Toshiba GA-1121 Color Manual

Toshiba printer user manual
Hide thumbs Also See for GA-1121:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
TOSHIBA GA-1121
COLOR GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Toshiba GA-1121

Summary of Contents for Toshiba GA-1121

  • Page 1 TOSHIBA GA-1121 COLOR GUIDE...
  • Page 2 • Release Notes provide last-minute product information and workarounds for some of Quick Start Guide summarizes the steps for configuring the TOSHIBA GA-1121 and printing. It also describes how to access the Acrobat PDF files on the User Documentation CD. User Software Installation Guide User Software CD to enable users to print to the TOSHIBA GA-1121, and also describes setting up printing connections to the TOSHIBA GA-1121.
  • Page 3 Copyright © 2003-2005 Electronics for Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc.
  • Page 4 FCC Information WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Class A Compliance This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Software License Agreement YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS SOFTWARE. IF YOU DO NOT AGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE. INSTALLING OR USING THE SOFTWARE INDICATES THAT YOU AGREE TO AND ACCEPT THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ACCEPT THE TERMS OF THIS AGREEMENT YOU MAY RETURN THE UNUSED SOFTWARE FOR A FULL REFUND TO THE PLACE OF PURCHASE.
  • Page 6 Limitation of Liability TO THE MAXIMUM EXTENT PERMITTED BY LAW, EFI AND ITS SUPPLIERS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING FROM THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE OR FAILURE OF THE SOFTWARE, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.

  • Page 7: Table Of Contents

    Contents About the Documentation Introduction About this manual Key features of ColorWise Chapter 1: GA-1121 Color Management Managing color on the GA-1121 Rendering Style Pure Black Text/Graphics Black Overprint Spot Color Matching RGB Source Profile CMYK Simulation Profile CMYK Simulation Method...
  • Page 8 Expert Mode Restoring default calibration measurements Using the EFI Spectrometer ES-1000 Setting up the ES-1000 Calibrating the GA-1121 with the ES-1000 Using the EFI Densitometer ED-100 Setting up the ED-100 Calibrating the GA-1121 with the ED-100 Calibrating the GA-1121 with the DTP41...
  • Page 9 ix Contents Uploading custom color groups Editing color values Using a measurement instrument to target colors Saving changes and exiting Spot-On Color Setup Setting default ColorWise options Appendix A: Color Measurement Instruments Using the X-Rite DTP41 spectrophotometer Setting up the DTP41 Calibrating the DTP41 Using the X-Rite DTP32 densitometer Setting up the DTP32...

  • Page 11: About This Manual

    The other manuals are available at your site—refer to them for a complete description of your Toshiba GA-1121. The term “GA-1121” is used in this manual to refer to the Toshiba GA-1121. The term “copier/printer” is used to refer to the e-STUDIO211c/311c/2100c/3100c.

  • Page 12: Key Features Of Colorwise

    GA-1121. For consistent color, calibrate the GA-1121 on a regular basis. ColorWise Pro Tools include an easy-to-use calibrator, which allows you to calibrate using either the scanning unit that is part of the copier/printer or a...
  • Page 13 RGB file under different printing conditions without having to reprocess the RGB data each time. ColorWise color management (ColorWise) users to customize the GA-1121 to meet new printing needs as they arise. ColorWise supports profiles, which are industry standard color profiles that describe the color behavior of a device.

