Notes: Please use this manual together with service manual
Model No.[SA-MAX770PUK], Order no. (PSG1401004CE).
• Speaker system SB-MAX670P-K, Order No: PSG1404009AE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 3
1.3. Protection Circuitry ---------------------------------------- 4
1.4. Caution For Fuse Replacement------------------------ 4
1.5. Safety Parts Information -------------------------------- 5
2 Warning -------------------------------------------------------------- 6
Model No.
Product Color: (K)...Black Type
PAGE
2.2. Precaution of Laser Diode -------------------------------7
(PbF) ---------------------------------------------------------- 7
prevention----------------------------------------------------8
© Panasonic Corporation 2014. All rights reserved.
Unauthorized copying and distribution is a violation of
law.
CD Stereo System
SA-MAX670P
SC-MAX670P
PSG1404008AE
A6
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-MAX670P Series

Summary of Contents for Panasonic SA-MAX670P Series

  • Page 1: Table Of Contents

    (PbF) ---------------------------------------------------------- 7 1.5. Safety Parts Information -------------------------------- 5 2.4. Handling Precautions for Traverse Ass’y ------------8 2 Warning -------------------------------------------------------------- 6 2.5. Grounding electrostatic breakdown prevention----------------------------------------------------8 © Panasonic Corporation 2014. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 3 Service Navigation---------------------------------------------- 10 3.1. Service Information -------------------------------------- 10 3.2. Notes -------------------------------------------------------- 10 4 Specifications ---------------------------------------------------- 11 5 Location of Controls and Components------------------ 12 5.1. Remote Control Key Button Operation ------------- 12 5.2. Main Unit Key Button Operation---------------------- 13 6 Block Diagram --------------------------------------------------- 15 6.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock, fire, or other hazards.

  • Page 4: Protection Circuitry

    ground. Caution: DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices. After repairs are completed, restore power gradually using a variac, to avoid overcurrent. Current consumption at AC 120 V, 60 Hz in FM mode at volume minimum should be ~ 850mA. 1.3.

  • Page 5: Safety Parts Information

    1.5. Safety Parts Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.

  • Page 6: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi- tive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 7: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 μW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 8: Handling Precautions For Traverse Ass

    2.4. Handling Precautions for Traverse Ass’y The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit (OPU) 2.4.1.
  • Page 9 2.5.2. Human body grounding • Use the anti-static wrist strap to discharge the static electricity form your body Figure 2-3. Figure 2-3...

  • Page 10: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 11: Specifications

    4 Specifications ” × 8 ” × 16 ” Mass (Weight) Approx. 7.1 kg (15.66 lbs) Amplifier section 0 °C to +40 °C Operating temperature RMS output power (each channel driven) range High 400+400 W (3 Ω), 1 kHz, 30% THD Operating humidity range 35% to 80% RH (no condensation)

  • Page 12: Location Of Controls And Components

    5 Location of Controls and Components 5.1. Remote Control Key Button Operation...

  • Page 13: Main Unit Key Button Operation

    5.2. Main Unit Key Button Operation...

  • Page 15: Block Diagram

    6 Block Diagram 6.1. Audio : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE : FM SIGNAL LINE IC4005 MAIN P.C.B. VUEALLPT090 MIC DET2 CN1401 P1803 MIC DET2 MIC DET2 TO SYSTEM CONTROL IC4002 MIC DET1 CN1401 P1803...
  • Page 16 : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE : FM SIGNAL LINE SPEAKERS MAIN P.C.B. Q4505 AMPLIFIER JK4201 38 IN3 LEFT LOW JK4201 46 IN1 40 IN4 Q4506 AMPLIFIER 44 IN2 Q4502 AMPLIFIER Q4509...

  • Page 17: Schematic Diagram

    7 Schematic Diagram 7.1. Schematic Diagram Notes • Voltage and signal line : +B signal line • This schematic diagram may be modified at any time : -B signal line with the development of new technology. : CD Audio input signal line Notes: : Tuner/Music Port/AUX/Mic/Bluetooth Audio input signal line...

  • Page 19: Main (I/O Expansion) Circuit

    7.2. Main (I/O Expansion) Circuit SCHEMATIC DIAGRAM - 1 MAIN (I/O EXPANSION) CIRCUIT : +B SIGNAL LINE : AUX/MIC AUDIO INPUT SIGNAL LINE USBLED_REC USBLED_PLAY1 R1236 C1826 1000P P1802 SP_INT R1226 REM_IN 3.3K PW_XSW3R3V PW_STBY3R3V FAN_OUT C1804 DGND R1229 C1803 1000P 3.3K DGND...

