- Page 1 UI/Functional Specification VHF Marine Radio MRHH150FLT USA and EU Series 5-9-2018 LCD display requires update to support power level settings and add one more bar to RX/TX bar graph Date: May 8, 2018 Issue: Preliminary R2 Issued By: C. deWaal Pages: 18...
- Page 2 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2...
- Page 3 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 STARTUP DESCRIPTIONS • When the unit is first powered ON, a 500 Hz power up tone will sound for 100 ms unless KEY TONES are OFF. • The LCD will display all Icons except ATIS for 2 seconds on USA models.
- Page 4 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE STANDBY MODE Definitions: RX: unit is in receive mode and tuned to the displayed channel. Bar graph meter will display received signal level. Turn ON the following Icons: Rx, other depending on last used state.
- Page 5 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE STANDBY MODE – Continue KEY FUNCTIONS FOR MARINE STANDBY MODE: 1) Power Button Push and hold for two seconds to turn unit ON. Push and hold for two seconds to turn unit OFF.
- Page 6 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE STANDBY MODE – Continue KEY FUNCTIONS FOR MARINE STANDBY MODE: 8) Dual Watch / Scan Key - DW operation Press and release DW / Scan; unit will activate Dual Watch mode. “DW” will appear on display as channels are scanned.
- Page 7 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE STANDBY MODE – Continue 10) MEM / ESC Key MEM KEY: Press and release to enter Memory mode. MEM and memory channel icons turns on. First memory location is “0”, last is “9”...
- Page 8 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE STANDBY MODE – Continue 11) Scan Key H / M /L and WX - push and release to change power level, no interruption of scan. Push and hold, exit SCAN and enter WX mode.
- Page 9 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 WX STANDBY MODE From WX standby: Unit is in receive mode and tuned to the last used WX channel The cloud Icon is turned ON WX channel number is displayed in the main channel digits (1st & 2nd digit locations) Bar graph display shows received signal level 1.5uV of received signal produces full scale on bar graph.
- Page 10 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 Press and release DN key; channel # decrease. Press and hold DN key >0.5 seconds; channels decrease in rapid sequence every 250ms. 5) WX STANDBY MODE - Continue...
- Page 11 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE SETUP MODE From Marine Standby: Push and hold Setup key for 3 seconds. (Enters Setup Mode) LCD is cleared of all Icons except those relevant to each setup step.
-
Page 12: Key Tone On / Off
Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 MARINE SETUP MODE - (continued) From Marine Standby: Push and hold Setup key for 3 seconds. (Enters Setup Mode) LCD is cleared of all Icons except those relevant to each setup step. - Page 13 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 WX SETUP MODE (USA model only) From WX Standby: Push and hold Setup key for 3 seconds. (Enters Setup Mode) LCD is cleared of all Icons except those relevant to each setup step.
- Page 14 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 WX SETUP MODE From WX Standby: WX AUTO SCAN ON / OFF Default OFF - alternate SCAN and OFF in LCD WX Icon is flashing. "SCAN" and "ON" or "OFF" are flashing alternately.
- Page 15 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 WX SETUP MODE – Continue WX setup mode notes: While in setup mode, if no action from user for 15 seconds then SAVE and EXIT to standby.
- Page 16 Cobra Electronics UI/Functional Specification Model: MR HH150 USA and EU Issue: Preliminary R2 Revision History Issue: Preliminary, 16 April, 2018; C. deWaal • New Issue Issue: Preliminary R2, 8 May, 2018; C. deWaal • Added industrial design. • Added volume control.
- Page 17 FCC Warnings: Replacement or substitution of transistors, regular diodes or other parts of a unique nature, with parts other than those recommended by Cobra may cause a violation of the technical regulations of part 80 of the FCC Rules, or violation of type acceptance requirements of part 2 of the rules.
- Page 18 Canadian Ship Station License You need a Radio Operator’s Certificate if your vessel is operated in Canadian waters. Radio Operator ALWAYS use only Cobra authorized accessories. training and certification is available from the Canadian Power Squadron. Visit their website at http:// DO NOT operate the radio in an explosive atmosphere, near blasting sites, www.cps-ecp.ca/...
- Page 19 This radio is supplied with NiMH (Nickel-Metal Hydride) rechargeable batteries. • Use only the Cobra power cord to recharge NiMH batteries in the radio. • Do not short circuit the batteries. • When replacing the batteries, dispose of the old batteries properly. The NiMH batteries may explode if disposed of in a fire.
- Page 20 Ar šo Cobra Electronics Europe, Ltd. deklarē, ka radioiekārta VHF Marine Radio atbilst Direktīvai 2014/53/ES. EN (English) Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta vietnē: Hereby, Cobra Electronics Europe, Ltd. declares that the radio equipment type VHF Marine Radio is in compliance with http://www.snooperneo.co.uk/DeviceDocs.cfm Directive 2014/53/EU.
- Page 21 Current Drain: Standby 45 mA This will ensure the fastest turnaround time on any repair. If Cobra asks that the product be sent to its Receive (Rx) 140 mA factory, the following must be furnished to have the product serviced and returned: Transmit (Tx) 1.1 A @ High Power, 450 mA @ Low Power...
- Page 22 All implied warranties, including warranties of merchantability and fitness for a particular purpose are limited in duration to the length of this warranty. Cobra shall not be liable for any incidental, consequential or other damages; including, without limitation, damages resulting from loss of use or cost of installation.