  • Page 15: Chapter 1: Ga-1121 Color Management

    Applications can generate color data for the GA-1121 in many different The most common type of color data produced from prepress applications generally produce generate may contain a mix of RGB, CMYK, and spot colors. The GA-1121 allows users to PostScript Level 2 or 3 printer drivers, see page 3-31).
  • Page 16 The following diagram illustrates the print options in the GA-1121 color management process that affect color data conversions. You can access these print options when you send a print job to the GA-1121. Most of these options and settings are described in subsequent sections of this chapter.
  • Page 17 You can specify settings for the following options by selecting print options when you send a job to the GA-1121. Some can also be set as defaults by the administrator dur- ing GA-1121 Setup or using ColorWise Pro Tools. Settings specified using print options override the defaults.
  • Page 18 1-4 GA-1121 Color Management GA-1121 color print option Enable Trapping On/Off Image Smoothing Automatic/Off/On/Below 90–300 ppi (Other) Gamma 1.0/1.2/1.4/1.6/1.8/2.0/2.2/2.4/2.6/2.8/3.0 (Default set at Setup or with ColorWise Pro Tools) (Other) White Point 5000 K (D50)/5500 K/6500 K (D65)/ 7500 K/9300 K...
  • Page 19 PostScript driver. output profile is applied to all data in the print job (see User-defined output profiles can be downloaded to the GA-1121 using ColorWise Pro Tools. For more information about using ColorWise Pro Tools, Chapter 3. This option is only available with the PostScript driver.
  • Page 20 DeviceRGB or calibrated RGB color spaces. This option is only available with the PostScript driver. The On setting enables GA-1121-defined matching of spot colors to their best CMYK equivalents. With the Spot-On (available as Option), you can use Spot-On to manage and edit these spot color matches (see...

  • Page 21: Rendering Style

    The Rendering Style option specifies a CRD for color conversions. To control the appearance of images, such as prints from office applications or RGB photographs from Adobe Photoshop, select the appropriate Rendering Style. The GA-1121 allows you to select from the four rendering styles currently found in industry standard ICC profiles.

  • Page 22: Pure Black Text/Graphics

    Spot PostScript applications (such as QuarkXPress) may convert elements defined as RGB = 0, 0, 0 to four-color CMYK black before sending the job to the GA-1121. These elements are not affected by the Pure Black Text/Graphics option. For details,...

  • Page 23: Black Overprint

    —Black text or text/graphics knocks out colored backgrounds. PostScript applications may perform their own black overprint conversions before sending the print job to the GA-1121. One example of how you might use this setting is with a page that contains black text on a light blue background.

  • Page 24: Spot Color Matching

    CMYK equivalents. • —The GA-1121 uses a built-in table to generate the closest CMYK matches of spot colors your copier/printer can produce. (New tables are generated when you add new output profiles.) With the Spot-On (available as Option), the GA-1121 uses the CMYK matches determined through Spot-On (see •...

  • Page 25: Rgb Source Profile

    Commonly used monitor color spaces are available from the printer driver and from the ColorWise Pro Tools Profile Manager. For special needs, use ColorWise Pro Tools to download custom monitor or scanner profiles. When you specify a setting other than None for the RGB Source Profile, the GA-1121 overrides source color space systems may have specified.

  • Page 26: Cmyk Simulation Profile

    Source-10. For more information on Two-Way Communication, see the User Software Installation • instructs the GA-1121 to allow the RGB sources you defined elsewhere, such None as in the application, to be used. When you set RGB Source to None, the appearance of colors will not be independent of the file type.

  • Page 27: Cmyk Simulation Method

    Profile setting. To properly simulate a printed image that was separated through the use of an ICC profile, the same profile must be present on the GA-1121. For more information about downloading ICC profiles to the GA-1121, see page 3-4.

  • Page 28: Rgb Separation

    The RGB Separation option determines how RGB colors (as well as Lab and XYZ colors) are converted to CMYK. The name of this option is meant to be descriptive, since the option defines the color spaces that will be used by the GA-1121 to “separate” the RGB data into CMYK values.

  • Page 29: Output Profile

    1-15 Managing color on the GA-1121 The RGB Separation print option should be used in conjunction with the Output Profile or CMYK Simulation Profile print options. • converts all RGB colors into the CMYK color space of your copier/printer Output (when set to the printer’s default), or a customized CMYK color space for your...

  • Page 30: Toner Reduction

    The printer driver writes a PostScript file containing the instructions generated by your application and the GA-1121 print options you chose. The printer driver sends the PostScript file to the GA-1121. The GA-1121 then performs PostScript processing and color conversions and sends raster color data to the print device.

  • Page 31: Setting Color Management Print Options For Windows

    • Install the Adobe PostScript Printer Driver and the GA-1121 PPD (see the Software Installation Guide). • Set up the GA-1121 for printing (see the • Install the ICC output profile for the GA-1121 on your Windows computer (see the User Software Installation O SET PRINT OPTIONS FOR INDOWS 1.