  • Page 20: Main (Fan Led) Circuit

    7.3. Main (Fan LED) Circuit SCHEMATIC DIAGRAM - 2 MAIN (FAN LED) CIRCUIT : +B SIGNAL LINE IC1501 AN32183A-VF P1501 LED DRIVER LB1508 R1501 J0JBC0000010 TO SB-MAX670 (LEFT) PW_SW3R3V IREF C1525 R1504 I2C_SCL AGND I2C_SDA NRST ILUMI_NRST R1503 SLAVSEL C1505 C1506 CLKIO KIRARI_IN...

  • Page 21: Main (Dsp) Circuit

    7.4. Main (DSP) Circuit SCHEMATIC DIAGRAM - 3 MAIN (DSP) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE C4055 R4037 0.047 1.5K R4034 LEFT MID LOW R4031...

  • Page 22: Main (Amp Btl) Circuit (1/2)

    7.5. Main (AMP BTL) Circuit (1/2) SCHEMATIC DIAGRAM - 4 MAIN (AMP BTL) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE AMP_GND D4508 B0ACGM000001 R4549 R4516 R4519 5.6K 4.7K R4547 D4507 B0ACGM000001 R4548 R4552 C4528 C4584 R4550...

  • Page 23: Main (Amp Btl) Circuit (2/2)

    7.6. Main (AMP BTL) Circuit (2/2) SCHEMATIC DIAGRAM - 5 MAIN (AMP BTL) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE P4501 PW_+40V +B (40V) C4599 +B (40V) AMP_GND +B (40V) C4555 C4567 C4560 50V3300 PWR_GND C4570...

  • Page 24: Main (Micon) Circuit (1/2)

    7.7. Main (MICON) Circuit (1/2) SCHEMATIC DIAGRAM - 6 MAIN (MICON) CIRCUIT : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE : USB SIGNAL LINE : +B SIGNAL LINE : -B SIGNAL LINE BT_UART_RTS BT_UART_RTS BT_UART_RX BT_UART_RX BT_UART_TX BT_UART_TX C2009...

  • Page 25: Main (Micon) Circuit (2/2)

    7.8. Main (MICON) Circuit (2/2) SCHEMATIC DIAGRAM - 7 MAIN (MICON) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE : USB SIGNAL LINE IC1003 RFKWFAX670LM 16M FLASH MEMORY DSP_WCK G_DSP_BCK DSP_SDO0...

  • Page 26: Main (Amp Single) Circuit (1/2)

    7.9. Main (AMP Single) Circuit (1/2) SCHEMATIC DIAGRAM - 8 MAIN (AMP SINGLE) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE TO MAIN (AMP SINGLE) C4279 C4278 IC4201 R4282 CIRCUIT (2/2) C0JBAB000902 C4277 100P OSCILLATOR AMP R4281 X4201...

  • Page 27: Main (Amp Single) Circuit (2/2)

    7.10. Main (AMP Single) Circuit (2/2) SCHEMATIC DIAGRAM - 9 MAIN (AMP SINGLE) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE : AUDIO OUTPUT SIGNAL LINE TO MAIN (AMP SINGLE) PW_+40V CIRCUIT (1/2) D4215 C4254 C4280 B0HCMM000019 50V3300 C4283 1000P D4214 Q4206...

  • Page 28: Main (Fe) Circuit

    7.11. Main (FE) Circuit SCHEMATIC DIAGRAM - 10 MAIN (FE) CIRCUIT : +B SIGNAL LINE : CD AUDIO INPUT SIGNAL LINE OPEN_SW INNER_SW CLOSE_SW C5009 LB5003 J0JHC0000045 PW_CD_SW5R4V C5010 0.01 LD_CCW C5031 C5030 C5029 C5028 C5027 LD_CW 100P 100P 100P 1000P 100P R5014...

