Cutter Unit

LT-F3000 Heavy-Duty Triple Turf Flail Mower
Model No. 02830

Introduction

Read this information carefully to learn how to operate
and maintain your product properly and to avoid
injury and product damage. You are responsible for
operating the product properly and safely.
You may contact Toro directly at www.Toro.com
for product safety and operation training materials,
accessory information, help finding a dealer, or to
register your product.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Toro
Distributor or Toro Customer Service and have the
model number of your product ready.
© 2017-The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
This product complies with all relevant European
directives. For details, please see the Declaration of
Incorporation (DOI) at the back of this publication.
Contents
Introduction ............................................................... 1
Safety ....................................................................... 2
Setup ........................................................................ 3
Operation .................................................................. 5
Maintenance ............................................................. 7
Register at www.Toro.com.
Installation Instructions
Safety and Instructional Decals .......................... 2
Assembling the Cutting Unit................................ 3
to a Center Unit ............................................... 5
Cutting Unit General Information......................... 5
Adjusting the Height of Cut ................................. 5
Inspecting the Blades ......................................... 6
Lubricating the Cutting Unit................................. 7
Unit ................................................................. 7
Sharpening the Blades ....................................... 8
Checking the Blade Bolts.................................... 8
Checking the Rear Guard ................................... 8
Clearing a Blocked Rotor .................................... 8
Checking the Rubber Guard ............................... 9
Checking the Cutting-Unit Pivot .......................... 9
Checking the Rotor ............................................. 9
Adjustment...................................................... 9
Tension ......................................................... 10
Replacing the Blades........................................ 10
Original Instructions (EN)
All Rights Reserved *3403-993* B
Printed in the USA
Form No. 3403-993 Rev B

Advertisement

Table of Contents
loading

Related Manuals for Toro LT-F3000

Summary of Contents for Toro LT-F3000

  • Page 1: Table Of Contents

    Safety ............... 2 register your product. Safety and Instructional Decals ......2 Setup ................ 3 Whenever you need service, genuine Toro parts, or Assembling the Cutting Unit........ 3 additional information, contact an Authorized Toro Changing the Cutting Unit from Left-Side Distributor or Toro Customer Service and have the Drive to Right-Side Drive.........

  • Page 2: Safety

    Safety Safety and Instructional Decals Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost. decal40-13-010 40-13-010 1. Cutting hazard of hand 2. Cutting hazard of foot decal111-9648 111-9648 1.

  • Page 3: Setup

    Installation Loose Parts Use the chart below to verify that all parts have been shipped. Description Qty. Front bar Rear guard Skid Short carriage bolt Washer (M10) Locknut (M10) Long carriage bolt Assemble the cutting unit. Socket-head bolt Carriage bolt (M6) Washer (M6) Locknut (M6) Spacer...

  • Page 4: Changing The Cutting Unit From Left-Side Drive To Right-Side Drive

    Changing the Cutting Unit from Left-Side Drive to Right-Side Drive Front Left Cutting Unit Only Remove the weight (Figure g036876 Figure 3 1. Long carriage bolt (2) 4. Skid (2) 2. Washer (6) 5. Socket-head bolt (4) 3. Locknut (6) Install the rear guard as shown in Figure g036877...

  • Page 5: Changing The Cutting Unit From A Front Unit To A Center Unit

    Changing the Cutting Unit Adjusting the Height of Cut from a Front Unit to a Note: The height of cut is determined by the rear roller. Blade wear, worn cutting-unit pivots, Center Unit bent/damaged cutting-unit pivot shafts, and bent/damaged arms can affect the height-of-cut Note: The center cutting unit does not require a setting.

  • Page 6: Inspecting The Blades

    Inspect each blade for excessive wear using the wear line (Figure 10). When a blade is worn down to the wear line, replace the blade. g034634 Figure 10 g034925 Figure 8 1. Wear line 1. 75 mm (3.0 inches) 4. 40 mm (1.5 inches) Make sure that each blade bolt is torqued to 45 2.

  • Page 7: Maintenance

    Maintenance Replace any damaged grease fittings. Important: Use 1 pump of grease on the height-of-cut adjusters and 3 pumps of grease on Lubricating the Cutting Unit all other grease fittings. Service Interval: Before each use or daily Refer to Figure 11 for where to grease the cutting Grease Type: No.

  • Page 8: Sharpening The Blades

    Checking the Rear Guard Service Interval: Before each use or daily Inspect the rear guard for wear or damage (Figure 14). Replace the rear guard if it is damaged to prevent objects being thrown into the operator’s area. g036883 Figure 13 Center cutting unit only 1.

  • Page 9: Checking The Rubber Guard

    Note: Use a wooden pole to remove the blockage. If you cannot resolve the vibration issue, contact your Authorized Service Dealer. Important: The flail rotor may rotate when Raise and support the cutting unit. you release the blockage. Grip the rotor at each end and check for Important: Support the wooden pole in the excessive end play.

  • Page 10: Checking The Rear-Roller Scraper Wire Tension

    Checking the Rear-Roller Mark the position of the bolt head so that you can replace the bolts from the same side. Scraper Wire Tension Holding the blade in a rag or padded glove, remove the nut, bolt, bushing, and blade (Figure Service Interval: Every 50 hours 18).
  • Page 11 Notes:...

  • Page 12: Model No

    The method of transmission shall be electronic transmittal. This machinery shall not be put into service until incorporated into approved Toro models as indicated on the associated Declaration of Conformity and in accordance with all instructions, whereby it can be declared in conformity with all relevant Directives.