  • Page 32: Adobe Postscript Printer Driver For Mac Os

    • Install the AdobePS printer driver and the GA-1121 PPD. • Select the GA-1121 in the Chooser and set it up with the GA-1121 PPD. • Install the ICC output profile for the GA-1121 on your Mac OS computer (see the User Software Installation Guide).
  • Page 33 • ColorSync Color Matching option can be used with PostScript devices such as the GA-1121, but it is intended for use with PostScript Level 1 devices. If you use this option, you must specify the GA-1121 ICC profile as the Printer Profile. ColorSync Color Matching is not a suggested color matching method because it does not work in conjunction with all applications and requires that you disable features of ColorWise on the GA-1121.
  • Page 34 1-20 GA-1121 Color Management GA-1121 O SET COLOR MANAGEMENT OPTIONS 1. In the AdobePS Print dialog box, choose Color Matching from the menu. Choose Color Matching from this menu 2. Choose Color/Grayscale from the Print Color menu. Choose Color/Grayscale...
  • Page 35 1-21 PostScript printer driver for Windows and Mac OS 3. In menu bar, choose desired print functions, and specify the appropriate print options displayed under the menu bar. Detailed descriptions of print options are on page 1-3. If these settings are used regularly, click Save Settings to save them for subsequent jobs.
  • Page 36 1-22 GA-1121 Color Management GA-1121 O SET COLOR MANAGEMENT OPTIONS FROM OS X 10.2/10.3 1. In the Print dialog box, choose Printer Features from the menu. Choose Printer Features from this menu 2. In the Printer Features menus, choose settings for the print options described on page 1-3.

  • Page 37: Chapter 2: Color Calibration

    Calibrating the GA-1121 ensures consistent, reliable color output. This chapter Chapter 2: explains how Color Calibration You can calibrate the GA-1121 using ColorWise Pro Tools in combination with any of the following color measurement instruments: • EFI Spectrometer ES-1000 hand-held spectrometer • EFI Densitometer ED-100 hand-held densitometer •...

  • Page 38: An Overview Of Calibration

    • A calibration target that describes the expected behavior of the copier/printer is contained in each output profile. After you have calibrated the GA-1121, a calibration set is stored. This calibration set will be used when it is associated with an output profile. Every output profile has an associated calibration set.

  • Page 39: How Calibration Works

    • Achieve better color matches when reproducing colors or other named color • Optimize the GA-1121 for using ColorWise rendering styles (CRDs) and CMYK simulations, and for using ICC profiles. How calibration works Success in obtaining satisfactory print quality from the GA-1121 depends on many factors.

  • Page 40: Scheduling Calibration

    1-15. Scheduling calibration In general, you should calibrate the GA-1121 at least once a day, depending on the volume of print jobs. If it is very important to maintain consistent color, or if the copier/printer is subject to wide fluctuations in temperature or humidity, calibrate every few hours.

  • Page 41: Checking Calibration Status

    Checking calibration status To verify whether the GA-1121 is calibrated, which calibration set and output profile were used, and when the copier/printer was last calibrated: • Print a Configuration page or Test Page from the Control Panel or Command WorkStation.

  • Page 42: Starting Calibrator

    GA-1121 ALIBRATE THE USING 1. Start ColorWise Pro Tools and connect to the GA-1121. For instructions on configuring the connection to the GA-1121, see the Installation Guide. If the connection to the GA-1121 from Command WorkStation (which also allows for access to ColorWise Pro Tools) is not established, you can start ColorWise Pro Tools independently of Command WorkStation.

  • Page 43: Expert Mode

    2-7 Using Calibrator The Calibration window appears in Standard mode. 3. Use the Calibrator window to perform the calibration method of your choice. Procedures for each calibration method are described in subsequent sections of this chapter. Expert Mode Calibrator provides two modes: Standard Mode and Expert Mode. You can perform all essential calibration tasks while in Standard Mode.
  • Page 44 PostScript or Encapsulated PostScript (EPS) file called CALIB.PS. Next, print the file to the Hold queue of the GA-1121 from your application, or download it to the Hold queue with Fiery Downloader. An additional way to create the CALIB.PS file is to...

  • Page 45: Restoring Default Calibration Measurements

    Restoring default calibration measurements The GA-1121 is shipped with default calibration measurements. You can use these measurements to achieve acceptable color without calibration, depending on the copier you use. If the measurement device you use does not produce acceptable color, you can...