  • Page 29: Main (Karaoke) Circuit

    7.12. Main (Karaoke) Circuit SCHEMATIC DIAGRAM - 11 MAIN (KARAOKE) CIRCUIT : +B SIGNAL LINE : CD AUDIO INPUT SIGNAL LINE : TUNER/AUX/MIC AUDIO INPUT SIGNAL LINE DGND IC4802 R4820 C0FBAY000032 A/D CONVERTER R4835 DSP_SDO1_A RX4802 R4823 D1H81034A042 SCLK LRCK R4822 SDTO MCLK...

  • Page 30: Main (Digital-Power) Circuit (1/2)

    7.13. Main (Digital-Power) Circuit (1/2) SCHEMATIC DIAGRAM - 12 MAIN (DIGITAL-POWER) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE CN8001 POSITIVE SMPS_FAN_N NEGATIVE SMPS_FAN_P TO MAIN (DIGITAL-POWER) SMPS_BP SMPS_BP CIRCUIT (2/2) PCONT SMPS_ID SMPS_ID GND_SYS_3R3V SMPS SYS3.3 CIRCUIT (CN1851) SYNC SYNC IN SCHEMATIC...

  • Page 31: Main (Digital-Power) Circuit (2/2)

    7.14. Main (Digital-Power) Circuit (2/2) SCHEMATIC DIAGRAM - 13 MAIN (DIGITAL-POWER) CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE PW_SW5R4V TO MAIN (DIGITAL-POWER) CIRCUIT (1/2) K8001 PW_CD_SW5R4V PDET IC8003 IC8005 C8032 C0DBAYY01094 C0DBAYY01685 D8003 DA2J10100L DC-DC CONVERTER DC-DC CONVERTER R8012 D8008 DA2J10100L...

  • Page 32: Main (Usb) Circuit

    7.15. Main (USB) Circuit SCHEMATIC DIAGRAM - 14 MAIN (USB) CIRCUIT : +B SIGNAL LINE : USB SIGNAL LINE USB_OE USB_SEL PW_XSW3R3V T9001 P9001 J0ZZB0000182 IC9001 DGND C0JBAS000401 D+ A USB SWITCH USB CIRCUIT D- A R9003 (CN9001) 2.2K DGND IN SCHEMATIC USB_D+ D+ B...

  • Page 33: Main (Aux Tuner) Circuit

    7.16. Main (AUX Tuner) Circuit SCHEMATIC DIAGRAM - 15 MAIN (AUX TUNER) CIRCUIT : +B SIGNAL LINE : TUNER/AUX AUDIO INPUT SIGNAL LINE : FM SIGNAL LINE JK4952 AUX IN 1 ANALOG_SEL LB4901 J0JBC0000010 PW_SW12R0V R4906 R4926 QR4901 R4901 C4904 B1GBCFJJ0040 ANALOG_SEL2 SWITCH...

  • Page 34: Illumination Left, Illumination Right, Button Right & Usb Circuit

    7.17. Illumination Left, Illumination Right, Button Right & USB Circuit SCHEMATIC DIAGRAM - 16 ILLUMINATION LEFT CIRCUIT ILLUMINATION RIGHT CIRCUIT P1950 P1980 ILLUMINATION JOG VOLUME JOG CIRCUIT (P1931) CIRCUIT (P1961) Z3(BLUE) IN SCHEMATIC Z2(GREEN) IN SCHEMATIC D1981 D1980 DIAGRAM - 20 DIAGRAM - 18 B3AZB0000101 B3AZB0000101...

  • Page 35: Fl Display Circuit

    7.18. FL Display Circuit SCHEMATIC DIAGRAM - 17 FL DISPLAY CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE DP1700 DP1800 A2BB00000186 A2BB00000185 FL DISPLAY FL DISPLAY R1804 C1804 C1805 D1800 1000P 1000P R1803 B0JCMD000066 1.2K R1713 Q1800 C1802 DSC200200L D1703 SWITCH DZ2J030M0L...

  • Page 36: Volume Jog & Multi Control Circuit

    7.19. Volume Jog & Multi Control Circuit SCHEMATIC DIAGRAM - 18 VOLUME JOG CIRCUIT MULTI CONTROL CIRCUIT : +B SIGNAL LINE : +B SIGNAL LINE P1602 SG11/KS11 SG10/KS10 R1960 R1961 SG9/KS9 P1960 SG8/KS8 BUTTON RIGHT CD_3R3V SG7/KS7 CIRCUIT (P1650) DGND IN SCHEMATIC VR1960 VOL_JOG_A...

