- Page 1 Radio CD MP3 WMA Alicante MP36 Sevilla MP36 Operating instructions 7 646 460 310 7 646 450 310 http://www.blaupunkt.com...
- Page 3 1 On/Off button Short press: Mutes the device. Long press: Switches the device off. button to open the flip-release con- trol panel. 3 Volume control 4 SOURCE button to switch sources be- tween radio, CD, CD changer (if con- nected) and AUX. 5 AUDIO button to adjust bass, treble, middle, sub-out, balance and fader. Switching X-BASS on/off and adjust- ing it. Selects an equaliser presetting. 6 BND•TS button Short press: Selects the FM memory banks and the MW and LW wavebands.
-
Page 4: Table Of Contents
Contents Notes and accessories ... 38 Disposal of old unit (EU countries only) ... 38 Installation ..38 Optional equipment (not part of the scope of delivery) ... 38 Detachable control panel ... 39 Theft protection... 39 Detaching the control panel ..40 Attaching the control panel ..40 Switch-off time (OFF TIMER) ... 40 Switching on/off ... 41 Adjusting the volume ... 41 Setting the power-on volume ... - Page 5 CD-changer mode ... 56 Switching to CD-changer mode ... 56 Selecting CDs ..56 Selecting tracks ..56 Fast searching (audible) ..56 Changing the display ... 57 Repeating individual tracks or whole CDs (REPEAT) ... 57 Random track play (MIX) ..57 Scanning all tracks on all CDs (SCAN) . ..57 Interrupting playback (PAUSE) ..57 Clock time ... 58 Displaying the time ... 58 Setting the time .
-
Page 6: Notes And Accessories
Notes and accessories Notes and accessories Thank you for choosing a Blaupunkt prod- uct. We hope you enjoy using this new piece of equipment. Please read these operating instructions before using the equipment for the first time. The Blaupunkt editors are constantly work- ing on making the operating instructions clearer and easier to understand. However, if you still have any questions on how to op- erate the device, please contact your dealer or the telephone hotline for your country. -
Page 7: Detachable Control Panel
Notes and accessories Amplifier You can use all Blaupunkt and Velocity am- plifiers. CD changers You can connect the following Blaupunkt CD changers: CDC A 03, CDC A 08 and IDC A 09. Detachable control panel Theft protection The device is equipped with a detachable control panel (flip-release panel) as a way of protecting your equipment against theft. The device is worthless to a thief without this control panel. Protect your device against theft by taking the control panel with you whenever you leave your vehicle. Do not leave the control... -
Page 8: Detaching The Control Panel
Control panel Detaching the control panel Press the button 2. The control panel opens out towards you. Hold the control panel by its right side and then pull the control panel straight out of the bracket. Notes: • The device is switched off after a time preset by you. For instructions, please read the section "Switch-off time (OFF TIMER)" in this chapter. • All the current settings are saved. • Any CD already inserted in the device remains there. Attaching the control panel Hold the control panel approximately at a right angle to the device. -
Page 9: Switching On/Off
Switching on/off Switching on/off There are various ways of switching the de- vice on/off: Switching on/off using button 1 To switch on the device, press button The device switches on. To switch off the device, press and hold down button 1 for longer than two seconds. The device switches off. Switching on/off using the vehicle ignition The device will switch on/off simultane- ously with the ignition if the device is cor-... -
Page 10: Quickly Reducing The Volume (Mute)
Your Blaupunkt dealer can provide you with the information which navigation system can be used with your car sound system. If a traffic announcement is received dur- ing a telephone call or a voice output of the navigation, you can listen to the traffic an- nouncement only after the telephone call/ voice output has ended, provided that it is still being broadcast. The traffic announce-... -
Page 11: Switching The Confirmation Beep On/Off
Switching the confirmation beep on/off The system will output a confirmation beep for some functions if you keep a button pressed down for longer than two seconds, for instance, when assigning a radio station to a station preset button. You can switch the beep on or off. Press the MENU button 9. Press the or button : repeatedly until "BEEP ON" or "BEEP OFF" appears on the display. Switch the BEEP ON or OFF with the or button :. -
Page 12: Radio Mode
