- Page 1 Before You Use This Machine Before you can send or receive fax messages, please take about 30 minutes to set up your machine. Set up your machine as in the following procedures. Keep going...
-
Page 2: Toner Cassette
Installing the Press down on the cassette until it locks Prepare the toner cassette. Toner Cassette into place. Important TDo not touch the green drum. Note TIf you do not push the cassette right in, the cover 1. Remove the toner cassette from its bag. will not close. - Page 3 Attaching the Installing the Set the paper then lower the cassette Quick Dial Sheet cover. Main Paper Note And Operation TThe frosted side of the cover must be face up when Cassette closed. Panel Sheet Unpack the cassette. Peel off the 3 pieces of tape from the cassette cover.
-
Page 4: Attaching The Trays And Docu- Ment Table
Attaching the If necessary, pull out the extensions on the Attach the Document Delivery Tray. Trays And Docu- Document Table and trays. ment Table Attach the Print Delivery Tray. Insert it at an angle so that the tabs fit in the slots pro- vided. - Page 5 Connecting up Connecting the to the Tel- Power and ephone Line Switching on There are two similar sockets located at the rear Insert the power cable into the socket of the machine: located at the rear of the machine. TEL1: For the external telephone LINE: Telephone line connection Plug in the cable to the mains.
- Page 6 Initial Settings & Enter your phone number. Press the [Yes] key. Adjustments Note CHANGE? Y/N TThe format of the number is normally as XYZ COMPANY follows: International Dial Prefix, Your Country Code, Your Area Code, then you must add a Press the [No] key to keep the TTI as it is.
-
Page 7: Phone Line
Setting the Setting the Date Changing the Paper Phone Line & Time Size Settings Press the [Function] key and [6], enter the Press the [Function] key and [6], enter the When you change the paper size loaded in the access code [2][2][2][2], then enter [6][2]. access code [2][2][2][2], then enter [9][1]. - Page 8 That’s it! EE GB H547-8671...