  • Page 37: Button Left Circuit

    7.20. Button Left Circuit SCHEMATIC DIAGRAM - 19 BUTTON LEFT CIRCUIT : +B SIGNAL LINE P1500 P1501 DGND DGND DGND VOL_JOG_A IRQ3V VOL_JOG_B DGND ILLUMI_JOG_A DGND ILLUMI_JOG_B BT_UART_RTS BLUETOOTH5V CDO_ON_R MAIN (I/O EXPANSION) HOST WAKE CIRCUIT (P1801) IN SCHEMATIC DIAGRAM - 1 DJ_JOG_LED_CTL DJ_JOG_A DJ_JOG_B...

  • Page 38: Mic, Illumination Jog & Cd Interface Circuit

    7.21. Mic, Illumination Jog & CD Interface Circuit SCHEMATIC DIAGRAM - 20 MIC CIRCUIT ILLUMINATION JOG CIRCUIT : +B SIGNAL LINE : AUX/MIC AUDIO INPUT SIGNAL LINE : +B SIGNAL LINE P1932 BUTTON LEFT ILLUMI_JOG_B CIRCUIT (P1503) ILLUMI_JOG_A IN SCHEMATIC VOL_JOG_B DIAGRAM - 19 VOL_JOG_A...

  • Page 39: Smps Circuit (1/2)

    7.22. SMPS Circuit (1/2) SCHEMATIC DIAGRAM - 21 SMPS CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE D1001 B0FBCR000021 L1001 L1002 G0B852L00001 G0B852L00001 LB1001 LB1005 R1001 C1001 P1001 0.22 J0JKB0000015 J0JKB0000015 ZC1705* WIRE CLAMPER AC IN ZC1851* DZ1001 D4EAY511A127 WIRE CLAMPER 110V~240V 50/60Hz ZA1002...

  • Page 40: Smps Circuit (2/2)

    7.23. SMPS Circuit (2/2) SCHEMATIC DIAGRAM - 22 SMPS CIRCUIT : +B SIGNAL LINE : -B SIGNAL LINE ZA1101* D1105 LB1102 HEATSINK B0ECNR000003 J0JKB0000015 D1104 B0FABR000025 TO SMPS IC1601 CIRCUIT (1/2) C0DAZYY00039 LB1103 C1118 470P SHUNT REGULATOR Q1404 B3PBA0000579 PCONT R1602 C1113 470P...

  • Page 41: Printed Circuit Board

    8 Printed Circuit Board 8.1. Main P.C.B. (Side A) MAIN P.C.B. (RFKV5033FA) R5009 LB1802 C9005 R5010 C5012 LB1803 LB5015 LB5014 LB1804 LB1807 C5001 C9006 LB1805 LB1806 LB1808 C5002 C5004 IC5001 C5003 C2008 C2010 C5010 C5009 C1023 R1034 C1006 R1032 R1031 LB1005 R1033 C1032...

  • Page 42: Main P.c.b. (Side B)

    8.2. Main P.C.B. (Side B) MAIN P.C.B. (RFKV5033FA) 3741AA-1 3741AA-1 LB5016 P1801 C5026 C5027 C5025 P5002 P5001 8 10 P9002 C5023 C5018 R5023 C5024 C5031 C5015 C2009 IC2001 C5028 C5029 R9006 R9008 Q5001 R5017 LB5010 R5015 C2012 Q9004 Q9003 R5020 R5019 C2005 R5040...

  • Page 43: Button Left, Button Right & Mic P.c.b

    8.3. Button Left, Button Right & Mic P.C.B. BUTTON LEFT P.C.B. (REP5034CB) BUTTON RIGHT P.C.B. (REP5034CC) W598 W596 W599 W597 S1508 S1512 S1660 S1654 S1652 D1556 S1502 D1507 W551 W578 W577 S1500 W563 (DJ-JUKEBOX) (RADIO/EXT-IN) (MEMORY4) D1522 (FF) (MEMORY REC) (LATIN PRESET EQ) (POWER SW) W582...

  • Page 44: Smps P.c.b

    8.4. SMPS P.C.B. SMPS P.C.B. (REP5035A) ZJ1001 ZJ1851 Q1702 L1601 T1401 C1604 SECONDARY QR1601 Q1405 D1601 R1601 Q1403 C1701 R1704 IC1601 C1602 PRIMARY D1405 R1607 R1419 Q1404 R1603 C1406 R1420 Q1402 R1415 ZC1851* F1401 T500mAL 250V C1104 T1101 R1102 R1107 IC1402 C1106 IC1101...