Radio mode Radio mode This device is equipped with an RDS radio receiver. Many of the receivable FM stations broadcast a signal that not only carries the programme but also additional information such as the station name and programme type (PTY). The station name appears on the display as soon as the tuner receives it. Adjusting the tuner To ensure proper functioning of the tuner, the device must be set for the region in which it is being operated. You can select among Europe (EUROPE), America (USA), South America (S-AMERICA), and Thailand (THAI). The tuner is factory-set to the re- gion in which it was sold. If you experience... -
Page 13: Selecting The Waveband/Memory Bank
Switching the RDS function on/off To switch the RDS functions AF and REGIONAL on or off, press and hold down the TRA•RDS but- ton 7 for longer than two seconds. The RDS functions are active when RDS lights up in the display. Selecting the waveband/memory bank This device can receive programmes broad- cast over the FM frequency range as well as the MW and LW (AM) wavebands. There are three memory banks available for the FM waveband (FM1, FM2 and FMT) and one for each of the MW and LW wavebands. -
Page 14: Setting The Sensitivity Of Station Seek Tuning
Radio mode Setting the sensitivity of station seek tuning You can choose whether the radio should only tune into stations providing good re- ception or whether it can also tune into those with a weak reception. Press the MENU button 9. Press the or button : repeatedly until "SENS" appears on the display. The display shows the currently set sensitiv- ity level. "SENS HI3" means that the tuner is set to the highest sensitivity setting. "SENS LO1" means it is set to the lowest sensitiv-... -
Page 15: Setting The Scanning Time
"SCAN" appears briefly in the display fol- lowed by a flashing display of the current station name or frequency. Cancelling the SCAN and continuing to listen to a station Press the MENU button 9. Scanning stops and the radio continues playing the station that it tuned into last. Setting the scanning time Press the MENU button 9. -
Page 16: Optimising Radio Reception
Radio mode Selecting the PTY language You can select the language for the display of the programme types. Options include DEUTSCH, ENGLISH and FRANÇAIS. Press the MENU button 9. Press the or button : repeat- edly until "PTY LANG" appears on the display. Set the desired language with the or button :. When you have finished making your chang- press the MENU button twice 9. Selecting a programme type and starting seek tuning ... -
Page 17: Traffic Information
Traffic information Your device is equipped with an RDS-EON receiver. EON (Enhanced Other Network) ensures that whenever a traffic announce- ment (TA) is broadcast, the system switch- es automatically from a station that does not provide traffic reports to the appropri- ate traffic information station within the broadcasting network that does. Once the traffic report has been played, the system will switch back to the programme that you were listening to before. Switching traffic information priority on/off Press the TRA•RDS button 7. The priority for traffic announcements is ac- tivated if the display shows the traffic jam symbol. Notes: You will hear a warning beep •... -
Page 18: Cd Mode
CD singles with a diameter of 8 cm and noncircular contoured CDs (shape CDs) must not be used. We accept no responsibility for any dam- age to the CD drive that may occur as a result of the use of unsuitable CDs. To ensure proper functioning, use only CDs with the Compact-Disc logo. Copy-pro- tected CDs can cause playback problems. Blaupunkt cannot guarantee the proper functioning of copy-protected CDs! Besides being able to play audio CDs on this device, you can also play CDs containing MP3/WMA music files. For further informa- tion, please read the chapter entitled "MP3/ WMA mode". Switching to CD mode If there is no CD inserted in the drive, ... -
Page 19: Scanning Tracks (Scan)
Cancelling MIX Press the 5 MIX button ; again. "MIX OFF" appears briefly on the display and the MIX symbol disappears. Scanning tracks (SCAN) You can scan (briefly play) all the tracks on the CD. Press the MENU button 9 for longer than two seconds. The next track will then be scanned. Note: You can set the scanning time. For further information, please read the section entitled "Setting the scanning time" in the "Radio mode" chapter. -
Page 20: Mp3/Wma Mode
CD mode Notes: • If a CD is ejected, the drive will auto- matically draw it back in again after 10 seconds. • You can also eject CDs whilst the de- vice is switched off or whilst another audio source is activated. MP3/WMA mode MP3/WMA mode You can also use this car sound system to play CD-Rs and CD-RWs that contain MP3 music files. You can also play WMA files. The operation for playing MP3 and WMA files is identical. Notes: •... - Page 21 This device supports as many subdirecto- ries as your burner software can create de- spite the fact that the maximum directory depth defined by the ISO 9660 standard is only 8. T001 T001 T002 T002 T003 T003 T004 T004 T005 T005 T006 T001 T007 T002 T008 T003 T009 T004 T010 T005 T011...