  • Page 46: Using The Efi Spectrometer Es-1000

    It uses the density measurements to effectively calibrate the GA-1121. Setting up the ES-1000 To use the ES-1000 for calibration purposes, you must first set it up for use with your computer.

  • Page 47: Calibrating The Ga-1121 With The Es-1000

    The following illustration shows the different parts of the ES-1000. Measure button Sample aperture White tile reference Calibrating the GA-1121 with the ES-1000 You can use ColorWise Pro Tools in conjunction with the ES-1000 to calibrate the GA-1121. GA-1121 O CALIBRATE THE 1.
  • Page 48 2-12 Color Calibration 5. Choose the appropriate options and click Print. For Page Type, choose either 21 or 34 Sorted Patches, or 21 or 34 Randomized Patches. Sorted patches are printed on the page in the order of their hue and saturation levels.
  • Page 49 2-13 Using the EFI Spectrometer ES-1000 The Information dialog box appears. 9. Place the ES-1000 in the calibration cradle, and click OK. The EFI Spectrometer Measurement dialog box appears. Directions for measuring the strips appear in the Status field. For a more accurate measurement, place several sheets of plain white paper beneath the Measurement Page to block underlying colors from being read by the instrument.

  • Page 50: Using The Efi Densitometer

    The EFI Densitometer ED-100 is a hand-held instrument that measures the density of printed ink and toner. Like the DTP32, the ED-100 is a reflection you can use to calibrate the GA-1121. Setting up the ED-100 To use the ED-100 for calibration purposes, you must first set it up for use with your computer.

  • Page 51: Calibrating The Ga-1121 With The

    2-15 Using the EFI Densitometer ED-100 Calibrating the GA-1121 with the ED-100 You can use ColorWise Pro Tools in conjunction with the ED-100 to calibrate the GA-1121. GA-1121 O CALIBRATE THE USING THE 1. Start Calibrator. For instructions on starting Calibrator, see 2.
  • Page 52 GA-1121. Multiple measurements are more accurate, but may take more time. To hear a confirmation tone each time a measurement is recorded, select the Audio Feedback option.
  • Page 53 2-17 Using the EFI Densitometer ED-100 When you click Start, the Measurements window appears. Directions for measuring the patches appear in the Status area. 9. Place the ED-100 over the specified patch on the Measurement Page, making sure to center the sample aperture over the patch. Press Measure to take the measurement. For a more accurate measurement, place several plain sheets of paper beneath the Measurement Page to block underlying colors from being read by the instrument.
  • Page 54 11. When all the patches have been read successfully, click Accept. 12. Click Apply in the Calibrator window to implement the new calibration set. 13. Click OK in the Information dialog box. This completes the GA-1121 calibration process.

  • Page 55: Calibrating The Ga-1121 With The Dtp41

    Using the ColorWise Pro Tools Calibrator application and the DTP41 spectrophotometer, you can quickly measure color patches generated by the copier/printer and automatically download these measurements to the GA-1121. Before using ColorWise Pro Tools and the DTP41 to calibrate the GA-1121, follow the instructions on GA-1121...
  • Page 56 2-20 Color Calibration Paper Size is automatically set to LTR/A4 for 21 Sorted Patches, or 11 x 17/A3 for 34 Sorted Patches. For Input Tray, choose the paper source for printing the measurement page. 6. Retrieve the measurement page from the copier/printer. 7.
  • Page 57 2-21 Calibrating the GA-1121 with the DTP41 10. Insert the measurement page into the DTP41, starting with the cyan strip. Follow the on-screen instructions to align the page properly. 11. Click Read Strip. The DTP41 pulls the measurement page through automatically.

  • Page 58: Calibrating The Ga-1121 With The Dtp32

    Calibrating the GA-1121 with the DTP32 Using the DTP32, you can quickly measure color patches and download these measurements to the GA-1121 using ColorWise Pro Tools Calibrator. Before using ColorWise Pro Tools and the DTP32 to calibrate the GA-1121, follow the instructions on GA-1121...
  • Page 59 2-23 Calibrating the GA-1121 with the DTP32 5. Choose the appropriate options, and click Print. For Page Type, choose either 34 or 21 Sorted Patches Paper Size is automatically set to LTR/A4 for 21 Sorted Patches, or 11 x 17/A3 for 34 Sorted Patches.