  • Page 45: Exploded View And Replacement Parts List

    9 Exploded View and Replacement Parts List 9.1. Cabinet Parts Location 1 DP1800 DP1700 ZA1701 IR1701 (FL DISPLAY P.C.B.) (ILLUMINATION JOG P.C.B.) (USB P.C.B.) T1700 P1960 P1700 P1932 CN9002 P1930 VR1960 JK9001 *P7701 P1961 CN9001 VR1930 P1931 JK9002 (VOLUME JOG P.C.B.) **(BLUETOOTH/NFC KIT) (ILLUMINATION LEFT P.C.B.) P1980...

  • Page 46: Cabinet Parts Location

    9.2. Cabinet Parts Location 2 P1650 P1501 P1500 (BUTTON RIGHT P.C.B.) P1502 (BUTTON LEFT P.C.B.) P1503 P1504 P1601 P1600 P1602 VR1600 (MULTI CONTROL P.C.B.) SA-MAX670P-K CABINET DRAWING NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY.

  • Page 47: Cabinet Parts Location

    9.3. Cabinet Parts Location 3 (CD MECHANISM UNIT) *D-AMP HEATSINK T1502 *HEATSINK T1501 *HEATSINK *HEATSINK *HEATSINK *HEATSINK *HEATSINK P4501 JK4952 *HEATSINK P1803 JK7001 CN1853 CN1852 ZJ1701 CN1851 P1501 ZJ8003 P1502 *HEATSINK P1001 *HEATSINK CN1854 JK4201 T1203 P9001 ZJ1103 *WIRE CLAMPER ZJ8001 *WIRE CLAMPER P1003...

  • Page 48: Packaging

    9.4. Packaging A1-1 SA-MAX670P ACCESSORIES BAG AC CORD **PAD OI BOOK FM INDOOR ANTENNA SB-MAX670P **PAD LEG CUSHION SET **PAD BOX SC-MAX670 F R O N T POLYFOAM (BOTTOM LEFT) POLYFOAM (BOTTOM RIGHT) POLYFOAM (TOP LEFT) POLYFOAM (TOP RIGHT) SC-MAX670P-K NOTE: "**"...

  • Page 49: Mechanical Replacement Part List

    9.5. Mechanical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description REE1900 10P FFC (MAIN-CD Safety Ref. Part No. Part Name & Qty Remarks INTERFACE) Description REX1678 13P WIRE (MAIN- SMPS) CABINET REX1679 WIRE (MIC- CHASSIS MAIN) REX1680 WIRE...
  • Page 50 Safety Ref. Part No. Part Name & Qty Remarks Description RHD30119-S SCREW RHDX031008 SCREW RKAX0042-K LEG CUSHION RKM0744-K2 TOP CABINET RMA2489 FAN ANGLE RMA2491 SUPPORT ANGLE RMB0982 CD LID SPRING RMG0982-H RADIATION RUBBER RMK0870-1 BOTTOM CHASSIS RMK0871-1 INNER CHASSIS RMN1000-1 FL HOLDER RMN1049-1 FL HOLDER...

