- Page 1 In Car Entertainment DVD-Player ME4 7 607 004 523 Operating and installation instructions http://www.blaupunkt.com http://www.blaupunkt.com...
- Page 3 STOP/RETURN for stopping/in- Button to switch the device on/off. terrupting playback. REP for activating/deactivating Numerical keys and PREV./ the REPEAT function. GOTO button for directly select- SCAN mode is only available in ing a chapter or a particular point TV mode. in time within the chapter.
-
Page 4: Table Of Contents
Notes ........33 External sources ....47 Road safety ........33 CD and MP3 mode ....48 Safety notice ......... 33 Equalizer ........ 49 Recycling and disposal ....34 Selecting sound presets ....49 Installation and connection ..35 Adjusting the user-defined Using for the first time ... - Page 5 Thank you for choosing a Blaupunkt Road safety has absolute prior- product. We hope you enjoy using this ity. Only operate this device if the new piece of equipment. road and traffic conditions allow you Please read these operating instruc- to do so.
- Page 6 Our products are made from materials DVD-ME4 DVD-CD-MP3 PLAYER that can be disposed of in an environ- mentally sensitive manner and are suit- able for appropriate recycling. Products that are to be scrapped must be collect- ed separately from household waste. To dispose of the product, please use the 80mm available waste return and collection...
- Page 7 You must take the following into account when selecting the installation location: - The vehicle tank must not be dam- The supplied installation kit contains two aged by screws. brackets, screws, a power supply ca- - There must be no wires or pipes ble and an IR receiver with a 3.5 mm running beneath the surface on jack plug.
-
Page 8: Notes
Connect the free ends of the supplied VIDEO VIDEO connection cable to your vehicle’s pow- er supply. AUDIO AUDIO DIGITAL Yellow: Continuous positive power AUX IN source 12V Remote Sensor Black: Earth Red: Ignition Connection socket (4 pin) The continuous positive power cable between the battery and the ME4 must additionally be protected directly at the battery with a fuse holder (5 amperes). - Page 9 Sicherung (FUSE) 5A gelb/yellow 1 2 V Batterie rot/red *) If connecting to terminal 15 of the vehi- ACC+B cle, you must protect the switched posi- I ==2A, 0,8A typ.*) tive cable by installing a fuse holder (0.8 A fuse) at a distance of max. 30 cm from terminal 15.
- Page 10 10cm 10cm 10cm...
- Page 11 The device is ready for operation when If you are using the ME4 for the first the device’s CD compartment lights up time, you must insert the batteries into blue. the remote control. To switch on the device, press the POWER button 1 on the re- mote control or the button 1 on the device.
- Page 12 “burned” yourself) can generally Press the MUTE button F again. also be played. Due to the varying qual- ity of CDs, Blaupunkt cannot guaran- tee that they will work properly. To ensure the system functions proper- ly, only use CDs labelled with the com- pact disc logo.
- Page 13 Risk of severe damage to the DVD drive! The ME4 has a slot-in drive without a Contoured DVDs/CDs (shape CDs) tray. It is only possible to achieve good and DVDs/CDs with a diameter of damping of the vibrations of the drive in 8 cm must not be used.
- Page 14 You can display various details regard- You can fast forward DVDs at double ing the playing time on the screen that speed, quadruple speed, 8-speed, 16- is connected to the device. You can hide speed, 32-speed and 64-speed (de- the on-screen display. pending on the DVD - some DVDs can only be played at up to 16 speed).
- Page 15 Once the speed has reached the one eighth setting, any subsequent press of A title on a DVD may be divided into the button will cause the film to be several smaller chapters. played backwards in slow motion. The To skip to the next or any other subse- screen displays the speed and SR for quent chapter, “Slow Rewind”.
- Page 16 To repeat the current title, press the REP button 2 on the You can directly select a particular po- sition on the DVD by entering the play- remote control a second time. ing time that corresponds with this po- “TITLE REPEAT ON” appears on the sition.