  • Page 60: Using Autocal And Colorcal

    This completes the GA-1121 calibration process. Using AutoCal and ColorCal AutoCal and ColorCal allow you to calibrate the GA-1121 without the use of an additional spectrophotometer or densitometer. Instead, these methods use the copier/printer’s built-in scanner to measure toner density values. Using either AutoCal or ColorCal provides an equally accurate calibration of the GA-1121.

  • Page 61: Calibrating With Colorwise Pro Tools And Autocal, Or Colorcal

    Calibrating with ColorWise Pro Tools and AutoCal, or ColorCal When you run ColorCal from ColorWise Pro Tools, you have the option to calibrate the copier/printer’s scanner before calibrating the GA-1121 itself. This option is not available for AutoCal. It is recommended to calibrate the scanner for ColorCal when the copier/printer output has been adjusted, such as after maintenance or service.
  • Page 62 13. To perform the scanner calibration, click Continue in the ColorCal dialog box that appears. After the scanner has been calibrated, another dialog box appears, prompting you to calibrate the GA-1121. 14. Click Measure in the AutoCal or ColorCal Get Measurements pane.

  • Page 63: Calibrating From The Control Panel With Autocal Or Colorcal

    Control Panel. For instructions on using the GA-1121 Control Panel, see the Configuration Guide. It is also possible to remove calibration measurements from the GA-1121. In general, it is not necessary, because any new calibration replaces the existing one if the same calibration set is selected.
  • Page 64 7. Choose Calibrate, and press Set. 8. Select the Media and press Set. Choose from the list of all calibration sets on the GA-1121. This prompt appears only if more than one calibration set is available. 9. When prompted, choose Yes to print the measurement page.
  • Page 65 2-29 Using AutoCal and ColorCal 12. Place the color measurement page face-down over the grayscale strip. Place the page at the upper-left corner of the copier/printer glass. Slide the grayscale strip to the top center of the color measurement page. Make sure the patches on the grayscale strip do not overlap the color patches.
  • Page 66 2-30 Color Calibration O REMOVE CALIBRATION FROM THE ONTROL ANEL 1. From the GA-1121 Control Panel, access the Calibration menu as described on page 2-27. 2. Choose Remove Calibration. 3. When prompted, verify that you want to proceed with removing calibration.

  • Page 67: Chapter 3: Colorwise Pro Tools

    Windows versions. For information on installing and configuring a connection to ColorWise Pro Tools, see the If the connection to the GA-1121 from Command WorkStation (which also allows for access to ColorWise Pro Tools) is not established, you can start ColorWise Pro Tools independently of Command WorkStation.

  • Page 68: Profile Manager

    RGB colors processed by the GA-1121. If you use Photoshop 5.x, 6.x, or 7.x, you can upload the profile for your selected working space to the GA-1121 and choose that as your RGB Source Profile. For more information, see the •...

  • Page 69: Setting The Default Profiles

    Setting the default profiles The default profiles are applied to all print jobs sent to the GA-1121, unless you override them using print options. Therefore, the defaults should be the most commonly used profiles.

  • Page 70: Downloading Profiles

    Use Calibration Set menu and a new name in the Profile Description menu. Downloading profiles The GA-1121 includes default profiles. You can download additional profiles from any computer connected to the GA-1121. O DOWNLOAD A PROFILE 1.
  • Page 71 3. When the profile you want to download appears in the list in the main Profile Manager window, select it. If the profile is compatible with the GA-1121, a green arrow indicates that the profile is available for downloading. Only output device profiles are downloadable to Simulation and Output.

  • Page 72: Editing Profiles

    Profile Manager allows you to back up profiles to ensure that no custom profiles are lost when the GA-1121 software is updated. You can also upload a copy of a built-in GA-1121 profile to your workstation in order to use it with an ICC-aware application, such as Photoshop.

  • Page 73: Defining Profiles

    These fixed names are used in the printer driver, so you can select profiles per job even if your driver does not have the capability to obtain an updated list from the GA-1121. A custom simulation profile is used to illustrate this procedure. The same steps apply for defining output profiles.
  • Page 74 3-8 ColorWise Pro Tools O DEFINE A CUSTOM SIMULATION PROFILE 1. Start ColorWise Pro Tools and click Profile Manager. For the purposes of this example, assume DIC-new is a custom simulation profile created with Color Editor and, as such, no information is displayed for DIC-new under the heading “Appear in Driver as.”...
  • Page 75 3-9 Profile Manager Although you cannot delete a preset profile, you can use the name of a preset profile name for your edited profile when you select the “Appear in Driver as” option. This replaces the preset profile with your own profile. In Profile Settings, you can also change profile descriptions for all non-locked profiles.

