Heron™
D130 READERS
QUICK REFERENCE
820001200

Advertisement

Table of Contents
loading

Related Manuals for Datalogic Heron D130

Summary of Contents for Datalogic Heron D130

  • Page 1 Heron™ D130 READERS QUICK REFERENCE 820001200...
  • Page 2 USING HERON    SERIES READERS Heron guns automatically scan barcodes at a distance. Simply aim and pull the trigger. Code scanning is performed along the center of the light bar emitted from the reading window. This bar must cover the entire code. Successful scanning is obtained by tilting the scanner with respect to the barcode to avoid direct reflections which impair the reading performance, see the figure above.

  • Page 3: Ibm Usb Pos

    (if required) With the USB cable, this accessory device is intended to be supplied by a UL Listed Power Unit marked "Class 2", or an LPS power source which supplies power directly to the reader. IBM USB POS With the USB cable, this accessory device is intended to be connected to a UL Listed computer which supplies power directly to the reader.

  • Page 4: Disconnecting The Cable

    WEDGE With the Wedge or PC Notebook cables, this accessory device is intended to be connected to either a UL Listed Computer which supplies power directly to the reader or a UL Listed Direct Plug-in Power Unit marked “Class 2”, rated 5 V, minimum 180 mA.

  • Page 5: Stand Installation

    STAND INSTALLATION The stand can be mounted by using self-tapping screws, double sided adhesive strips or rubber feet: mount the stand directly to the surface using the self-tapping screws; carefully clean the bottom surface of the stand and the table surface. Remove the protective plastic from one side of the adhesive strips and stick them on the stand bottom.

  • Page 6: Interface Selection

    Load drivers from the O.S. (if requested). When configuring the USB-COM interface, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the web page http://www.datalogic.com/services/support/. The reader is ready.
  • Page 7 First Start-Up Connect Heron™ Green LED blinks USB to Host Load drivers (if requested) Does a dialog box appear Disconnect reader Green LED off warning that Bus at Host power is not sufficient? Connect external power supply to cable and power up Green LED off - BEEP OK Select desired USB Reconnect reader...

  • Page 8: Usb Interface Selection

    USB INTERFACE SELECTION USB-KBD USB-COM* USB-IBM-Table Top USB-IBM-Hand Held USB-KBD-ALT-MODE USB-KBD-APPLE * When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software which can be downloaded from the Heron™ USB web page (see http://www.datalogic.com/services/support/).

  • Page 9: Usb Keyboard Nationality

    USB KEYBOARD NATIONALITY USB-KBD users should select one of the following KEYBOARD NATIONALITY codes. Belge Deutsch English Español Français Italiano Svenskt...

  • Page 10: Rs232 Reader Configuration

    USB KEYBOARD NATIONALITY (Continued) Japanese RS232 READER CONFIGURATION Read the RESTORE DEFAULT code, then read the interface selection code for your application. RESTORE DEFAULT RS232 Standard POS Systems Nixdorf Mode A Fujitsu ICL Mode...
  • Page 11 WEDGE READER CONFIGURATION Read the RESTORE DEFAULT code, then read the interface selection code for your application. RESTORE DEFAULT WEDGE IBM AT or PS/2 PCs IBM XT PC Notebook IBM SURE1 IBM Terminal 3153...

  • Page 12: Key Transmission Mode

    WEDGE (continued) IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct TRANSMISSION code. Select KEYBOARD TYPE if necessary (default = advanced keyboard). KEY TRANSMISSION MODE make-only keyboard make-break keyboard KEYBOARD TYPE advanced keyboard typewriter keyboard The following interface selection allows barcodes sent to the PC to be interpreted correctly independently from the...
  • Page 13 WEDGE (continued) Wyse Terminals ANSI Keyboard PC Keyboard ASCII Keyboard VT220 style Keyboard Digital Terminals VT2xx/VT3xx/VT4xx APPLE APPLE ADB Bus...

  • Page 14: Wedge Keyboard Nationality

    WEDGE KEYBOARD NATIONALITY Wedge users should select one of the following WEDGE KEYBOARD NATIONALITY codes. Belge Deutsch English Español Français Italiano Svenskt The following Keyboard Nationality selection is only valid for IBM AT compatible PCs: Japanese...

  • Page 15: Default Values

    PEN READER CONFIGURATION Read the RESTORE DEFAULT code, then read the PEN interface selection code. RESTORE DEFAULT DEFAULT VALUES USB DEFAULT SETTINGS : code identifier disabled, no field adjustment, DATA FORMAT code length not transmitted, character replacement disabled. : USA keyboard, inter-character and inter- USB KEYBOARD code delays disabled, control character emulation = ctrl+shift+key;...
  • Page 16 RS232 Nixdorf DEFAULT SETTINGS : code identifier enabled, no field adjustment, DATA FORMAT code length not transmitted, no header, terminator = CR, character replacement disabled RS232 Fujitsu DEFAULT SETTINGS 9600 baud, no parity, 8 data bits, 1 stop bit, no handshaking, delay disabled, rx timeout 2 sec., ack/nack disabled, FIFO enabled, serial trigger lock disabled;...

  • Page 17: Code Selection

    CODE SELECTION Enabled codes • EAN 8/EAN 13 / UPC A/UPC E without ADD ON check digit transmitted, no conversions • Interleaved 2/5 check digit control and transmission, variable length code; 4-99 characters • Standard Code 39 no check digit control, variable length code; 1-99 characters •...

  • Page 18: Operating Test

    OPERATING TEST Read the TEST codes below. EAN-8 1 2 3 4 5 6 7 0 EAN-13 1 2 3 4 5 6 7 0 0 0 9 9 2 Code 39 (Normal) Code 128 Interleaved 2 of 5 0 1 2 3 4 5 6 7 8 4 YOUR READER IS NOW READY TO READ BARCODES.

  • Page 19: Technical Features

    LED Safety Class Class 1 EN 60825-1 Reading Field see reading diagrams Max. Resolution 0.10 mm (4 mils) min. 15% (Datalogic Test Chart) Environmental Features 0 °C to + 55 °C Working Temperature -20 °C to + 70 °C Storage Temperature...

  • Page 20: Reading Diagram

    READING DIAGRAM D130 (STD) - Reading Zones (10° skew angle) 0.13 mm CODE 39 (5 mils) 0.50 mm (20 mils) CODE 39 0.13 mm (5 mils) EAN13 M=1 0.33 mm (13 mils) (cm)

  • Page 21: Warranty

    Datalogic has the faculty to repair or replace the product, these provisions do not prolong the original warranty term. The warranty does not apply to any product that has been subject to misuse, accidental damage, unauthorized repair or tampering.

  • Page 22: Fcc Compliance

    PATENTS This product is licensed under one or more of the following U.S. patents: 4,282,425; 4,570,057; 4,766,300; 4,894,523; 5,021,642; 5,038,024; 5,081,343; 5,095,197; 5,144,119; 5,144,121; 5,182,441; 5,187,355; 5,187,356; 5,218,191; 5,233,172; 5,258,606 and /or 5,288,985 This product is covered by one or more of the following patents and patent applications: US 5,917,176;...
