4" center to center
Wheel Application . . . . . . .13" to 24" wheels with mounted tires
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-1/4"
Overall Retracted Width . . . . . . . . . . . . . . . . . . . . . . . . . . 24-3/4"
Overall Height With Pedal Raised. . . . . . . . . . . . . . . . . . . . . . 13"
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Lbs.
MODEL 791-5223 CAR DOLLY RACK (sold separately)
Capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Lbs.
Overall Length, Width and Height. . . . . . . . . . . .32"x24-3/4"x10"
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3/4" Dia.
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Lbs.
791-5222, 791-5223
Model # 791-5222, 791-5223
1,500 Lbs. CAPACITY
MODEL 791-5222 CAR DOLLY
• Read, study, understand and follow all instructions before
operating this device. • Inspect the dolly before each use.
Do not use if damaged, altered, modified, in poor condition,
leaking hydraulic fluid, or unstable due to loose or missing
hardware or parts. Make corrections before using. • Wear
eye protection that meets ANSI Z87.1 and OSHA standards.
• Do not exceed rated capacity. • Use only on hard, level,
dry concrete surface free from expansion joints and all
obstructions. • Do not us with tires that are wider than 12".
• Make sure setup is stable and secure before moving a
vehicle supported by dollies. • Do not start the vehicle's
engine or drive the vehicle when mounted on dollies. The
dolly is designed for manually moving the vehicle. • Stay
clear of lifted load. • This product contains one or more
chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm. Wash
hands thoroughly after handling. • Failure to heed these
warnings may result in serious or fatal personal injury and/
or property damage.
MODEL 791-5223 CAR DOLLY RACK
• Read, study, understand and follow all instructions before
operating this device. • Inspect the rack before each use.
Do not use if damaged, altered, modified, in poor condition,
or unstable due to loose or missing hardware or parts. Make
corrections before using. • Wear eye protection that meets
ANSI Z87.1 and OSHA standards. • Do not exceed rated
capacity. • Use only on hard, level, dry concrete surface
free from expansion joints and all obstructions. • Use this
rack for its intended purpose of storing and transporting
up to four dollies only. • This product contains one or
more chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm. Wash
hands thoroughly after handling. • Failure to heed these
warnings may result in serious or fatal personal injury and/
or property damage.
1
CAR DOLLY AnD
200 Lbs. CAPACITY
CAR DOLLY RACK
(sOLD sePARATeLY)
WARNING
rev. 03/14/12