  • Page 76: Color Editor

    When you choose Profile Settings for an output profile, the Use Calibration Set options also appear. You must calibrate the GA-1121 with this calibration set before this option has any effect. If you have never measured for this calibration set, default measurements are used.
  • Page 77 USTOM 1. Start ColorWise Pro Tools and click Color Editor. 2. Choose Simulation or Output from the View menu. Simulation lists the simulation profiles resident on the GA-1121, and Output lists the output profiles resident on the GA-1121. , or —Create custom linked simulations.
  • Page 78 Color Editor window allows you to import a calibration target file (.trg) created on another GA-1121 using the previous version of ColorWise. The current version of ColorWise does not allow you to save a target separately; rather, it saves the...
  • Page 79 3-13 Color Editor 5. Select the colors you want to edit by turning colors off and on. The Eye icon to the left of each color indicates whether that color is visible on the graph and will be affected by changes to the curves, brightness, and dot gain controls. You can view and edit all four colors (cyan, magenta, yellow, and black) at once, or in any combination.
  • Page 80 3-14 ColorWise Pro Tools If you use Dot Gain values, apply the settings first, so that the curves are deflected from their straight-line positions. Then make edits to the new curves. When you adjust Dot Gain values, all existing points on the curve are removed. A warning dialog box allows you to cancel Dot Gain settings before they are applied.
  • Page 81 10. When you are finished, click Save and enter a name for the new profile. The new custom profile is saved to the GA-1121 with the new name. If you edit one of the press standard targets (for example, SWOP-Coated, DIC, or Euroscale), consider including the original name as part of the new target name (for example, DIC-new) to help you remember the source of the new target.
  • Page 82 Color Editor window allows you to import a custom Quick Simulation created on another GA-1121 using the previous version of ColorWise. The current version of ColorWise does not allow you to save custom CMYK Quick, Full (Source GCR) or Full (Output GCR) Simulations independently;...

  • Page 83: Undoing Cmyk Simulation Edits

    Checking edited profiles To view a printed sample of a profile before you save it to the GA-1121, print one of the following: • Comparison Page provided with ColorWise Pro Tools, which shows a comparison of images and colored patches with and without edits •...

  • Page 84: Using Spot-On

    However, you may switch to a different output profile at any time while working with Spot-On. In order to use Spot-On CMYK equivalents, you must enable the Spot Color page 1-10). The GA-1121 allows only one user connection through Spot-On at a time.

  • Page 85: Using The Spot-On Main Window

    Using the Spot-On main window The Spot-On main window displays a list of color groups which represent libraries of spot colors on the GA-1121. Tool icons for working with colors appear at the top of the window.
  • Page 86 Custom color group Default color group By default, the GA-1121 includes several PANTONE libraries along with a System library. These factory default libraries appear marked with the default group icon You can also add custom color groups and colors to the Spot-On window (see page 3-23).

  • Page 87: Working With Existing Colors

    You can also close all color groups by clicking the Close All icon above the color list. Working with existing colors With Spot-On, you can view and manage existing groups of colors on the GA-1121. You can also search for a particular color in the Spot-On list.
  • Page 88 3-22 ColorWise Pro Tools O REARRANGE THE PRIORITY OF COLORS 1. To rearrange an entire color group, select the desired color group. To rearrange an individual color, select the desired color. Individual spot colors are marked with circular color icons. 2.

  • Page 89: Creating Custom Colors

    3-23 Using Spot-On 3. To find additional colors based on the same search criteria, choose Find Again from the Edit menu. Creating custom colors Spot-On provides a number of default color groups, such as PANTONE and DIC, in the color list. You can add your own custom spot colors and groups to the list. O ADD A NEW COLOR OR COLOR GROUP 1.

  • Page 90: Downloading Custom Color Groups

    The upload feature allows you to share a group by creating a local copy that can be downloaded to another GA-1121. A color group must be saved to the GA-1121 before you can upload it to your computer. To upload a factory default group, copy and paste the group as a new...