-
Page 22: Switching To Mp3 Mode
MP3/WMA mode Switching to MP3 mode MP3 mode is activated in the same way as normal CD mode. For further information, please read the section entitled "Switching to CD mode" in the "CD mode" chapter. Configuring the display Configuring the default display You can display various types of informa- tion on the current track: • Directory number and track number • Directory number and time • Directory number and playing time • Track number and playing time • Track number and time To switch between the different display op- tions, press and hold down the DISPL ton 8 for longer than two seconds, to switch the display. -
Page 23: Selecting A Directory
Selecting a directory To move up or down to another directory, press the or button : once or several times. Selecting tracks/files To move up or down to another track/file in the current directory, press the or button : once or several times. If you press the button : once, the cur- rent track is played again from the beginning. Fast search To fast search backwards or forwards, press and hold down the or button : until fast searching backwards / for- wards begins. -
Page 24: Interrupting Playback (Pause)
MP3/WMA mode Cancelling repeat To stop the current track or current direc- tory from being repeated, briefly press the 4 RPT button ;. "RPT OFF" appears briefly on the display and RPT disappears. Interrupting playback (PAUSE) Press the 3 button ;. "PAUSE" appears on the display. Cancelling pause During the pause, press the button 3 ;. -
Page 25: Changing The Display
Changing the display Five options are available for the display in CD changer mode: • Track number and playing time • Track number and time • CD number and track number • CD number and time • CD number and playing time To switch between the display options, press and hold down the DISPL but- ton 8 for longer than two seconds. Repeating individual tracks or whole CDs (REPEAT) To repeat the current track, briefly press the 4 RPT button ;. "RPT TRCK" appears briefly and RPT lights up on the display. To repeat the current CD, press and hold down the 4 RPT button ; for longer than two seconds. "RPT DISC" appears briefly and RPT lights up on the display. Cancelling repeat To stop the current track or current CD from being repeated,... -
Page 26: Clock Time
Clock time Clock time Displaying the time To briefly display the time, briefly press the DISPL button 8. The time appears on the display for several seconds. Setting the time To set the time, press the MENU button 9. Press the or button : repeat- edly until "CLOCK SET" appears on the display. Press the button :. The time appears on the display. The hours flash and can be adjusted. Set the hours with the or button Once the hours are set, ... -
Page 27: Sound
Sound You can perform the sound settings (bass, middle, treble and sub-out) separately for every source (radio, CD, CD changer, AUX, traffic announcement and telephone/navi- gation). The volume distribution settings (balance and fader) apply to all the audio sources. Note: The settings of the sound for traffic announcements and telephone/navi- gation can only be made during a traf- fic announcement or a telephone call/ voice output. -
Page 28: Setting The Left/Right Volume Distribution (Balance)
Sound Setting the left/right volume distribution (balance) To adjust the left/right volume distribution (balance), press the AUDIO button 5. "BASS" appears on the display. Press the or button : repeatedly until "BAL" appears on the display with the current setting. Press the or button : to adjust the balance (right/left). Press the AUDIO button 5 to exit the menu. Adjusting the front/rear volume distribution (fader) To adjust the front/rear volume distribution (fader), press the AUDIO button 5. "BASS" appears on the display. Press the or button : repeatedly until "Fader" appears on the display with the current setting. -
Page 29: X-Bass
Preamplifier output Press the or button : once. Press the or button : repeatedly until the desired frequency appears on the display. When you have finished making your chang- press the AUDIO button 5 twice. X-BASS X-Bass allows you to increase the bass at low volume. The selected X-Bass setting is effective for all audio sources (radio, CD, CD changer or AUX). The X-BASS increase can be set in incre- ments of 1 to 3. "XBASS OFF" means that the X-BASS func- tion is switched off. Adjusting the X-BASS boost ... -
Page 30: Equalizer Presettings (Presets)
Adjusting the display settings Entering a switch-on message If you switch on the device, a brief mes- sage is shown on the display. The text "BLAUPUNKT" is preset at the factory. Instead, you can enter your own text of up to 9 characters. Press the MENU button 9. Press the or button : repeatedly until "ON MSG" appears on the display. -
Page 31: Adjusting The Display Brightness
Press the MENU button 9. The displays shows "MENU". Press the or button : repeat- edly until "PEAK LVL" appears on the display. Press the or button : to select between "PEAK ON" and "PEAK OFF". When you have finished making your chang- press the MENU button twice 9. Adjusting the display brightness If your car sound system is installed as described in the installation instructions and your vehicle features the correspond- ing connection, the display brightness is... -
Page 32: External Audio Sources
CD players, MiniDisc players or MP3 players. If you want to connect an external audio source, you will need an adapter cable. You can obtain this cable (Blaupunkt no.: 7 607 897 093) from your authorised Blaupunkt dealer. The AUX input must be activated in the menu. -
Page 33: Adjusting The Aux Preamplification
External audio sources Adjusting the AUX preamplification To be able to adjust for differences in vol- ume, the level adjustment of the AUX input can be adjusted in 4 increments (0 to 3). Press the MENU button 9. Press the or button : repeatedly until "AUX LVL" appears on the display. Press the or button : to adjust the level adjustment. When you have finished making your chang- es, press the MENU button twice 9. Technical Data Amplifier Output power: 4 x 18 watts sine at 14.4 V and 1% distortion factor at 4 ohms. 4 x 26 watts sine in accordance with DIN 45324 at 14.4 V at 4 ohms. 4 x 50 watts max. - Page 34 Bitte den ausgefüllten Gerätepass sicher aufbewahren! Please keep the filled-in radio pass in a safe place! Prière de conserver soigneusement la carte d’autoradio remplie ! Tenete per favore il libretto di apparecchio, debitamente riempito, in un posto sicuro! Bewaar de ingevulde apparaatpas op een veilige plaats! Vänligen förvara ifyllt apparatpass på...
- Page 35 (Asia Pacific) (MAL) +604-6382 474 Gerätepass Name: Typ: BP ... Serien-Nr: Blaupunkt GmbH, Robert-Bosch-Straße 200, D-31139 Hildesheim 02/06 - CM-AS/SCS1 (dt, gb, fr, it, nl, sw, es, pt, dk, pl, cz, sk) Fax: 05121-49 4002 01-610 39 391 02-525 5263...