  • Page 51: Electrical Replacement Part List

    9.6. Electrical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks IC1004 RFKV5033FB (E.S.D) Description IC1101 C0DBBYY00075 (E.S.D) IC1202 C0DBBYY00076 (E.S.D) PRINTED CIR- IC1202 C0ZBZ0002175 (E.S.D) CUITS BOARDS IC1401 C1AB00003130 (E.S.D)
  • Page 52 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description IC8501 C0ABBB000342 (E.S.D) QR4902 B1GBCFJJ0040 TRANSISTOR (E.S.D) IC9001 C0JBAS000401 (E.S.D) QR8001 B1GBCFJJ0040 TRANSISTOR (E.S.D) QR8003 B1GBCFJJ0040 TRANSISTOR (E.S.D) TRANSISTORS QR8004 B1GBCFJN0038 TRANSISTOR (E.S.D)
  • Page 53 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description D1659 DA2J10100L DIODE (E.S.D) D8003 DA2J10100L DIODE (E.S.D) D1660 DA2J10100L DIODE (E.S.D) D8004 DA2J10100L DIODE (E.S.D) D1661 DA2J10100L DIODE (E.S.D) D8005 B0JCND000021 DIODE...
  • Page 54 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description CN7002 K1MY10BA0539 10P CONNECTOR LB1016 J0JBC0000010 INDUCTOR CN8001 K1ZZ00000834 CONNECTORS LB1017 J0JCC0000286 INDUCTOR CN9001 K1KA06BA0061 6P CONNECTOR LB1018 J0JCC0000286 INDUCTOR CN9002 K1KA07BA0061 7P CONNECTOR...
  • Page 55 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description LB5010 J0JBC0000010 INDUCTOR OSCILLATORS LB5011 J0JBC0000010 INDUCTOR LB5012 J0JBC0000010 INDUCTOR X1001 H0J169500036 OSCILLATOR LB5013 J0JBC0000010 INDUCTOR X1002 H0A327200181 OSCILLATOR LB5014 J0JBC0000010 INDUCTOR X4001...
  • Page 56 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description W563 D0GBR00JA008 1/10W R1015 D0GB102JA008 1/10W W567 D0GDR00JA017 1/8W R1016 D0GB101JA008 1/10W W569 D0GBR00JA008 1/10W R1017 D0GB101JA008 1/10W W575 D0GDR00JA017 1/8W R1018 D0GB101JA008...
  • Page 57 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R1406 D0GB104JA065 100K 1/10W R1711 D0GB270JA065 1/10W R1407 D0GB561JA065 1/10W R1711 D1BB2401A074 2.4K 1/10W R1408 D0GB681JA065 1/10W R1712 D0GB471JA065 1/10W R1409 D0GBR00J0004 1/10W...
  • Page 58 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R4043 D0GB103JA008 1/10W R4240 D0GB473JA008 1/10W R4044 D0GB562JA008 5.6K 1/10W R4241 D0GB4R7JA008 1/10W R4045 D0GB152JA008 1.5K 1/10W R4242 D0GB392JA008 3.9K 1/10W R4046 D0GB821JA008...
  • Page 59 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R4525 D0GB473JA008 1/10W R4834 D0GBR00JA008 1/10W R4526 D0GB473JA008 1/10W R4835 D0GB101JA008 1/10W R4527 D0GB220JA008 1/10W R4901 D0GB123JA065 1/10W R4528 D0GB220JA008 1/10W R4902 D0GB822JA065...
  • Page 60 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R8044 ERJ3RBD333V 1/16W RX1003 D1H81014A042 RESISTOR NETWORK R8045 ERJ3RBD911V 1/16W RX1004 D1H82224A042 RESISTOR NETWORK R8046 ERJ3RBD103V 1/16W RX4001 D1H82214A042 RESISTOR NETWORK R8048 ERJ3RBD222V 2.2K...
  • Page 61 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C1217 F1K1H105A251 C1703 F1H1A105A036 C1218 F2A1E1010120 100uF C1703 F2A1V102B750 1000uF C1219 F1H1H4700006 47pF C1704 F1H1H104A783 0.1uF C1220 F1H1H102A219 1000pF C1704 F1H1H333B047 0.033uF 50V C1221...
  • Page 62 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C4016 F1H0J1060006 10uF 6.3V C4219 F1H1H222A831 2200pF C4017 F1H1H222B047 2200pF C4220 F1J1C334A091 0.33uF C4018 F1H1H561B052 560pF C4221 F1H1H102A831 1000pF C4019 F1J1C1060001 10uF C4222...
  • Page 63 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C4507 F1H1H1010005 100pF C4821 F1H1A105A028 C4508 F1J1C1060001 10uF C4823 F1H1C104A041 0.1uF C4509 F1H1H1010005 100pF C4825 F1H0J1060006 10uF 6.3V C4510 F1H1H102A831 1000pF C4904 F1H1A105A028...
  • Page 64 Safety Ref. Part No. Part Name & Qty Remarks Description C8029 F1H1H1500009 15pF C8030 F1H1H6810005 680pF C8031 F1H1H332A219 3300pF C8032 F1H1H104A783 0.1uF C8046 F1J0J106A014 10uF 6.3V C8047 F1J0J106A014 10uF 6.3V C8048 F1H1H1010005 100pF C8049 F1J0J106A014 10uF 6.3V C8051 F1H1H104A783 0.1uF C8052 F1H1H104A783 0.1uF...