  • Page 91: Editing Color Values

    3-25 Using Spot-On O UPLOAD CUSTOM COLOR GROUPS 1. Select the name of the color group you want to upload. 2. Choose Upload from the File menu. The Save As dialog box appears. 3. Browse to the location where you want to save the file, name the file, and then click Save.
  • Page 92 3-26 ColorWise Pro Tools Center Patch 2. To update the center patch to a neighboring color that more closely matches the target, click the corresponding neighbor patch. Neighboring patches represent variations from the center patch and can be selected if they offer a closer match to the desired color.
  • Page 93 3-27 Using Spot-On Saturation generates neighbor patches based on less saturated to more saturated variations of the original color. This variation is displayed from left to right, with the original color remaining in the center of the middle group. Choose a setting from the Color Spacing menu to control the closeness of the neighbor patches.
  • Page 94 3-28 ColorWise Pro Tools 6. Click OK to print the patches. The Print Pattern test page prints the following information: • Center patch color CMYK value • Color spacing • Lightness or Saturation neighbors selected • Output profile selected The goal of the Spot-On Color Search is to find the color values that make a printed color patch match a target, not the screen simulation of it.

  • Page 95: Using A Measurement Instrument To Target Colors

    The Device Codes option allows you to enter color values between 0 and 255. This option reflects the full range of color values that the GA-1121 can actually reproduce, and provides finer gradations of color than are possible with Percentages.

  • Page 96: Saving Changes And Exiting Spot-On

    Spot-On closes the connection to the instrument. Saving changes and exiting Spot-On To enable your spot color matches for use on the GA-1121, you must save your edits before exiting Spot-On. This action ensures that all your changes to Spot-On color definitions are stored on the GA-1121 and available for use when printing documents that contain spot colors.

  • Page 97: Color Setup

    Color Setup allows you to configure the default color management settings for the GA-1121. These settings are applied to all print jobs sent to the GA-1121, unless a user overrides them for an individual job by changing settings in the printer driver.
  • Page 98 3-32 ColorWise Pro Tools Once you have made your changes, you must click OK or Apply for the changes to take effect. Clicking OK sets the new defaults and closes the Color Setup window. Clicking Apply sets the new defaults and keeps the Color Setup window open. Clicking Cancel closes the Color Setup window without applying any changes to the default settings.

  • Page 99: Appendix A: Color Measurement Instruments

    GA-1121 automatically. Setting up the DTP41 Before you calibrate the GA-1121, you must connect, configure, and calibrate the spectrophotometer to prepare for measuring the printed patches. For additional information about setting up and using the DTP41, see the documentation included with the instrument.
  • Page 100 A-2 Color Measurement Instruments 3. Plug the square end of the interface cable (looks like a modular phone plug) into the serial interface connection on the side of the X-Rite DTP41. Instrument button Alignment mark LED indicator Measurement page slot Power input Calibration strip entrance Serial interface connection...
  • Page 101 A-3 Color Measurement Instruments 4. Attach the connector to the computer. For a Windows computer, insert the 8-pin mini-DIN end of the interface cable into the 9-pin DB9 Connector cable adapter. Insert the 9-pin end into the COM1 or COM2 port on the computer and tighten the screws. If the available port on your computer is 25-pin, you must use the 8-pin-to-25-pin adapter.

  • Page 102: Calibrating The Dtp41

    For the best color accuracy, calibrate the X-Rite DTP41 spectrophotometer every time you calibrate the GA-1121. You can initiate the calibration sequence in ColorWise Pro Tools Calibrator as part of the process of GA-1121 calibration. The computer may also prompt you that it is necessary to calibrate the spectrophotometer.
  • Page 103 A-5 Color Measurement Instruments Multiple users can be connected to one GA-1121 with ColorWise Pro Tools, but only one user at a time can use the Calibrator module. An error message appears if you try to calibrate when another user is already using ColorWise Pro Tools to calibrate.
  • Page 104 A-6 Color Measurement Instruments The Instructions area displays instructions for selecting the port. 7. Click Utilities. The Utilities dialog box appears. To view version and serial number information, click Show DTP-41 Info, and then click Done when you are finished. 8.
  • Page 105 This completes DTP41 calibration. When the DTP41 requires calibration, your computer prompts you. When the prompt message appears, click Calibrate Now and follow the instructions, starting with step 8 page A-6. After calibrating the DTP41, calibrate the GA-1121 (see page 2-19).