- Page 17 Note: You can also use the DVD menu to To display subtitles, change the playback language (see press the SUBTITLE button 9 on DVD menu). Additionally, you can set the remote control. your preferred playback language in the setup menu. For further information, Subtitles are displayed.
- Page 18 The DVD menu is provided by the DVD that you inserted in the player. After you You can zoom into a freely selectable insert a DVD and playback begins, the section of the film that is currently being DVD menu appears on-screen automat- played with up to 3 times the magnifi- ically.
- Page 19 DVDs generally provide menus in which You can connect two external sources you can select various options such as to this device. “Start film”, “Select chapter”, etc. You could, for instance, connect a tele- To switch between the individual menu vision tuner to the AUDIO/VIDEO IN items, sockets and a games console to the...
-
Page 20: Dvd Mode
Note: You cannot change directories during In addition to DVDs and video CDs, you playback. can also play audio CDs, photo CDs The other functions (play, search, pause (VCD 2.0) and MP3-CDs. and repeat) as described for DVD mode If you insert and play an audio CD, you can also be used in MP3 mode. - Page 21 The ME4 is equipped with a built-in 7- band equalizer that you can use to opti- You can adjust the equalizer to suit your mise the music reproduction to suit your requirements by boosting or reducing vehicle or the style of music. You have the output of the available frequencies.
- Page 22 Note: When you make your adjustments to the To deactivate the equalizer, settings, the sound reproduction chang- press the EQUALIZER button E es to reflect these changes. on the remote control. A few seconds after you adjust the final “EQUALIZER OFF” appears briefly on setting, the equalizer display disappears the display.
-
Page 23: On-Screen Display
Confirm your choice by pressing the ENTER/PLAY button C. The setup menu on the ME4 provides you with many options for customising Close the setup menu by pressing the DVD SETUP button ;. the device to suit your needs. The settings are saved and the setup menu closes. -
Page 24: Parental Lock
Normal/PS: The DVD player is 3 PG: Accompaniment by an adult is connected to a 4:3 monitor. The wi- recommended during playback. descreen picture is displayed using 4 PG 13: Accompaniment by an adult the full height of the screen. The is recommended, not suitable for chil- left and right edges of the wide- dren under the age of 13. - Page 25 The available age limits are displayed. If you have already set a pass- buttons = to select word, first use the numerical key- Use the pad 0-9 ? to enter the old pass- the required age limit. word next to “OLD PASSWORD”. Confirm your choice by pressing the ENTER/PLAY button B.
- Page 26 Note: Generally, the line output should be You can select the picture mode for op- used (“LINE OUT”). timum picture quality. Select the “AUTO” option. You can adjust the picture mode set- For DVDs with 1+1 audio mode (two ting in the “PIC MODE” menu item in mono channels), you can set how you the “GENERAL SETUP”...
-
Page 27: Pro Logic Setting
comes close to the Dolby 5.1 listening Close the setup menu by pressing the DVD SETUP button ;. experience. You can choose between the settings: The settings are saved and the setup “ON”, “OFF” and “AUTO”. If the “AUTO” menu closes. setting is selected and a Dolby Surround Pro Logic track is present on the disc, the device will always use the Pro Log-... - Page 28 If the screensaver is activated, a Blau- punkt logo is displayed approximately Operating voltage: 10.8 V to 23 V 60 seconds after the last action taken by the user in order to prevent individu- Current consumption: al pictures burning into the screen. In operation: less than 2.0 A During standby:...
- Page 29 76 511 803 76 511 809 Poland (PL) 0800-118922 022-8771260 Turkey (TR) 0212-335 06 71 0212-3460040 (USA) 800-2662528 708-6817188 Brasil (Mercosur) (BR) 0800 7045446 +55-19 3745 2773 Malaysia (Asia Pacific) (MAL) +604-6382 474 +604-6413 640 Blaupunkt GmbH 8622404637 08.05 CM/ASA...