  • Page 106: Using The X-Rite Dtp32 Densitometer

    Measurements from other densitometers can be input using a simple ASCII file format (see Appendix Setting up the DTP32 Before you calibrate the GA-1121 using the X-Rite DTP32, you need to connect, configure, and calibrate the densitometer to prepare for measuring the printed patches (see “Calibrating the DTP32”...
  • Page 107 A-9 Color Measurement Instruments 3. Attach the connector to the computer. For a Windows computer, insert the 8-pin mini-DIN end of the interface cable into the 9-pin DB9 Connector cable adapter. Insert the 9-pin end into the COM1 or COM2 port on the computer and tighten the screws. If the available port on your computer is 25-pin, you must use the 8-pin-to-25-pin adapter.

  • Page 108: Calibrating The Dtp32

    AC adapter 5. Turn on the computer. 6. Calibrate the DTP32 (see the following section). 7. Calibrate the GA-1121 using ColorWise Pro Tools and the DTP32 (see Calibrating the DTP32 You will need the black-and-white X-Rite Auto-Cal Strip included with the densitometer.
  • Page 109 A-11 Color Measurement Instruments Recalibrate the DTP32 at least once per month. For critical color, calibrate the densitometer every time you calibrate the GA-1121. The DTP32 may also warn periodically that it requires calibration.

  • Page 111: Appendix B: Importing Density Measurements

    B-1 Importing density measurements This appendix describes Simple ASCII File Format, which can be used to import Appendix B: density measurements from measurement devices. To use your own measurement data Importing from an alternate measurement instrument, record your individual readings in a text density file and structure it as follows.

  • Page 112: Example Of 1D Status T Density For Efi 34 Patch Page

    B-2 Importing density measurements Example of 1D Status T density for EFI 34 patch page This file format is used to specify the Status T density measurements of the EFI 34 patch page. The value in the first column is the patch number. The first patch must be 1 and the last must be 34.

  • Page 113: Example Of 1D Status T Density For An Arbitrary Page

    B-3 Importing density measurements Example of 1D Status T density for an arbitrary page This file format is used to specify the Status T density measurements of a user-defined patch page. The value in the first column is the ink/toner percentage of the patch. The first percentage must be 0 and the last percentage must be 100.
  • Page 115 Index Index Absolute Colorimetric rendering style 1-7 Apple Standard setting, RGB Source Profile option 3-2 Apple Standard setting, RGB Source profile option 1-11 AutoCal calibration from ColorWise Pro Tools 2-25 from Control Panel 2-27 Black Detection option 1-3 Black Overprint option 1-9 Black Overprint Style option 1-3 black text and line art 1-5 Brightness option 1-3...
  • Page 116 I-2 Index ColorWise Pro Tools Calibrator 2-5 to 2-10 checking calibration status 2-5 Color Editor 3-10 to 3-18 Color Setup 3-31 Profile Manager 3-2 to 3-10 Combine Separations option 1-3, 1-15 Comparison Page 2-8, 3-17 composites, printing 1-3, 1-8, 1-10, 1-15 Configuration page 2-5 Contrast ICC rendering style 1-7 Control Panel...
  • Page 117 I-3 Index Mac OS color management options 1-18 to 1-21 Match Copy setting of CMYK Simulation option 1-3 measurements page 2-3 None setting, RGB Source Profile option 1-12 Other setting, RGB Source Profile option 1-12 Output Profile option 1-5 output profiles calibration sets for 2-3, 2-4, 3-10 PANTONE Coated Color Reference 1-10 Paper Simulation option 1-5...
  • Page 118 I-4 Index Spot Color Matching option 1-6, 1-10 spot colors, matching to CMYK equivalents 1-10, 3-18 to 3-30 Spot-On 3-18 sRGB, RGB Source Profile option 1-11, 3-2 Status T B-1 SWOP setting, CMYK Simulation Profile option 1-13, 3-2 targets, for calibration 2-3 Test Page 2-5 Toner Reduction option 1-4, 1-16 transfer functions 2-3...
